HCC1000ABT, HMC1000ABT, HCC1400ABT, HMC1400ABT,
HCC1000WBT, HMC1000WBT, HCC1400WBT, HMC1400WBT
HCE1000ABT, HME1000ABT, HCE1400ABT, HME14000ABT,
HCE1000WBT, HME1000WBT, HCE1400WBT, HME1400WBT
(See model number confi gurator on page 2 for details.)
Order parts online
www.follettice.com
™
Horizon
Icemaker Installation Instructions
for Ice Storage Bin Top-mount Applications
Stock Module Identification Plate
Module No.
Product
Service No.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
208264
self-contained
00182212R03
Advertisement
Table of Contents
Related Manuals for Follett Horizon HME14000ABT
Summary of Contents for Follett Horizon HME14000ABT
- Page 1 ™ Horizon Icemaker Installation Instructions for Ice Storage Bin Top-mount Applications HCC1000ABT, HMC1000ABT, HCC1400ABT, HMC1400ABT, HCC1000WBT, HMC1000WBT, HCC1400WBT, HMC1400WBT HCE1000ABT, HME1000ABT, HCE1400ABT, HME14000ABT, HCE1000WBT, HME1000WBT, HCE1400WBT, HME1400WBT (See model number confi gurator on page 2 for details.) Order parts online www.follettice.com self-contained Stock Module Identification Plate...
- Page 2 † Ice Manager Diverter Valve Systems can be used to fill any two of these bins or dispensers with a single ice machine. Chewblet is a registered trademark of Follett Corporation, registered in the US. BIN • TOP-MOUNT self-contained...
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Bin preparation Louvered docking assembly Ice transport tube External connection Internal connection Front cover BIN • TOP-MOUNT self-contained...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett icemaker. Unpack icemaker ➊ ➋ ➌ ➍ 1/2" 1/2" ➎ ➏ BIN • TOP-MOUNT self-contained...
-
Page 5: Site Preparation
Potable water supply • 10-70 psi (69-483kpa) • 45 F to 90 F (7 C to 32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) ➌ Condenser water supply for water-cooled systems • 10 psi min.; 150 psi max. (69kpa min.; 1034kpa max.) •... - Page 6 Bin preparation Prepare the bin. Bin top preparation Bin top preparation ➋ ➊ ➌ ➊ ➊ • Remove protective tape from • Apply gaskets gaskets ➋ • Install shuttle actuator through dispenser top and secure with locking ➌ BIN • TOP-MOUNT self-contained...
- Page 7 Louvered docking assembly Install the louvered docking assembly. WARNING • Docking station must be secured in accordance with these instructions to ensure icemaker stability. • Ventilation openings in the louvered docking station should be clear of obstruction Louvered docking assembly •...
-
Page 8: Ice Transport Tube
Ice transport tube Install the ice transport tube. ➋ Hot Water 160 F (71 C) ➊ ➌ • Install supplied ice transport tube insulation ➊ • Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers before making connection to ease assembly ➋... -
Page 9: External Connections
External connections Connect utilities to louvered docking assembly. Air-cooled icemakers only Water-cooled icemakers only ➌ ➋ ➍ ➋ ➊ ➊ • Remove access panel if necessary • Remove access panel if necessary ➊ ➊. • Install drain line • Install drain line The rigid drain line from the icemaker The rigid drain line from the icemaker must have at least 1/4"... -
Page 10: Internal Connections
Internal connections Connect icemaker to louvered docking assembly. CAUTION • Plug must be accessible after fi nal installation. • HCE1400A/W 230/50/1) requires a 20 amp circuit (4.00 mm wire) Air-cooled icemakers – follow steps 7.1 through 7.4. Ice transport tube Potable water and drain lines ➊... - Page 11 Water-cooled icemakers – follow steps 7.5 through 7.10. Cooling lines Ice transport tube ➋ ➊ • Install icemaker cooling water lines to • Slide icemaker into louvered docking ➊ louvered docking assembly assembly • Insert ice transport tube into coupling ➋...
- Page 12 7.10 Power cord Power cord • Remove twist tie • Position plate into opening and secure with supplied screw • Carefully pass plug thru opening and plug into wall outlet BIN • TOP-MOUNT self-contained...
-
Page 13: Front Cover
Front cover Install front cover to icemaker. Install front cover ➋ ➊ • Slide icemaker cover over machine ensuring that tabs on back of cover slip under louvers on back of louvered ➊ docking assembly • Insert and tighten two screws through cover and into louvered docking ➋... - Page 14 BIN • TOP-MOUNT self-contained...
- Page 15 BIN • TOP-MOUNT self-contained...
- Page 16 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00182212R03 www.follettice.com 01/11...
