Follett HCE1400A Operation And Service Manual
  1. Manuals
  2. Brands
  3. Follett Manuals
  4. Ice Maker
  5. HCE1400A
  6. Operation and service manual
Follett HCE1400A Operation And Service Manual

Follett HCE1400A Operation And Service Manual

Hce/hme1400a, hce/hme1400w 50hz ice machines
Hide thumbs Also See for HCE1400A:
Table of Contents

Advertisement

Quick Links

Download this manual
Order parts online
www.follettice.com
Following installation, please forward this manual
HCE/HME1400A, HCE/HME1400W
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
50Hz Ice Machines
Operation and Service Manual
After Serial Number C37309
00186924R12

Advertisement

Table of Contents
loading

Related Manuals for Follett HCE1400A

Summary of Contents for Follett HCE1400A

  • Page 1 HCE/HME1400A, HCE/HME1400W 50Hz Ice Machines Order parts online Operation and Service Manual www.follettice.com After Serial Number C37309 Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 www.follettice.com 00186924R12...

  • Page 3: Table Of Contents

    Table of contents Welcome to Follett Corporation Specifi cations Operation Cleaning Weekly exterior care Monthly condenser cleaning Semi-annual evaporator cleaning Service Ice machine operation Water system Electrical system Normal control board operation Test points Error faults Hard error Soft errors Relay output indication Compressor/refrigerant solenoid output Wiring diagram...

  • Page 4: Welcome To Follett Corporation

    Welcome to Follett Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding after-the-sale support. To ensure that this equipment delivers the same degree of service, we ask that you review the installation manual (provided as a separate document) before beginning to install the unit. Our instructions are designed to help you achieve a trouble-free installation.

  • Page 5: Specifi Cations

    Specifi cations Electrical Each ice machine requires its own separate circuit with electrical disconnect within 10 ft (6m). Equipment ground required. Standard electrical – 220-240/50/1 Maximum ice machine fuse – 20 amps Amperage – 16 amps Maximum power – 5280 watts Climatic class –...
  • Page 6 Dimensions and clearances Entire front of ice machine must be clear of obstructions/connections to allow removal. 1" (26mm) clearance above ice machine for service. 1" (26mm) minimum clearance on sides. The intake and exhaust air grilles must provide at least 170 sq in (1098 sq cm) of open area. Air-cooled model ice machines –...

  • Page 7: Operation

    Operation Cleaning and preventive maintenance (all models) Note: Do not use bleach to sanitize or clean the ice machine. Preventive maintenance Periodic cleaning of Follett’s ice machine system is required to ensure peak performance and delivery of clean, sanitary ice. The recommended cleaning procedures that follow should be performed at least as frequently as recommended, and more often if environmental conditions dictate.
  • Page 8 Fig. 2 2. Mix 1 gallon (3.8L) 120 F (49 C) water and 7 ounces (198g) (one 7 ounce packet of Follett SafeCLEAN ice machine cleaner, part# 00132001). Locate cleaning cup. Fill until HI WATER light HI WATER comes on (Fig. 2). Note: Do not use bleach to sanitize or clean the ice machine.
  • Page 9 Fig. 5 5. Mix 1 gallon 120 F (49 C) water and 1.6 ounces (48ml) NU-CALGON IMS-II SANITIZER. Fill until HI WATER light comes on (Fig. 5). Note: Do not use bleach to sanitize or clean the ice machine. HI WATER Fig.
  • Page 10 Fig. 8 8. Disconnect coupling as shown (Fig. 8). Fig. 9 9. Using disposable food service grade gloves, insert dry Sani-Sponge (kit part# 00132068). ™ Next, insert Sani-Sponge soaked in Nu-Calgon IMS-II sanitizer solution. Push both Sani-Sponges down ice transport tube with supplied pusher tube (Fig.
  • Page 11 Fig. 11 11. Reconnect coupling. Press power switch ON. Ice pushes Sani-Sponges through tube (Fig. 11). Fig. 12 12. Place a sanitary (2 gallon or larger) container in bin or dispenser to collect Sani-Sponges and ice for 10 minutes. Collect 5.5 lbs (3kg) of ice from unit.

  • Page 12: Service

    Service Ice machine operation (all models) Follett’s ice machine consists of fi ve distinct functional systems covered in detail as follows: • Water system • Electrical control system • Mechanical assembly • Refrigeration system • Bin full The Horizon ice machine overview The Follett Horizon ice machine uses a horizontal, cylindrical evaporator to freeze water on its inner surface.

  • Page 13: Water System

    Water system The water level in the evaporator is controlled by a feed solenoid and level detecting sensors. Referencing the diagram below, water sensing rods extend down into the reservoir at the end of the evaporator assembly. The system works via electrical conductivity as follows: One of the longest probes is a common.

  • Page 14: Electrical System

    Electrical system Normal control board operation The PC board indicator lights provide all the information necessary to determine the machine's status. Green indicator lights generally represent “go” or normal operation; Yellow indicators represent normal off conditions; Red indicators generally represent alarm conditions, some of which will lock the machine off. A green light labeled POWER indicates power to the machine.

  • Page 15: Test Points

    Test points: The Horizon PC board incorporates on-board test points that can be used to determine various electrical outputs. The test point holes allow a standard probe to be inserted for quick voltage measurement. For 208-230 systems, use TP-4 (L2) as the common for testing outputs for solenoids, motors, etc. Error faults: The Horizon PC board monitors various operating parameters including high pressure, auger gearmotor amperage limits, clogged drain, and high and low water alarm conditions.

  • Page 16: Wiring Diagram

    Wiring diagram SNUBBER POWER (G) LOW BIN (G) AUGER ON (G) REFRIG ON (G) TIME DELAY (Y) CLEANING (Y) PURGE (Y) SERVICE (R) HI AMPS (R) HI PRESS (R) CONTROL BOARD DRAIN CLOG (R) HI WATER (R) LO WATER (R) CPU (G)

  • Page 17: Compressor Data

    Compressor data Compressor current draw Air-cooled Ambient air temp. 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C 100 F/38 C 6.9A 6.9A 7.0A 7.3A 7.9A Water-cooled Condenser water temp 50 F/10 C 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C 7.4A...

  • Page 18: Mechanical System

    Mechanical system Fig. 13 Evaporator disassembly Press PURGE button to purge evaporator, and then turn power OFF. 2. Unscrew and remove stream divider as shown. Fig. 14 3. Unplug and remove gearmotor as shown. 4. Remove all traces of petrol-gel from the auger shaft. Fig.
  • Page 19 Fig. 16 8. Loosen nut on V-band clamp and remove. 9. Remove V-band clamp from front of evaporator. 10. Remove main housing as shown. Fig. 17 11. Remove and discard mating ring and seal. 12. Carefully remove auger.

  • Page 20: Evaporator Reassembly

    Fig. 18 Evaporator reassembly Remove and inspect O ring seal. Discard if damaged in any way. 2. Clean O ring groove. Lubricate O ring with petrol-gel and reinstall. Fig. 19 3. Press new mating ring into main housing as shown. 4.
  • Page 21 Fig. 21 6. Orient auger shaft with keyway in the Note: Shuttle housing upward position. removed for clarity Force main housing into position against evaporator and place 1/4" (7mm) diameter Phillips screwdriver into hole in the auger shaft. 8. Replace V-band clamp as shown. 9.
  • Page 22 Fig. 24 17. Insert a bolt into the auger shaft and fi nger tighten. 18. Using a wrench, rotate the shaft clockwise to align the keyways in the gear housing and the shaft so as to accept the key. 19. Insert the key into the keyway. Fig.

  • Page 23: Refrigeration System

    Refrigeration system Refrigerant pressure data Air temperature Air-cooled condensers 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C 100 F/38 C Pressure 208/26psi 238/28psi 270/30psi 306/33psi 346/36psi discharge/suction 1435/180kPa 1641/194kPa 1862/207kPa 2110/228kPa 2386/249kPa 14.35/1.80bar 16.41/19.4bar 18.62/2.07bar 21.10/2.28bar 23.86/2.49bar Water temperature Water-cooled condensers...

  • Page 24: Refrigerant Charge Size

    Refrigeration charge All service on refrigeration systems must be performed in accordance with all federal, state and local laws. It is the responsibility of the technician to ensure that these requirements are met. Recharging ice machine to other than factory specifi cations will void the warranty. R404A ice machine charge specifi cations Model Charge...

  • Page 25: "Bin Full" Detection System

    “Bin full” detection system The Follett Horizon ice machine incorporates a unique “bin full” detection system that consists of the shuttle and actuator. The shuttle incorporates a fl ag and sensor. Referencing the fi gure below, the normal running position of the fl ag is down, out of the sensor.

  • Page 26: Troubleshooting

    Troubleshooting Please see “Service” section for a description of each function. Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING Ice machine is in running 1. Defective compressor. 1. Replace compressor. 2. Defective start relay. 2. Replace start relay. condition but not making ice.
  • Page 27 Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING 6. Ice machine is not making ice. 1. High ambient temperatures 1. Air condition area to below HI PRESSURE. >100 F (38 C). 100 F (38 C). 2. Poor ventilation or air 2.

  • Page 28: Replacement Parts

    Replacement parts Order parts online www.follettice.com Evaporator assembly...
  • Page 29 Order parts online www.follettice.com Reference # Description Part # Tube, ice transport, molded 00175299 Shuttle assembly (includes gasket and nozzle) 00130815 Switch, optical 00130849 Compression nozzle 00115774 Elbow, water 00134502 Gasket, shuttle 00115600 Stream divider 00142521 Auger bolt 00116988 Washer 00161513 Retainer, auger bolt 00161356...
  • Page 30 Air-cooled assembly Order parts online www.follettice.com...
  • Page 31 Order parts online www.follettice.com Reference # Description Part # Condenser (includes 00130922) 00137588 Shroud, condenser 00137596 Fan motor assembly 00121566 Electrical box support 00153635 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 00134593 Valve, expansion, thermal (includes 502830 and 00106534) 00136317 Insulation, TXV 502830...
  • Page 32 Water-cooled assembly Order parts online www.follettice.com...
  • Page 33 Order parts online www.follettice.com Reference # Description Part # Electrical box support 00153635 Elbow, water 00129486 Valve, water regulating 00131052 Union, water 202148 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 00134593 Valve, expansion, thermal (includes 502830 and 00106534) 00130997 Insulation, TXV 502830...
  • Page 34 Electrical box Order parts online www.follettice.com...
  • Page 35 Order parts online www.follettice.com Reference # Description Part # Cover, electrical box, air/water-cooled 00130872 Board, control circuit, 240V (includes 00130906) 00132902 Stand off’s (set of 6) 00130906 Capacitor, compressor run 00133512 Clamp, run capacitor 00133603 Relay, compressor starting (includes wire harness) 00161810 Contactor 00917195...
  • Page 36 Integration kit – top-mount and RIDE remote ice delivery equipment Order parts online www.follettice.com Top mount configuration RIDE model configuration...
  • Page 37 Order parts online www.follettice.com Reference # Description Part # Shuttle actuator 00171322 Clamp 500377 Actuator elbow (includes 00167122 and 209100) 00171264 Screws 209100 Gasket 00167122 Actuator body 00171272 Gasket, coupling 00126532 Ring, locking (includes 00126532) 00171371 Ice transport tube, 10' (3m) 00171280 Ice transport tube, 20' (6m) 00171298...
  • Page 38 Skins assembly Order parts online www.follettice.com ni a sy lva n Pe SI NG TI O O RA M AL SI DE R TH E US M PR M OT SI DE N PR SI G . BR 208264 Stock Module Identification Plate Module No.
  • Page 39 Order parts online www.follettice.com Reference # Description Part # Grille, intake 00122846 Front cover, air- & water-cooled (includes 00122846) 00137612 Tubing, water, 3/8" OD 502719 Tubing, drain 00144923 Fitting, drain 00109728 Fitting, water inlet 502924 Elbow, water inlet 502925 Coupling (includes 00144675) 00171207 O ring 00144675...
  • Page 40 Horizon, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge and Vision are trademarks of Follett Corporation. Chewblet , RIDE and Follett are registered trademarks of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00186924R12 www.follettice.com © Follet Corporation 11/13...
