Page 1: Gas Cooktops
Gas Cooktops M o d e l s : C 6 ( 6 0 0 m m ) C 9 ( 9 0 0 m m ) I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L For use in GB &... - Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL BRANCHES AUSTRALIA Moffat Pty Limited E.Mail: vsales@moffat.com.au Main Office: (tel) (03) 9518 3888 (fax) (03 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281 CANADA Serve Canada...
-
Page 3: Table Of Contents
Contents C6 Gas Cooktops 600 mm Wide. C9 Gas Cooktops 900 mm Wide. Part 1 Introduction ..................2 Part 2 Specifications .................. 3 Part 3 Installation ..................5 Part 4 Operation ..................8 Part 5 Cleaning and Maintenance ............10 Part 6 Gas Conversion ................ -
Page 4: Part 1 Introduction
Part 1 Introduction We are confident that you will be delighted with your Cobra Series Cooktop, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Cobra Series Appliance, there are two important things you can do. -
Page 5: Part 2 Specifications
Part 2 Specifications Model Covered in this Specification - NOTE: (*) - The burner operating pressure is to be measured C6D [1] Cooktop 4 Open Burners. at the manifold test point with two burners C6C [1] Cooktop 2 Burners + 300 mm Griddle. operating at full setting. - Page 6 Part 2 Specifications Dimensions C6 - Gas Cooktop - 600 mm Wide. C6D Model C6C Model C6B Model C9 - Gas Cooktop - 900 mm Wide. C9D Model C9C Model C9B Model C9A Model...
-
Page 7: Part 3 Installation
Cobra Series Cooktops are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. -
Page 8: Gas Connection
ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED SERVICE PERSON. NOTE: A Manual Isolation Valve must be fitted to the 1. Cobra Series Cooktops do not require an individual appliance supply line. electrical connection, they function totally on the gas supply only. - Page 9 Part 3 Installation Commissioning The following commissioning checks must be carried out before the appliance is handed over for use, to ensure that the unit operates correctly and the operator(s) understand the correct operating procedure. 1. Before leaving the new installation; a.
-
Page 10: Part 4 Operation
(e.g. paint sealed) manufacturer should not be adjusted by the user / operator. 1. Cobra appliances have been designed to provide simplicity of operation and 100% safety protection. 2. Improper operation is therefore almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product. - Page 11 Part 4 Operation Open Burners Griddle NOTE: AUTI ON Only cooking pans from size Ø 150 mm to Ø 420 mm are suitable fo use on these open burners. The griddle plate temperature reaches over 300°C hottest points during normal Lighting the Open Burners operation at 'Full Flame' setting.
-
Page 12: Part 5 Cleaning And Maintenance
Part 5 Cleaning and Maintenance 2. Always ensure that the scraper tool blades are General changed regularly to ensure that the scraper tool works efficiently and prevents damage to AUTI ON the griddle plate surface. Always turn off the gas supply at the mains 3. - Page 13 Part 5 Cleaning and Maintenance Cooktop Cooking Area Trivets and Burners a. Remove the trivets from the top of the a. Clean the Cooktop cooking area using a soft appliance, taking note that the trivets are cloth moistened with a mild detergent and hot manufactured with a lip on one edge, the lip water solution.
-
Page 14: Periodic Maintenance
Part 5 Cleaning and Maintenance Re-Fitting the Components to the Cooktop Gas Control Valve Re-Greasing a. Refit the trivet supports to the Cooktop, ensuring The gas control valve should be dismantled and that the trivet supports are correctly fitted. greased every 6 months to ensure the correct operation of the gas control valve. -
Page 15: Part 6 Gas Conversion
Part 6 Gas Conversion Gas Conversion Procedure 4. Remove all the trivet supports from the top of the appliance. Take note AUTI ON the orientation of the trivet supports when Ensure that the unit is isolated from the gas Front removing. - Page 16 Part 6 Gas Conversion Aeration Adjustment 5. Remove and replace the main burner injector with correct size injector. Refer to the ‘Gas 1. Check / adjust the main burner aeration gap. Specifications’ table at the end of this section, This gap should be set to the dimensions shown for correct injector sizes.
-
Page 17: Gas Regulator
Part 6 Gas Conversion Gas Regulator NOTE: The regulator supplied is convertible between Natural Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. NOTE, Pin rotated for Natural Gas NOTE, Pin rotated for LPG 1. -
Page 18: Gas Specifications
Part 6 Gas Conversion Gas Specifications - Non-UK Only Natural. Gas LP Gas (Propane) Burner Injector Ø 2.10 mm Ø 1.30 mm ¾ turn open ¼ turn open Open Burner Low Fire Setting c.c.w. c.c.w. Burner Aeration Setting 16 mm open. 16 mm open. -
Page 19: Part 7 Replacement Parts List
Grease Tray (1 per 300 mm Griddle Section). 230059 Griddle Plate 300 mm. 230084 Griddle Plate 600 mm. 230091 Griddle Plate 900 mm. General 230138 Drip Tray C6. 230139 Drip Tray C9. 229674 Rear Roller Assy. 234059 Leg Assy (150 mm). - Page 20 Part 7 Replacement Parts List Regulator 228531 Regulator (Natural Gas/LP Gas [Propane] Convertible) ¾” BSP F/F. Gas Conversion Kits - Non UK Only: Gas Type to Convert to Model LPG (Propane) Nat. Gas 231567 231566 231570 231569 - UK Only: Gas Type to Convert to Model Propane (G31)
