Page 1 M5163dn User's Guide April 2014 www.lexmark.com Machine type(s): 4063 Model(s):...
Page 2: Table Of Contents
Contents Contents Safety information..................5 Learning about the printer................7 Finding information about the printer......................7 Selecting a location for the printer......................8 Printer configurations..........................9 Using the printer control panel.......................11 Understanding the colors of the Sleep button and indicator lights............12 Additional printer setup................13 Installing internal options........................13 Installing hardware options........................30 Attaching cables............................34 Setting up the printer software.......................36...
Page 3 Contents Canceling a print job..........................78 Understanding the printer menus..............79 Menus list..............................79 Paper menu.............................80 Reports menu............................91 Network/Ports menu..........................92 Security menu............................104 Settings menu............................107 Help menu.............................131 Saving money and the environment............133 Saving paper and toner.........................133 Saving energy............................134 Recycling..............................136 Securing the printer..................138 Using the security lock feature......................138 Statement of Volatility..........................138 Erasing volatile memory........................139 Erasing non‑volatile memory........................139...
Page 4 Contents Restoring factory default settings......................157 Clearing jams....................158 Avoiding jams............................158 Understanding jam messages and locations..................160 [x]‑page jam, lift front cover to remove cartridge [200–201]...............162 [x]‑page jam, open upper rear door [202]....................165 [x]‑page jam, open upper and lower rear door [231–234]..............166 [x]‑page jam, remove standard bin jam [203]..................168 [x]‑page jam, remove tray 1 to clear duplex [235–239]................169 [x]‑page jam, open tray [x] [24x]......................170 [x]‑page jam, clear manual feeder [250]....................171...
Page 5: Safety Information
Safety information Safety information Connect the power cord directly to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible. CAUTION—POTENTIAL INJURY: Do not use this product with extension cords, multioutlet power strips, multioutlet extenders, or other types of surge or UPS devices. The power rating capacity of these types of accessories can be easily overloaded by a laser printer and may result in poor printer performance, property damage, or potential fire.
Page 6 CAUTION—TIPPING HAZARD: Floor-mounted configurations require additional furniture for stability. You must use either a printer stand or printer base if you are using multiple input options. If you purchased a printer with a similar configuration, then you may need additional furniture. For more information, see www.lexmark.com/multifunctionprinters. SAVE THESE INSTRUCTIONS.
Page 7: Learning About The Printer
Initial setup instructions: Setup documentation—The setup documentation came with the printer and is also available at • Connecting the printer http://support.lexmark.com. • Installing the printer software Additional setup and instructions for using the printer: User's Guide and Quick Reference Guide—The guides are available on the Documentation CD.
Page 8: Selecting A Location For The Printer
Learning about the printer What are you looking for? Find it here The latest supplemental information, updates, and customer Lexmark Support Web site— support: http://support.lexmark.com • Documentation Note: Select your country or region, and then select your product to view the appropriate support site.
Page 9: Printer Configurations
Learning about the printer Right side 152 mm (6 in.) Front 508 mm (20 in.) Left side 152 mm (6 in.) Rear 152 mm (6 in.) 115 mm (4.5 in.) Printer configurations Basic model Standard bin Printer control panel Multipurpose feeder Standard 550‑sheet tray (Tray 1)
Page 10: Fully Configured Model
For more information, see www.lexmark.com/multifunctionprinters. The following illustration shows the maximum number of optional finishers and trays that are supported by the printer. For more information on other configurations, visit www.lexmark.com/multifunctionprinters. Hardware option Alternative hardware option Staple finisher •...
Page 11: Using The Printer Control Panel
Learning about the printer The staple, hole punch finisher must not be combined with any other output options. In a configuration with two or more optional finishers: • The staple finisher must always be on top. • The high‑capacity output expander must always be at the bottom. •...
Page 12: Understanding The Colors Of The Sleep Button And Indicator Lights
Learning about the printer Use the Back button Return to the previous screen. Home button Go to the home screen. Indicator light Check the status of the printer. USB port Connect a flash drive to the printer. Note: Only the front USB port supports flash drives. Understanding the colors of the Sleep button and indicator lights The colors of the Sleep button and indicator lights on the printer control panel signify a certain printer status or condition.
Page 13: Additional Printer Setup
Firmware cards – Forms and Bar Code – PRESCRIBE – IPDS • Printer hard disk • Lexmark Internal Solutions Ports (ISP) – Parallel 1284-B interface – MarkNet N8350 802.11 b/g/n wireless printer server – RS-232-C serial interface Accessing the controller board...
Page 14 Additional printer setup CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn them off as well, and unplug any cables going into the printer.
Page 15 Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer first before touching any controller board electronic component or connector. Lexmark Internal Solutions Port or printer hard disk connector Option card connector Memory card connector...
Page 16 Additional printer setup Align the screws with the holes on the shield, and then reattach the shield. Tighten the screws on the shield.
Page 17: Installing A Memory Card
Additional printer setup Reattach the access cover. Installing a memory card CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing.
Page 18: Installing An Internal Solutions Port
Reattach the controller board shield, and then the controller board access cover. Installing an Internal Solutions Port The controller board supports one optional Lexmark Internal Solutions Port (ISP). Note: This task requires a flat‑head screwdriver. CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing.
Page 19 Additional printer setup Unpack the ISP kit. ISP solution Screw for attaching the plastic bracket to the ISP Screws for attaching the ISP mounting bracket to the controller board shield Plastic bracket Remove the metal cover from the ISP opening. Loosen the screw.
Page 20 Additional printer setup Align the posts of the plastic bracket with the holes on the controller board cage, and then press the plastic bracket on the controller board cage until it clicks into place. Make sure the cables are neatly tucked under the plastic bracket.
Page 21 Additional printer setup Lower the ISP toward the plastic bracket until the ISP is seated between the guides of the plastic bracket. Use the provided thumbscrew for the ISP to attach the plastic bracket to the ISP. Note: Turn the screw clockwise, enough to hold the ISP in place, but do not tighten it yet.
Page 22 Additional printer setup Attach the two provided screws to secure the ISP mounting bracket to the controller board shield. Tighten the thumbscrew that is attached to the ISP. Warning—Potential Damage: Do not screw it on too tightly. Connect the ISP solution interface cable into the receptacle of the controller board. Note: The plugs and receptacles are color-coded.
Page 23: Installing An Optional Card
Additional printer setup Installing an optional card CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing. If you have other devices attached to the printer, then turn them off as well, and unplug any cables going into the printer.
Page 24: Installing A Printer Hard Disk
Additional printer setup Note: The entire length of the connector on the card must touch and be flushed against the controller board. Close the controller board access door. Note: When the printer software and any hardware options are installed, it may be necessary to manually add the options in the printer driver to make them available for print jobs.
Page 25 Additional printer setup Locate the appropriate connector on the controller board cage. Note: If an optional ISP is currently installed, then the printer hard disk must be installed onto the ISP.
Page 26 Additional printer setup To install a printer hard disk onto the ISP: Remove the screws attached to the printer hard disk mounting bracket, and then remove the bracket. Align the standoffs of the printer hard disk to the holes in the ISP, and then press the printer hard disk down until the standoffs are in place.
Page 27 Additional printer setup Align the standoffs of the printer hard disk to the holes in the controller board cage, and then press the printer hard disk down until the standoffs are in place. Installation warning: Hold only the edges of the printed circuit board assembly. Do not touch or press on the center of the printer hard disk.
Page 28: Removing A Printer Hard Disk
Additional printer setup Removing a printer hard disk Note: This task requires a flat‑head screwdriver. CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing.
Page 29 Additional printer setup Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board electronic components or connectors. Access the controller board. For more information, see “Accessing the controller board” on page Unplug the printer hard disk interface cable from the controller board, leaving the cable attached to the printer hard disk.
Page 30: Installing Hardware Options
If you purchased a printer with a similar configuration, then you may need additional furniture. For more information, see www.lexmark.com/multifunctionprinters. Install the printer and any hardware options you have purchased in the following order: •...
Page 31: Installing Optional Trays
If you purchased a printer with a similar configuration, then you may need additional furniture. For more information, see www.lexmark.com/multifunctionprinters. Turn off the printer using the power switch, and then unplug the power cord from the electrical outlet.
Page 32 Additional printer setup Align the printer with the tray, and then slowly lower the printer into place. Note: Optional trays lock together when stacked.
Page 33 Additional printer setup Connect the power cord to the printer, then to a properly grounded electrical outlet, and then turn on the printer.
Page 34: Attaching Cables
Additional printer setup Note: When the printer software and any optional trays are installed, you may need to manually add the options in the printer driver to make them available for print jobs. For more information, see “Adding available options in the print driver” on page To uninstall the optional trays, slide the latch on the right side of the printer toward the front of the printer until it clicks into place, and then remove stacked trays one at a time from the top to the bottom.
Page 35 Additional printer setup Use the Parallel port Connect the printer to a computer. Note: This can also be used in installing an optional Internal Solutions Port (ISP). USB port Attach an optional wireless network adapter. Ethernet port Connect the printer to a network. USB printer port Connect the printer to a computer.
Page 36: Setting Up The Printer Software
Additional printer setup Setting up the printer software Installing the printer Obtain a copy of the software installer package. Run the installer, and then follow the instructions on the computer screen. For Macintosh users, add the printer. Note: Obtain the printer IP address from the TCP/IP section in the Network/Ports menu. Adding available options in the print driver For Windows users Open the printers folder.
Page 37: Networking
Additional printer setup In Windows 7 or earlier Click , or click Start and then click Run. Type control printers. Press Enter, or click OK. Select the printer you want to update, and then do either of the following: • For Windows 7 or later, select Printer properties.
Page 38: Preparing To Set Up The Printer On A Wireless Network
Additional printer setup Preparing to set up the printer on a wireless network Notes: • Make sure your wireless network adapter is installed in your printer and working properly. For more information, see the instruction sheet that came with the wireless network adapter. •...
Page 39: Connecting The Printer Using The Wireless Setup Wizard
Additional printer setup Connecting the printer using the Wireless Setup Wizard Before you begin, make sure that: • A wireless network adapter is installed in the printer and is working properly. For more information, see the instruction sheet that came with the wireless network adapter. •...
Page 40: Connecting The Printer To A Wireless Network Using The Embedded Web Server
Additional printer setup Using the Personal Identification Number (PIN) method From the printer control panel, navigate to: > Settings > >Network/Ports > > Network [x] > > Network [x] Setup > > Wireless > > Wireless Connection Setup > > Wi‑Fi Protected Setup > >...
Page 41: Verifying Printer Setup
Additional printer setup Changing port settings after installing a new network ISP Notes: • If the printer has a static IP address, then you do not need to make any changes. • If the computers are configured to use the network name, instead of an IP address, then you do not need to make any changes.
Page 42: Printing A Network Setup Page
Additional printer setup Note: If you have not changed any menu settings, then the menu settings page lists all the factory default settings. When you select and save other settings from the menus, they replace the factory default settings as user default settings.
Page 43: Loading Paper And Specialty Media
If you regularly print large jobs on narrow paper, then you may use the MS710 Series printer models, which print batches of 10 or more pages of narrow paper at a faster speed. For more information on the MS710 Series printer models, contact your Lexmark sales representative. From the printer control panel, navigate to: >...
Page 44 Loading paper and specialty media Notes: • When loading folio‑, legal‑, or Oficio‑size paper, lift the tray slightly and pull it out completely. • Avoid removing trays while a job prints or while Busy appears on the display. Doing so may cause a jam. Squeeze and slide the width guide to the correct position for the size of the paper being loaded until it clicks into place.
Page 45 Loading paper and specialty media Unlock the length guide, and then squeeze and slide the guide to the correct position for the size of the paper being loaded. Notes: • Lock the length guide for all paper sizes. • Use the paper size indicators at the bottom of the tray to help position the guides.
Page 46 Loading paper and specialty media Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. Load the paper stack with the printable side facedown. Note: Make sure the paper or envelope is loaded properly.
Page 47 Loading paper and specialty media Without an optional staple finisher With an optional staple finisher Two‑sided printing Two‑sided printing • If you are loading prepunched paper for use with the staple finisher, then make sure the holes on the long edge of the paper are on the right side of the tray.
Page 48 Loading paper and specialty media • If you are loading envelopes, then make sure that the flap side is facing up and the envelopes are on the left side of the tray. • Make sure the paper is below the solid line, which is the maximum paper fill indicator. Warning—Potential Damage: Overfilling the tray can cause paper jams.
Page 49 Loading paper and specialty media • When using card stock, labels, or other types of specialty media, make sure the paper is below the dashed line, which is the alternate paper fill indicator. For custom‑ or Universal‑size paper, adjust the paper guides to lightly touch the sides of the stack, and then lock the length guide.
Page 50: Loading The 2100-Sheet Tray
Loading paper and specialty media Loading the 2100‑sheet tray CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed. Pull out the tray. Adjust the width and length guides. Loading A5‑size paper Pull up and slide the width guide to the position for A5.
Page 51 Loading paper and specialty media Squeeze and slide the length guide to the position for A5 until it clicks into place. Remove the A5 length guide from its holder. Insert the A5 length guide into its designated slot. Note: Press the A5 length guide until it clicks into place.
Page 52 Loading paper and specialty media Loading A4‑, letter‑, legal‑, oficio‑, and folio‑size paper Pull up and slide the width guide to the correct position for the size of the paper being loaded. If the A5 length guide is still attached to the length guide, then remove it from its place. If the A5 length guide is not attached, then proceed to step d.
Page 53 Loading paper and specialty media Put the A5 length guide in its holder. Squeeze the length guide and slide it to the correct position for the size of the paper being loaded until it clicks into place.
Page 54 Loading paper and specialty media Flex and fan the sheets to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. Load the paper stack with the printable side facedown. Note: Make sure the paper is loaded properly.
Page 55 Loading paper and specialty media One‑sided printing Two‑sided printing Note: If the holes on the long edge of the paper are on the left side of the tray, then a jam may occur. • Make sure the paper is below the maximum paper fill indicator. Warning—Potential Damage: Overfilling the tray can cause paper jams.
Page 56: Loading The Multipurpose Feeder
Loading paper and specialty media From the printer control panel, set the size and type in the Paper menu to match the paper loaded in the tray. Note: Set the correct paper size and type to avoid paper jams and print quality problems. Loading the multipurpose feeder Pull down the multipurpose feeder door.
Page 57 Loading paper and specialty media Pull the multipurpose feeder extender. Note: Guide the extender gently so that the multipurpose feeder is fully extended and open. Slide the width guide to the correct position for the size of the paper being loaded. Note: Use the paper size indicators on the bottom of tray to help position the guides.
Page 58 Loading paper and specialty media Prepare the paper or specialty media for loading. • Flex sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. •...
Page 59 Loading paper and specialty media • There are different ways of loading letterhead depending on whether an optional staple finisher is installed or not. Without an optional staple finisher With an optional staple finisher One‑sided printing One‑sided printing Two‑sided printing Two‑sided printing •...
Page 60 Loading paper and specialty media • Load envelopes with the flap side down and on the left of the multipurpose feeder. Warning—Potential Damage: Never use envelopes with stamps, clasps, snaps, windows, coated linings, or self‑stick adhesives. These envelopes may severely damage the printer. •...
Page 61: Linking And Unlinking Trays
Loading paper and specialty media Linking and unlinking trays The printer links trays when the specified paper size and type are the same. When a linked tray becomes empty, paper feeds from the next linked tray. To prevent trays from linking, assign a unique custom paper type name. Linking and unlinking trays Open a Web browser, and then type the printer IP address in the address field.
Page 62: Assigning A Custom Paper Type
Loading paper and specialty media Using the printer control panel From the printer control panel, navigate to: > Settings > > Paper Menu > > Custom Names Select a custom name, and then type a new custom paper type name. Press Press Custom Types, and then verify if the new custom paper type name has replaced the custom name.
Page 63: Paper And Specialty Media Guide
The printer may print at a reduced speed to prevent damage to the fuser. • For more information on card stock and labels, see the Card Stock & Label Guide on the Lexmark support Web site at http://support.lexmark.com. Using specialty media Tips on using card stock Card stock is heavy, single‑ply specialty media.
Page 64: Paper Guidelines
• Print samples on labels being considered for use before buying large quantities. • For more information on label printing, characteristics, and design, see the Card Stock & Label Guide on the Lexmark Web site at http://support.lexmark.com. • Use labels designed specifically for laser printers.
Page 65: Moisture Content
Paper and specialty media guide Weight The printer trays and multipurpose feeder can automatically feed paper weights between 60–176 g/m (16–47‑lb) grain long paper. The 2100‑sheet tray can automatically feed paper weights up to 60–135 g/m (16–36‑lb) grain long paper. Paper lighter than 60 g/m (16 lb) might not be stiff enough to feed properly, and may cause jams.
Page 66: Selecting Preprinted Forms And Letterhead
Lexmark concerns itself with the responsible use of paper in general based on life cycle assessments of its products. To gain a better understanding of the impact of printers on the environment, the company commissioned a number of life cycle assessments and found that paper was identified as the primary contributor (up to 80%) of carbon emissions caused throughout the entire life of a device (from design to end-of-life).
Page 67: Storing Paper
In addition, the company encourages purchasing paper from suppliers who demonstrate their commitment to sustainable forestry practices. Lexmark does not endorse specific suppliers, although a converter’s product list for special applications is maintained. However, the following paper choice guidelines will help alleviate the environmental impact of printing: Minimize paper consumption.
Page 68: Supported Paper Sizes, Types, And Weights
Paper and specialty media guide Supported paper sizes, types, and weights The following tables provide information on standard and optional paper sources and the sizes, types, and weights of paper they support. Note: For an unlisted paper size, select the closest larger listed size. Paper types and weights supported by the printer The printer engine supports 60–176‑g/m (16–47‑lb) paper weights.
Page 69 Paper and specialty media guide Dimensions Standard or Optional Multipurpose Duplex Paper size optional 250‑ or 2100‑sheet tray feeder 550‑sheet tray JIS B5 182 x 257 mm (7.2 x 10.1 in.) Letter 216 x 279 mm (8.5 x 11 in.) Legal 216 x 356 mm (8.5 x 14 in.)
Page 70 Paper and specialty media guide Dimensions Standard or Optional Multipurpose Duplex Paper size optional 250‑ or 2100‑sheet tray feeder 550‑sheet tray Other Envelope 98 x 162 mm (3.9 x 6.4 in.) to 176 x 250 mm (6.9 x 9.8 in.) If your preferred default paper size cannot be set in the printer control panel, then you may select common paper sizes that correspond to the position of the length guide in the tray from the Paper Size/Type menu.
Page 71 Paper and specialty media guide Supported paper types and weights Paper type Paper weight 4‑bin mailbox Output expander Staple finisher Staple, hole punch and high‑capacity finisher output expander Plain Paper 90–176 g/m (24–47 lb bond) 60–90 g/m (16–24 lb bond) Card Stock 163 g/m (90 Ib index)
Page 72 Paper and specialty media guide Paper type Paper weight 4‑bin mailbox Output expander Staple finisher Staple, hole punch and high‑capacity finisher output expander Preprinted 90–176 g/m (24–47 lb bond) 60–90 g/m (16–24 lb bond) Colored Paper 90–176 g/m (24–47 lb bond) 60–90 g/m (16–24 lb bond) Light paper...
Page 73: Printing
Printing Printing Printing a document Printing a document From the Paper menu on the printer control panel, set the paper type and size to match the paper loaded. Send the print job: For Windows users With a document open, click File > Print. Click Properties, Preferences, Options, or Setup.
Page 74: Printing From A Flash Drive Or Mobile Device
Printing Using the printer control panel From the printer control panel, navigate to: > Settings > > Print Settings > > Quality Menu > > Toner Darkness Adjust the toner darkness, and then press Printing from a flash drive or mobile device Printing from a flash drive Notes: •...
Page 75: Supported Flash Drives And File Types
Printing From the printer control panel, select the document you want to print. Press the left or right arrow button to specify the number of copies for printing, and then press Notes: • Do not remove the flash drive from the USB port until the document has finished printing. •...
Page 76: Printing Confidential And Other Held Jobs
Printing Printing from a mobile device To download a compatible mobile printing application, visit www.lexmark.com/mobile. Note: Mobile printing applications may also be available from your mobile device manufacturer. Printing confidential and other held jobs Storing print jobs in the printer From the printer control panel, navigate to: >...
Page 77: Printing Information Pages
Printing Printing confidential and other held jobs Note: Confidential and Verify print jobs are automatically deleted from memory after printing. Repeat and Reserve jobs are held in the printer until you choose to delete them. For Windows users With a document open, click File > Print. Click Properties, Preferences, Options, or Setup.
Page 78: Canceling A Print Job
Printing Press Note: The PPDS fonts appear only when the PPDS data stream is activated. Printing a directory list From the printer control panel, navigate to: > Settings > Reports > > Print Directory > Note: The Print Directory menu item appears only when an optional flash memory or printer hard disk is installed. Canceling a print job Canceling a print job from the printer control panel From the printer control panel, press...
Page 79: Understanding The Printer Menus
Understanding the printer menus Understanding the printer menus Menus list Paper Menu Reports Network/Ports Default Source Menu Settings Page Active NIC Paper Size/Type Device Statistics Standard Network Configure MP Stapler Test Standard USB Substitute Size Network Setup Page Parallel [x] Paper Texture Profiles List Serial [x]...
Page 80: Paper Menu
Understanding the printer menus Paper menu Default Source menu Default Source Set a default paper source for all print jobs. Tray [x] Notes: Multipurpose Feeder • Tray 1 (standard tray) is the factory default setting. MP Feeder • From the Paper menu, set Configure MP to "Cassette" for Multipurpose Manual Paper Feeder or MP Feeder to appear as a menu setting.
Page 81 Understanding the printer menus Tray [x] Type Specify the paper type loaded in each tray. Plain Paper Notes: Card Stock • Plain Paper is the factory default setting for Tray 1. Custom Type [x] is Transparency the factory default setting for all other trays. Recycled •...
Page 82 Understanding the printer menus MP Feeder Type Specify the paper type loaded in the multipurpose feeder. Plain Paper Notes: Card Stock • Plain Paper is the factory default setting. Transparency • From the Paper menu, set Configure to “Cassette” for MP Feeder Type Recycled to appear as a menu.
Page 83: Configure Mp Menu
Understanding the printer menus Manual Envelope Size Specify the envelope size being manually loaded. 7 3/4 Envelope Note: 10 Envelope is the U.S. factory default setting. DL Envelope is the 9 Envelope international factory default setting. 10 Envelope DL Envelope C5 Envelope B5 Envelope Other Envelope...
Page 84: Paper Texture Menu
Understanding the printer menus Paper Texture menu Plain Texture Specify the relative texture of the plain paper loaded in a specific tray. Smooth Note: Normal is the factory default setting. Normal Rough Card Stock Texture Specify the relative texture of the card stock loaded in a specific tray. Smooth Notes: Normal...
Page 85: Paper Weight Menu
Understanding the printer menus Preprinted Texture Specify the relative texture of the preprinted paper loaded in a specific tray. Smooth Note: Normal is the factory default setting. Normal Rough Colored Texture Specify the relative texture of the colored paper loaded in a specific tray. Smooth Note: Normal is the factory default setting.
Page 86 Understanding the printer menus Labels Weight Specify the relative weight of the labels loaded. Light Note: Normal is the factory default setting. Normal Heavy Vinyl Labels Weight Specify the relative weight of the vinyl labels loaded. Light Note: Normal is the factory default setting. Normal Heavy Bond Weight...
Page 87: Paper Loading Menu
Understanding the printer menus Custom [x] Weight Specify the relative weight of the custom paper loaded. Light Notes: Normal • Normal is the factory default setting. Heavy • The options appear only when the custom type is supported. Paper Loading menu Card Stock Loading Determine and set two-sided printing for all print jobs with Card Stock as the paper type.
Page 88: Custom Types Menu
Understanding the printer menus Heavy Loading Determine and set two-sided printing for all print jobs with Heavy as the paper type. Duplex Rough/Cotton Loading Determine and set two-sided printing for all print jobs with Rough or Cotton as the paper type. Duplex Custom [x] Loading Determine and set two-sided printing for all print jobs with Custom [x]...
Page 89: Universal Setup Menu
Understanding the printer menus Universal Setup menu Units of Measure Identify the units of measure. Inches Notes: Millimeters • Inches is the U.S. factory default setting. • Millimeters is the international factory default setting. Portrait Width Set the portrait width. 3–14.17 inches Notes: 76–360 mm...
Page 90 Understanding the printer menus Configure Bins Specify configuration options for bins. Mailbox Notes: Link • Mailbox is the factory default setting. This setting Mail Overflow treats each bin as a separate mailbox. Link Optional • Link configures all available bins as one large bin. Type Assignment •...
Page 91: Reports Menu
Understanding the printer menus Reports menu Reports menu Menu Settings Page Print a report containing information about the paper loaded in trays, installed memory, total page count, alarms, timeouts, printer control panel language, TCP/IP address, status of supplies, status of the network connection, and other information.
Page 92: Network/Ports Menu
Understanding the printer menus Network/Ports menu Active NIC menu Active NIC Allow the printer to connect to a network. Auto Notes: [list of available network cards] • Auto is the factory default setting. • This menu item appears only if an optional network adapter is installed. Standard Network or Network [x] menu Note: Only active ports appear in this menu.
Page 93 Understanding the printer menus Network Buffer Set the size of the network input buffer. Auto Notes: 3KB to [maximum size allowed] • Auto is the factory default setting. • The value can be changed in 1KB increments. • The maximum size allowed depends on the amount of memory in the printer, the size of the other link buffers, and whether Resource Save is set to On or Off.
Page 94: Network Card Menu
Understanding the printer menus Network Card menu To access the menu, navigate to either of the following: • Network/Ports > Standard Network > Standard Network Setup > Network Card • Network/Ports > Network [x] > Network [x] Setup > Network Card View Card Status View the connection status of the wireless network adapter.
Page 95: Ipv6 Menu
Understanding the printer menus Enable RARP Specify the RARP address assignment setting. Note: Off is the factory default setting. Enable BOOTP Specify the BOOTP address assignment setting. Note: On is the factory default setting. Enable AutoIP Specify the Zero Configuration Networking setting. Note: Yes is the factory default setting.
Page 96: Wireless Menu
Understanding the printer menus Enable IPv6 Enable IPv6 in the printer. Note: On is the factory default setting. Auto Configuration Specify whether or not the wireless network adapter accepts the automatic IPv6 address configuration entries provided by a router. Note: On is the factory default setting. View Hostname Set the host name.
Page 97: Appletalk Menu
Understanding the printer menus Choose Network Select an available network for the printer to use. View Signal Quality View the quality of the wireless connection. View Security Mode View the encryption method for the wireless network. AppleTalk menu Note: This menu appears only in printer models that are connected to an Ethernet network or when an optional wireless network adapter is installed.
Page 98 Understanding the printer menus PS SmartSwitch Set the printer to automatically switch to PS emulation when a print job received through a USB port requires it, regardless of the default printer language. Notes: • On is the factory default setting. •...
Page 99 Understanding the printer menus ENA Address Set the network address information for an external print server. yyy.yyy.yyy.yyy Note: This menu is available only when the printer is attached to an external print server through the USB port. ENA Netmask Set the netmask information for an external print server. yyy.yyy.yyy.yyy Note: This menu is available only when the printer is attached to an external print server through the USB port.
Page 100 Understanding the printer menus Parallel Buffer Set the size of the parallel input buffer. Disabled Notes: Auto • Auto is the factory default setting. 3K to [maximum size allowed] • Disabled turns off job buffering. Any print jobs already buffered on the printer hard disk are printed before normal processing resumes.
Page 101 Understanding the printer menus Mac Binary PS Set the printer to process Macintosh binary PostScript print jobs. Notes: • Auto is the factory default setting. Auto • Off filters print jobs using the standard protocol. • On processes raw binary PostScript print jobs. ENA Address Set the network address information for an external print server.
Page 102 Understanding the printer menus NPA Mode Set the printer to perform the special processing required for bidirectional communication following the conventions defined by the NPA protocol. Notes: Auto • Auto is the factory default setting. Auto sets the printer to examine data, determine the format, and then processes it appropriately.
Page 103: Smtp Setup Menu
Understanding the printer menus Robust XON Determine whether the printer communicates availability to the computer. Notes: • Off is the factory default setting. • This menu item applies only to the serial port if Serial Protocol is set to XON/XOFF. Baud Specify the rate at which data can be received through the serial port.
Page 104: Security Menu
Understanding the printer menus SMTP Timeout Specify the amount of time in seconds before the server stops trying to send an e‑mail. 5–30 Note: 30 seconds is the factory default setting. Reply Address Specify a reply address of up to 128 characters in the e-mail sent by the printer.
Page 105 Understanding the printer menus Confidential Job Expiration Limit the amount of time a confidential print job stays in the printer before it is deleted. Notes: 1 hour • If the “Confidential Job Expiration” setting is changed while confidential print jobs 4 hours reside in the printer RAM or printer hard disk, then the expiration time for those print 24 hours...
Page 106: Security Audit Log Menu
Understanding the printer menus Automatic Method Mark all disk space used by a previous print job. This method does not permit the file system to reuse this space until it has been cleared. Single pass Multiple pass Notes: • “Single pass” is the factory default setting. •...
Page 107: Settings Menu
Understanding the printer menus Time Zone Select the time zone. [list of time zones] Note: GMT is the factory default setting. Automatically observe DST Set the printer to use the applicable daylight saving time (DST) start and end times associated with the printer Time Zone setting. Note: On is the factory default setting.
Page 108 Understanding the printer menus Show Supply Estimates Get an estimate on the status of supplies. Show estimates Notes: Do not show estimates • Show estimates displays the estimated supply status in pages on the control panel, printer Web page, and on the Menu Settings and the Device Statistics reports.
Page 109 Understanding the printer menus Keyboard Specify a language and custom key information for the control panel keyboard. The additional tabs enable access to accent marks Keyboard Type and symbols from the keypad on the control panel. English Francais Notes: Francais Canadien •...
Page 110 Understanding the printer menus Displayed Information Specify what is displayed on the upper left and right corners of the control panel. Left side For the Left side and Right side options, select from the following Right side options: None IP Address Hostname Contact Name Location...
Page 111 Understanding the printer menus Displayed Information (continued) Customize the displayed information for Paper Jam, Load Paper, and Service Errors. Paper Jam Select from the following options: Load Paper Display Service Errors Message to Display Default Alternate Default [text entry] Alternate [text entry] Notes: •...
Page 112 Understanding the printer menus Time Format Format the printer time. 12 hour A.M./P.M. Note: This menu appears only in touch‑screen printer models. 24 hour clock Screen Brightness Specify the brightness of the display. 20–100 Notes: • This menu appears only in touch‑screen printer models. •...
Page 113 Understanding the printer menus Location Specify the location of the printer. Notes: • This menu appears only in touch‑screen printer models. • The location will be stored on the Embedded Web Server. Alarms Set an alarm to sound when the printer requires user intervention. Alarm Control For each alarm type, select from the following options: Cartridge Alarm...
Page 114 Understanding the printer menus Timeouts Set the amount of time the printer waits before it enters Hibernate mode. Hibernate Timeout Disabled Notes: 20 minutes • When the Hibernate Timeout timer expires, the printer uses 1 hour Ethernet connection to check the value of Hibernate 2 hours Timeout on Connection.
Page 115 Understanding the printer menus Timeouts Set the amount of time the printer waits for user intervention before it holds jobs that require unavailable resources and Job Hold Timeout continues to print other jobs in the print queue. 5–255 sec Notes: •...
Page 116 Understanding the printer menus Print Recovery Let the printer successfully print a page that may not have printed otherwise. Page Protect Notes: • Off is the factory default setting. Off prints a partial page when there is not enough memory to print the whole page. •...
Page 117: Flash Drive Menu
Understanding the printer menus Export Configuration Package Export the printer configuration package to a flash drive. Export Note: The configuration package cannot be exported unless a flash drive is attached to the printer. Flash Drive Menu Print Settings menu Copies Specify a default number of copies for each print job.
Page 118 Understanding the printer menus Duplex Binding Define the way duplexed pages are bound and printed. Long Edge Notes: Short Edge • Long Edge assumes binding along the long edge of the page (left edge for portrait and top edge for landscape). This is the factory default setting. •...
Page 119: Print Settings
Understanding the printer menus Separator Sheets Specify if blank separator sheets are inserted. Notes: Between Copies • Off is the factory default setting. Between Jobs • Between Copies inserts a blank sheet between each copy of a print job if Between Pages Collate is set to On.
Page 120 Understanding the printer menus Print Area Set the logical and physical printable area. Normal Notes: Fit to Page • Normal is the factory default setting. When attempting to Whole Page print data in the non‑printable area defined by the Normal setting, the printer clips the image at the boundary.
Page 121: Finishing Menu
Understanding the printer menus Finishing menu Sides (Duplex) Specify whether two‑sided (duplex) printing is set as the default for all print jobs. 1 sided Notes: 2 sided • “1 sided” is the factory default setting. • You can set two‑sided printing from the printer software. For Windows users: Click File >...
Page 122 Understanding the printer menus Separator Source Specify the paper source for the separator sheet. Tray [x] Notes: Multipurpose Feeder • Tray 1 (standard tray) is the factory default setting. MP Feeder • From the Paper menu, set Configure MP to "Cassette" for Multipurpose Feeder or MP Feeder to appear as a menu setting.
Page 123: Quality Menu
Understanding the printer menus Hole Punch Mode Specify the number of holes to be created on printed outputs for the purpose of collecting the sheets in a binder or folder. 2 holes 3 holes Notes: 4 holes • “3 holes” is the U.S. factory default setting. “4 holes” is the international factory default setting.
Page 124: Job Accounting Menu
Understanding the printer menus Enhance Fine Lines Enable a print mode preferable for files such as architectural drawings, maps, electrical circuit diagrams, and flow charts. Notes: • Off is the factory default setting. • To set this option using the Embedded Web Server, type the network printer IP address in the Web browser address field.
Page 125: Utilities Menu
Understanding the printer menus Disk Near Full Action Determine and set how the printer responds when the printer hard disk is nearly full. None Notes: E‑mail Current Log • None is the factory default setting. E‑mail & Delete Current Log •...
Page 126: Xps Menu
Understanding the printer menus Format Flash Format the flash memory. Warning—Potential Damage: Do not turn off the printer while the flash memory is being formatted. Notes: • Yes deletes all data stored in the flash memory. • No cancels the format request. •...
Page 127: Postscript Menu
Understanding the printer menus Annotations Print annotations in a PDF. Do Not Print Note: Do Not Print is the factory default setting. Print PostScript menu Print PS Error Print a page containing the PostScript error. Note: Off is the factory default setting. Lock PS Startup Mode Disable the SysStart file.
Page 128 Understanding the printer menus Symbol Set Specify the symbol set for each font name. 10U PC‑8 Notes: 12U PC‑850 • 10U PC‑8 is the US factory default setting. 12U PC‑850 is the international factory default setting. • A symbol set is a set of alphabetic and numeric characters, punctuation, and special symbols.
Page 129 Understanding the printer menus PCL Emulation Settings Specify whether the printer automatically performs a carriage return (CR) after a line feed (LF) control command. Auto CR after LF Note: Off is the factory default setting. PCL Emulation Settings Specify whether the printer automatically performs a line feed (LF) after a carriage return (CR) control command.
Page 130: Html Menu
Understanding the printer menus HTML menu Font Name Joanna MT Set the default font for HTML documents. Albertus MT Letter Gothic Note: The Times font is used in HTML documents that do not Antique Olive Lubalin Graph specify a font. Apple Chancery Marigold Arial MT...
Page 131: Help Menu
The Help menu consists of a series of Help pages that are stored in the printer as PDFs. They contain information about using the printer and performing printing tasks. English, French, German, and Spanish translations are stored in the printer. Other translations are available at http://support.lexmark.com. Menu item Description...
Page 132 Understanding the printer menus Menu item Description Printing Guide Provides information about loading paper and other specialty media Media Guide Provides a list of the paper sizes supported in trays and feeders Print Defects Guide Provides information about resolving print defects Menu Map Provides a list of the printer control panel menus and settings Information Guide...
Page 133: Saving Money And The Environment
Saving money and the environment Saving money and the environment Lexmark is committed to environmental sustainability and is continually improving its printers to reduce their impact on the environment. We design with the environment in mind, engineer our packaging to reduce materials, and provide collection and recycling programs.
Page 134: Saving Energy
Saving money and the environment Avoid paper jams Correctly set the paper type and size to avoid paper jams. For more information, see “Avoiding jams” on page 158. Saving energy Using Eco‑Mode Open a Web browser, and then type the printer IP address in the address field. Notes: •...
Page 135: Adjusting Sleep Mode
Saving money and the environment Reduce printer noise. Notes: • Print jobs process at a reduced speed. • Printer engine motors do not start until a document is ready to print. There is a short delay before the first page is printed. •...
Page 136: Recycling
Click Settings > General Settings. In the Screen Brightness field, enter the brightness percentage you want for the display. Click Submit. Recycling Lexmark provides collection programs and environmentally progressive approaches to recycling. For more information, see: • The Notices chapter •...
Page 137: Recycling Lexmark Products
The foam used in Lexmark packaging is recyclable where foam recycling facilities exist. Facilities may not exist in your area. When you return a cartridge to Lexmark, you can reuse the box that the cartridge came in. Lexmark will recycle the box.
Page 138: Securing The Printer
Securing the printer Securing the printer Using the security lock feature The printer is equipped with a security lock feature. When a lock compatible with most laptop computers is attached, the printer is locked. When locked, the controller board shield and the controller board cannot be removed. Attach a security lock to the printer in the location shown.
Page 139: Erasing Volatile Memory
Securing the printer • The printer is being serviced by someone from outside your organization. • The printer is being removed from your premises for service. • The printer is being sold to another organization. Disposing of a printer hard disk Note: Some printer models may not have a printer hard disk installed.
Page 140: Erasing Printer Hard Disk Memory
Securing the printer Erasing printer hard disk memory Notes: • Some printer models may not have a printer hard disk installed. • Configuring Erase Temporary Data Files in the printer menus lets you remove residual confidential material left by print jobs by securely overwriting files that have been marked for deletion. Using the printer control panel Turn off the printer.
Page 141: Finding Printer Security Information
You can also see the Embedded Web Server — Security: Administrator’s Guide for additional information: Go to www.lexmark.com, and then navigate to Support & Downloads > select your printer. Click the Manuals tab, and then select Embedded Web Server — Security: Administrator’s Guide.
Page 142: Maintaining The Printer
Maintaining the printer Maintaining the printer Cleaning printer parts Cleaning the printer Note: You may need to perform this task after every few months. Warning—Potential Damage: Damage to the printer caused by improper handling is not covered by the printer warranty.
Page 143: Checking The Status Of Parts And Supplies
Maintaining the printer Insert the emptied hole punch box back into the finisher until it clicks into place. Checking the status of parts and supplies A message appears on the printer display when a replacement supply item is needed or when maintenance is required. Checking the status of parts and supplies on the printer control panel From the printer control panel, navigate to: >...
Page 144: Ordering Supplies
Using genuine Lexmark parts and supplies Your Lexmark printer is designed to function best with genuine Lexmark supplies and parts. Use of third-party supplies or parts may affect the performance, reliability, or life of the printer and its imaging components. Use of third-party supplies or parts can affect warranty coverage.
Page 145: Ordering A Toner Cartridge
Maintaining the printer Ordering a toner cartridge Notes: • The estimated cartridge yield is based on approximately 5% coverage per page. • Extremely low print coverage for extended periods of time may negatively affect actual yield. Part name Part number Toner Cartridge 24B6015 Ordering an imaging unit...
Page 146: Storing Supplies
Maintaining the printer Lexmark Return Program fuser maintenance kit type Fuser maintenance kit type Part number M5100 Series Return Program fuser maintenance kit type 00 40X8420 M5100 Series Return Program fuser maintenance kit type 01 40X8421 M5100 Series Return Program fuser maintenance kit type 02...
Page 147: Replacing Supplies
Maintaining the printer Replacing supplies Replacing the toner cartridge Lift the front cover, and then pull down the multipurpose feeder door. Pull the cartridge out of the printer using the handle.
Page 148 Maintaining the printer Unpack the new toner cartridge, then remove the packing material, and then shake the cartridge to redistribute the toner. Insert the toner cartridge into the printer by aligning the side rails of the cartridge with the arrows on the side rails inside the printer.
Page 149 Maintaining the printer Replacing the imaging unit Lift the front cover, and then pull down the multipurpose feeder door. Pull out the toner cartridge from the printer using the handle. Lift the green handle, and then pull out the imaging unit from the printer.
Page 150 Maintaining the printer Unpack the new imaging unit, and then shake it. Remove all packing material from the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum.
Page 151 Maintaining the printer Insert the toner cartridge into the printer by aligning the side rails of the cartridge with the arrows on the side rails inside the printer. Close the multipurpose feeder door and the front cover.
Page 152 Maintaining the printer Replacing a staple cartridge Open the stapler door. Pull down the latch of the staple cartridge holder, and then pull the holder out of the finisher. Squeeze both sides of the empty staple case with your fingers, and then remove the staple case from the cartridge.
Page 153: Moving The Printer
Maintaining the printer Insert the front side of the new staple case into the staple cartridge, and then push the rear side into the cartridge. Push the staple cartridge into the finisher until it clicks into place. Close the stapler door. Moving the printer CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more trained personnel to lift it safely.
Page 154 Maintaining the printer • If the printer does not have a caster base but is configured with optional trays, then remove the trays. Note: Slide the latch on the right side of the optional tray toward the front of the tray until it clicks into place. •...
Page 155: Moving The Printer To Another Location
Maintaining the printer Warning—Potential Damage: Damage to the printer caused by improper moving is not covered by the printer warranty. Moving the printer to another location The printer and its hardware options can be safely moved to another location by following these precautions: •...
Page 156: Managing The Printer
This chapter covers basic administrative support tasks using the Embedded Web Server. For more advanced system support tasks, see the Networking Guide on the Software CD or the Embedded Web Server Administrator's Guide at http://support.lexmark.com. Checking the virtual display Open a Web browser, and then type the printer IP address in the address field.
Page 157: Restoring Factory Default Settings
Managing the printer Notes: • View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123. • If you are using a proxy server, then temporarily disable it to load the Web page correctly. Click the Copy Printer Settings.
Page 158: Clearing Jams
Clearing jams Clearing jams By carefully selecting paper and specialty media and loading it properly, you should be able to avoid most jams. If jams occur, then follow the steps outlined in this chapter. Warning—Potential Damage: Never use any tool to remove a jam. Doing so could permanently damage the fuser. Avoiding jams Load paper properly •...
Page 159 Clearing jams • Do not slide the paper into the tray. Load paper as shown in the illustration. • Make sure the guides in the tray or the multipurpose feeder are properly positioned and are not pressing tightly against the paper or envelopes. •...
Page 160: Understanding Jam Messages And Locations
Clearing jams • If paper needs to be returned to the mailbox bin, then insert the paper under the bin arm, and then push the paper all the way back. Note: If the paper is not under the bin arm, then a jam occurs due to an overfilled bin. Use recommended paper •...
Page 161 Clearing jams Jam location Printer message What to do Staple finisher [x]‑page jam, remove paper, open Remove paper from the stapler bin, open the stapler stapler door. Leave paper in bin. [455– door, then remove the staple cartridge, and then 457] remove the jammed staples.
Page 162: [X]-Page Jam, Lift Front Cover To Remove Cartridge [200-201]
Clearing jams Jam location Printer message What to do Upper door and rear [x]‑page jam, open upper and lower Open the rear door of the printer and the rear duplex duplex area rear door. [231–234] area, and then remove the jammed paper. Mailbox [x]‑page jam, remove paper, open Open the rear door of the mailbox, and then remove...
Page 163 Clearing jams Lift the green handle, and then pull the toner cartridge out of the printer. Place the cartridge aside. Lift the green handle, and then pull the imaging unit out of the printer. Place the imaging unit aside on a flat, smooth surface. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes.
Page 164 Clearing jams Warning—Potential Damage: The jammed paper may be covered with toner, which can stain garments and skin. Install the imaging unit. Note: Use the arrows on the side of the printer as a guide. Insert the cartridge into the printer, and then push the green handle back into place. Notes: •...
Page 165: [X]-Page Jam, Open Upper Rear Door [202]
Clearing jams Close the multipurpose feeder door and the front cover. To clear the message and continue printing, select Next > > Clear the jam, press OK > [x]‑page jam, open upper rear door [202] CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching.
Page 166: [X]-Page Jam, Open Upper And Lower Rear Door [231-234]
Clearing jams Close the rear door. To clear the message and continue printing, select Next > > Clear the jam, press OK > [x]‑page jam, open upper and lower rear door [231–234] CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching.
Page 167 Clearing jams Close the rear door. Push the back of the standard tray. Press down the rear duplex flap, then firmly grasp the jammed paper, and then gently pull the paper out. Note: Make sure all paper fragments are removed.
Page 168: [X]-Page Jam, Remove Standard Bin Jam [203]
Clearing jams Insert the standard tray. To clear the message and continue printing, select Next > > Clear the jam, press OK > [x]‑page jam, remove standard bin jam [203] Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed.
Page 169: [X]-Page Jam, Remove Tray 1 To Clear Duplex [235-239]
Clearing jams [x]‑page jam, remove tray 1 to clear duplex [235–239] Lift the tray slightly, and then pull out it out completely. Push down the front duplex flap, then firmly grasp the jammed paper, and then gently pull the paper to the right and out of the printer.
Page 170: [X]-Page Jam, Open Tray [X] [24X]
Clearing jams [x]‑page jam, open tray [x] [24x] Check which tray is indicated on the printer display, and then pull the tray. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Insert the tray.
Page 171: [X]-Page Jam, Clear Manual Feeder [250]
Clearing jams [x]‑page jam, clear manual feeder [250] From the multipurpose feeder, firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface.
Page 172: [X]-Page Jam, Remove Paper, Open Stapler Door. Leave Paper In Bin. [455-457]
Clearing jams [x]‑page jam, remove paper, open stapler door. Leave paper in bin. [455–457] From the stapler bin, firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Open the stapler door.
Page 173 Clearing jams Use the metal tab to lift the staple guard, and then remove any loose staples. Press down the staple guard until it clicks into place.
Page 174 Clearing jams Slide the staples toward the metal bracket. Note: If the staples are at the rear of the cartridge, then shake the cartridge downward to bring the staples near the metal bracket. Warning—Potential Damage: Do not tap the cartridge on a hard surface. This could damage the cartridge. Push the cartridge holder firmly back into the stapler unit until the cartridge holder clicks into place.
Page 175: [X]-Page Jam, Remove Paper, Open Finisher Rear Door. Leave Paper In Bin. [451]
Clearing jams [x]‑page jam, remove paper, open finisher rear door. Leave paper in bin. [451] Open the rear staple finisher door. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Close the staple finisher door.
Page 176: [X]-Page Jam, Remove Paper, Open Expander Rear Door. Leave Paper In Bin. [41Y.xx]
Clearing jams [x]‑page jam, remove paper, open expander rear door. Leave paper in bin. [41y.xx] Open the output expander rear door. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Close the output expander rear door.
Page 177: [X]-Page Jam, Remove Paper, Open Mailbox Rear Door. Leave Paper In Bin. [43Y.xx]
Clearing jams [x]‑page jam, remove paper, open mailbox rear door. Leave paper in bin. [43y.xx] Open the mailbox rear door. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Close the mailbox rear door.
Page 178 Clearing jams If the jam is in the mailbox bin, then firmly grasp the jammed paper, and then gently pull it out. Note: Make sure all paper fragments are removed. To clear the message and continue printing, select Next > >...
Page 179: Troubleshooting
Cartridge, imaging unit mismatch [41.xy] Check if both the toner cartridge and imaging unit are Lexmark-authorized MICR (magnetic ink character recognition) supplies or non-MICR supplies. Change the toner cartridge or imaging unit so that both are Lexmark-authorized MICR supplies or non‑MICR supplies. Notes: •...
Page 180 Troubleshooting Change [paper source] to [custom type name] load [orientation] Try one or more of the following: • Load the correct size and type of paper in the tray, and then press on the printer control panel. Note: Make sure the paper size and type settings are specified in the Paper menu on the printer control panel. •...
Page 181: Close Door Or Insert Cartridge
Troubleshooting Close door or insert cartridge The toner cartridge is missing or not installed properly. Insert the cartridge, and then close all doors and covers. Close finisher rear door Close the rear door of the finisher. Close rear door Close the rear door of the printer. Complex page, some data may not have printed [39] Try one or more of the following: •...
Page 182: Disk Must Be Formatted For Use In This Device
Troubleshooting Disk full [62] Try one or more of the following: • From the printer control panel, press to clear the message and continue printing. • Delete fonts, macros, and other data stored in the printer hard disk. • Install a printer hard disk with larger capacity. Disk must be formatted for use in this device From the printer control panel, select Format disk to format the printer hard disk and clear the message.
Page 183: Insert Staple Cartridge
Troubleshooting Imaging unit very low, [x] estimated pages remain [84.xy] You may need to replace the imaging unit very soon. For more information, see the “Replacing supplies” section of the User’s Guide. If necessary, press on the printer control panel to clear the message and continue printing. Incompatible output bin [x] [59] Do either of the following: •...
Page 184 Troubleshooting Insert Tray [x] Insert the indicated tray into the printer. Install bin [x] Try one or more of the following: • Install the specified bin: Turn off the printer. Unplug the power cord from the electrical outlet. Install the specified bin. Connect the power cord to a properly grounded electrical outlet.
Page 185: Load Staples
Troubleshooting Insufficient memory, some held jobs will not be restored [37] Do either of the following: • From the printer control panel, press to clear the message. • Delete other held jobs to free up additional printer memory. Insufficient memory to collate job [37] Try one or more of the following: •...
Page 186 Troubleshooting Load [paper source] with [custom type name] [orientation] Try one or more of the following: • Load the tray or feeder with the correct size and type of paper. • From the printer control panel, press to clear the message and continue printing. Note: If the printer finds a tray that has the correct size and type of paper, then it feeds from that tray.
Page 187 • Cancel the current job. Maintenance kit low [80.xy] You may need to order a maintenance kit. For more information, visit the Lexmark support Web site at http://support.lexmark.com or contact customer support, and then report the message. If necessary, press on the printer control panel to clear the message and continue printing.
Page 188 Troubleshooting Maintenance kit very low, [x] estimated pages remain [80.xy] You may need to replace the maintenance kit very soon. For more information, visit the Lexmark support Web site at http://support.lexmark.com or contact customer support, and then report the message.
Page 189: Paper Changes Needed
Printer had to restart. Last job may be incomplete. From the printer control panel, select Continue to clear the message and continue printing. For more information, visit http://support.lexmark.com or contact customer support. Parallel port [x] disabled [56] Do either of the following: •...
Page 190 Troubleshooting Connect the power cord to a properly grounded electrical outlet. Turn the printer back on. • Remove the specified bin: Turn off the printer. Unplug the power cord from the electrical outlet. Remove the specified bin. Contact customer support. •...
Page 191: Remove Paper From All Bins
Troubleshooting Reinstall missing or unresponsive fuser [31.xy] Try one or more of the following: • Remove the unresponsive fuser, and then reinstall it. Note: If the message appears after reinstalling the supply, then the fuser is defective. Replace the fuser. •...
Page 192: Remove Paper From Standard Output Bin
Note: If you do not have a replacement imaging unit, then see the “Ordering supplies” section of the User’s Guide or visit www.lexmark.com. Replace maintenance kit, 0 estimated pages remain [80.xy] The printer is scheduled for maintenance. For more information, visit the Lexmark support Web site at http://support.lexmark.com or contact your service representative, and then report the message.
Page 193: Restore Held Jobs
Guide. Note: If you do not have a replacement cartridge, then see the “Ordering supplies” section of the User’s Guide or visit www.lexmark.com. Replace unsupported fuser [32.xy] Remove the fuser, and then install a supported one. For more information, see the instruction sheet that came with the part.
Page 194: Some Held Jobs Were Not Restored
• Turn off the printer, and then turn it back on. • Update the network firmware in the printer or the print server. For more information, visit the Lexmark support Web site at http://support.lexmark.com. Standard USB port disabled [56] Try one or more of the following: •...
Page 195: Unsupported Disk
Troubleshooting Too many disks installed [58] Turn off the printer. Unplug the power cord from the electrical outlet. Remove the extra printer hard disks. Connect the power cord to a properly grounded electrical outlet. Turn the printer back on. Too many flash options installed [58] Turn off the printer.
Page 196: Solving Printer Problems
Troubleshooting Unsupported option in slot [x] [55] Turn off the printer. Unplug the power cord from the electrical outlet. Remove the unsupported option card from the printer controller board, and then replace it with a supported card. Connect the power cord to a properly grounded electrical outlet. Turn the printer back on.
Page 197 Troubleshooting Action Step 4 Unplug the other Go to step 5. electrical equipment, Check other electrical equipment plugged into the electrical outlet. and then turn on the printer. If the printer Does other electrical equipment work? does not work, then reconnect the other electrical equipment.
Page 198: Printer Display Is Blank
Troubleshooting Action Step 11 Go to step 12. Install the correct printer driver. Check the installed printer driver. Is the correct printer driver installed? Step 12 The problem is solved. Contact customer support. Turn off the printer, then wait for about 10 seconds, and then turn the printer back on.
Page 199: Hardware And Internal Option Problems
Troubleshooting Hardware and internal option problems 2100-sheet tray problems Action Step 1 The problem is solved. Go to step 2. Pull out the tray, and then do one or more of the following: • Make sure paper lies flat in the tray. •...
Page 200: Internal Print Server Does Not Operate Correctly
Troubleshooting Cannot detect internal option Action Step 1 The problem is solved. Go to step 2. Turn off the printer, then wait for about 10 seconds, and then turn on the printer. Does the internal option operate correctly? Step 2 Go to step 3.
Page 201: Tray Problems
Troubleshooting Action Step 2 The problem is solved. Contact customer support. Check the cable and the internal print server connection. Use the correct cable, and then check if it is securely connected to the internal print server. Does the internal print server operate correctly? Tray problems Action Step 1...
Page 202: Internal Solutions Port Does Not Operate Correctly
Troubleshooting Internal Solutions Port does not operate correctly Action Step 1 Go to step 2. Check if you have a supported ISP. Make sure the Internal Solutions Port (ISP) is installed. Note: An ISP from Install the ISP. For more information, see “Installing an Internal another printer may Solutions Port”...
Page 203: Paper Feed Problems
Troubleshooting Paper feed problems Jammed pages are not reprinted Action The problem is solved. Contact customer Turn on jam recovery. support. From the printer control panel, navigate to: Settings > General Settings > Print Recovery > Jam Recovery Select On or Auto, and then press Resend the pages that did not print.
Page 204: Solving Print Problems
Troubleshooting Paper jam message remains after jam is cleared Action Contact customer The problem is solved. From the printer control panel, navigate to: support. Next > > Clear the jam, press OK > Follow the instructions on the printer display. Does the paper jam message remain? Solving print problems Printing problems...
Page 205: Incorrect Characters Print
Troubleshooting Error message about reading the flash drive appears Action Step 1 Go to step 2. Insert the flash drive into the front USB port. Check if the flash drive is inserted into the front USB port. Note: The flash drive will not work if it is inserted into the rear USB port.
Page 206: Job Prints From The Wrong Tray Or On The Wrong Paper
Troubleshooting Job prints from the wrong tray or on the wrong paper Action Step 1 The problem is solved. Go to step 2. Check if you are printing on paper that is supported by the tray. Resend the print job. Did the job print from the correct tray or on the correct paper? Step 2 The problem is solved.
Page 207: Print Job Takes Longer Than Expected
Troubleshooting Action Step 3 The problem is solved. Contact customer support. Reduce the complexity of the print job by eliminating the number and size of fonts, the number and complexity of images, and the number of pages in the job. Did the job print and collate correctly? Multiple‑language PDF files do not print Action...
Page 208: Print Jobs Do Not Print
Troubleshooting Action Step 4 The problem is solved. Go to step 5. Disable the Page Protect feature. From the printer control panel, navigate to: Settings > General Settings > Print Recovery > Page Protect > Off Resend the print job. Did the job print? Step 5 The problem is solved.
Page 209: Printing Slows Down
Remove, and then reinstall the printer software. For more information, see “Installing the printer” on page Note: The printer software is available at http://support.lexmark.com. Resend the print job. Do the jobs print? Printing slows down Notes: • When printing using narrow paper, the printer prints at a reduced speed to prevent damage to the fuser.
Page 210: Unexpected Page Breaks Occur
Troubleshooting Action Step 1 The problem is solved. Go to step 2. Open the trays, and then check if they contain paper of the same size and type. • Check if the paper guides are in the correct positions for the size of the paper loaded in each tray.
Page 211: Print Quality Problems
Troubleshooting Print quality problems Characters have jagged or uneven edges Action Step 1 Go to step 2. Select a font that is supported by the Print a font sample list to check if the fonts you are using are supported printer.
Page 212 Troubleshooting Action Step 2 Go to step 3. Do one or more of the following: From the printer control panel, set the paper size and type in the Paper menu to match the paper loaded in the tray. • Specify the paper size from the tray settings to match Do the paper size and type match the paper loaded in the tray?
Page 213: Gray Background On Prints
Troubleshooting Action Step 2 The problem is solved. Contact customer support. Replace the fuser. For more information on installing the fuser, see the instruction sheet that came with the part. Resend the print job. Do compressed images still appear? Gray background on prints Leading edge ABCDE ABCDE...
Page 214: Horizontal Voids Appear On Prints
Troubleshooting Horizontal voids appear on prints Leading edge Trailing edge Action Step 1 Go to step 2. The problem is solved. Make sure your software program is using a correct fill pattern. Resend the print job. Do horizontal voids appear on prints? Step 2 Go to step 3.
Page 215: Incorrect Margins On Prints
Troubleshooting Incorrect margins on prints Action Step 1 The problem is solved. Go to step 2. Move the width and length guides in the tray to the correct positions for the paper size loaded. Resend the print job. Are the margins correct? Step 2 Go to step 3.
Page 216: Paper Curl
Troubleshooting Paper curl Action Step 1 Go to step 2. Adjust the width and length guides. Move the width and length guides in the tray to the correct positions for the size of the paper loaded. Are the width and length guides positioned correctly? Step 2 Go to step 3.
Page 217 Troubleshooting Action Step 1 Go to step 2. The problem is solved. Move the width and length guides in the tray to the correct positions for the size of the paper loaded in the tray. Resend the print job. Do print irregularities still appear? Step 2 Go to step 3.
Page 218: Print Is Too Dark
Troubleshooting Print is too dark Action Step 1 Go to step 2. The problem is solved. From the Quality menu on the printer control panel, reduce the toner darkness. Note: 8 is the factory default setting. Resend the print job. Is the print still too dark? Step 2 Go to step 3.
Page 219: Print Is Too Light
Troubleshooting Action Step 5 Go to step 6. The problem is solved. Load paper from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you use it. Resend the print job. Is the print still too dark? Step 6 Contact...
Page 220: Printer Is Printing Blank Pages
Troubleshooting Action Step 4 From the printer Go to step 5. control panel, change Make sure that the paper has no texture or rough finishes. the texture settings in the Paper Texture Are you printing on textured or rough paper? menu to match the paper you are printing Step 5...
Page 221: Printer Is Printing Solid Black Pages
Troubleshooting Action Step 1 Go to step 2. The problem is solved. Check if there is packing material left on the imaging unit. Remove the toner cartridge, and then the imaging unit. Check if the packing material is properly removed from the imaging unit.
Page 222: Repeating Defects Appear On Prints
Troubleshooting Action Step 1 Go to step 2. The problem is solved. Reinstall the imaging unit. Remove the toner cartridge, and then the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems.
Page 223: Shadow Images Appear On Prints
Troubleshooting Shadow images appear on prints Leading edge A B C D A B C D A B C D A B C D Trailing edge Action Step 1 Go to step 2. Load paper with the correct paper type and Load paper with the correct paper type and weight in the tray.
Page 224: Streaked Horizontal Lines Appear On Prints
Troubleshooting Action Step 1 Go to step 2. The problem is solved. Move the width and length guides in the tray to the correct positions for the size of the paper loaded. Resend the print job. Is the print still skewed? Step 2 Contact customer...
Page 225: Streaked Vertical Lines Appear On Prints
Troubleshooting Action Step 4 Go to step 5. The problem is solved. Reinstall the imaging unit. Remove the toner cartridge, and then the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems.
Page 226: Toner Specks Appear On Prints
Troubleshooting Action Step 3 Go to step 4. The problem is solved. Load paper from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you use it. Resend the print job. Do streaked vertical lines appear on prints? Step 4 Go to step 5.
Page 227: Toner Rubs Off
Troubleshooting Action Step 1 The problem is solved. Go to step 2. Reinstall the imaging unit. Remove the toner cartridge, and then the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems.
Page 228: Transparency Print Quality Is Poor
Troubleshooting Transparency print quality is poor Action Step 1 Go to step 2. Set the paper type to Transparency. From the printer control panel, set the paper type in the Paper menu to match the paper loaded in the tray. Is the paper type for the tray set to Transparency? Step 2 Contact...
Page 229: Embedded Web Server Does Not Open
Troubleshooting Action Step 2 Go to step 3. The problem is solved. From the printer control panel, set the paper type and weight in the Paper menu to match the paper loaded in the tray. Resend the print job. Do vertical voids appear on prints? Step 3 Go to step 4.
Page 230: Contacting Customer Support
You need to know your printer model type and serial number. For more information, see the label at the back of the printer. The serial number is also listed on the menu settings page. Lexmark has various ways to help you solve your printing problem. Visit the Lexmark Web site at http://support.lexmark.com, and then select one of the following: Tech Library You can browse our library of manuals, support documentation, drivers, and other downloads to help you solve common problems.
Page 231 Troubleshooting Telephone support is also available. In the U.S. or Canada, call 1-800-539-6275. For other countries or regions, visit http://support.lexmark.com.
Page 232: Notices
The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Page 233 All licensing notices associated with this product can be viewed from the root directory of the documentation CD. Trademarks Lexmark, Lexmark with diamond design, and MarkVision are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
Page 234: Noise Emission Levels
The WEEE logo signifies specific recycling programs and procedures for electronic products in countries of the European Union. We encourage the recycling of our products. If you have further questions about recycling options, visit the Lexmark Web site at www.lexmark.com for your local sales office phone number.
Page 235: Static Sensitivity Notice
ENERGY STAR Any Lexmark product bearing the ENERGY STAR emblem on the product or on a start-up screen is certified to comply with Environmental Protection Agency (EPA) ENERGY STAR requirements as configured when shipped by Lexmark.
Page 236: Power Consumption
The product is plugged into an electrical outlet, but the power switch is turned off. The power consumption levels listed in the previous table represent time-averaged measurements. Instantaneous power draws may be substantially higher than the average. Values are subject to change. See www.lexmark.com for current values.
Page 237: Hibernate Mode
The total product energy usage is the sum of each mode's energy usage. Modular component notice This product may contain the following modular component(s): Lexmark Regulatory Type/LEX-M01-005; FCC ID: IYLLEXM01005; Industry Canada IC: 2376A-M01005 Multiple model information The following information applies to M5163dn printer model.
Page 238: Industry Canada Compliance Statement
Note: To assure compliance with FCC regulations on electromagnetic interference for a Class B computing device, use a properly shielded and grounded cable such as Lexmark part number 1021231 for parallel attach or 1021294 for USB attach. Use of a substitute cable not properly shielded and grounded may result in a violation of FCC regulations.
Page 239: Regulatory Notices For Wireless Products
The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA. The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium Tower III, 1095 Budapest HUNGARY, A declaration of conformity to the requirements of the Directives is available upon request from the Authorized Representative.
Page 240: Notice To Users In The European Union
Compliance is indicated by the CE marking. The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA. The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium Tower III, 1095 Budapest HUNGARY.
Page 241 Operation is allowed in all EU and EFTA countries, but is restricted to indoor use only. The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA. The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium Tower III, 1095 Budapest HUNGARY.
Page 242 Alulírott, Lexmark International, Inc. nyilatkozom, hogy a termék megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Íslenska Hér með lýsir Lexmark International, Inc. yfir því að þessi vara er í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC. Italiano Con la presente Lexmark International, Inc.
Page 243 Remarketer or Lexmark, or ship it prepaid and suitably packaged to a Lexmark designated location. You are responsible for loss of, or damage to, a product in transit to the Remarketer or the Lexmark designated location.
Page 244: Limitation Of Liability
ANY LOST PROFITS, LOST SAVINGS, INCIDENTAL DAMAGE, OR OTHER ECONOMIC OR CONSEQUENTIAL DAMAGES. This is true even if you advise Lexmark or a Remarketer of the possibility of such damages. Lexmark is not liable for any claim by you based on a third party claim.
Page 245 Notices The use of this product or service is subject to the reasonable, non-discriminatory terms in the Intellectual Property Rights (IPR) Disclosure of Certicom Corp. at the IETF for Addition of the Camellia Cipher Suites to Transport Layer Security (TLS) implemented in the product or service. The use of certain patents in this product or service is subject to the reasonable, non-discriminatory terms in the Intellectual Property Rights (IPR) Disclosure of Certicom Corp.
Page 246: Index
Index Index avoiding jams 67 Close finisher rear door 181 Numerics avoiding paper jams 158 Close rear door 181 2100‑sheet tray Complex page, some data may not loading 50 have printed [39] 181 550‑sheet tray compressed images appear on Bin Setup menu 89 installing 31 prints 212 buttons, printer control panel 11...
Page 247 Index contacting customer support 230 copying settings to other finisher control panel, printer printers 156 finishing features 70 indicator light 12 modifying confidential print supported paper sizes 70 Sleep button light 12 settings 156 finisher features 70 controller board networking settings 156 Finishing menu 121 accessing 13 problem accessing 229...
Page 248 Index individual settings Maintenance kit very low, [x] erasing 139 estimated pages remain keypad Insert hole punch box 183 [80.xy] 188 printer control panel 11 Insert staple cartridge 183 memory Insert Tray [x] 184 types installed on printer 138 Install bin [x] 184 memory card 13 labels, paper Install Tray [x] 184...
Page 249 Embedded Utilities 125 imaging unit 145 Web Server 143 Wireless 96 maintenance kit 145 using genuine Lexmark 144 XPS 126 staple cartridges 145 parts and supplies, status of mobile device ordering supplies checking, on printer control...
Page 250 Index white streaks 228 printer information Complex page, some data may not Print Settings menu 117 where to find 7 have printed [39] 181 print troubleshooting printer is printing blank pages 220 Configuration change, some held error reading flash drive 205 printer messages jobs were not restored [57] 181 held jobs do not print 204...
Page 251 Standard USB port disabled using 39 Network [x] software error [56] 194 [54] 188 Supply needed to complete Non‑Lexmark [supply type], see job 194 Quality menu 123 User’s Guide [33.xy] 188 Too many bins attached [58] 194 Quiet mode 134...
Page 252 Index repeating defects appear on setting using genuine Lexmark 144 prints 222 paper size 43 using recycled paper 133 Replace cartridge, 0 estimated paper type 43 supplies, ordering pages remain [88.xy] 192 TCP/IP address 94 imaging unit 145 Replace cartridge, printer region...
Page 253 Index troubleshooting, display transparency print quality is printer display is blank 198 poor 228 wiping printer hard disk 140 troubleshooting, paper feed uneven print density 228 Wireless menu 96 message remains after jam is white streaks on a page 228 wireless network cleared 204 troubleshooting, printer options...

Lexmark M5163dn User Manual

Safety Information

Learning about the Printer

Additional Printer Setup

Loading Paper and Specialty Media

Paper and Specialty Media Guide

Printing

Understanding the Printer Menus

Saving Money and the Environment

Securing the Printer

Maintaining the Printer

Managing the Printer

Clearing Jams

Troubleshooting

Notices

Index

Quick Links

Related Manuals for Lexmark M5163dn

Summary of Contents for Lexmark M5163dn
