Quick Setup Guide
Start Here
Please read the Safety and Legal booklet first before you set up your machine. Then, please read this Quick Setup
Guide for the correct setup and installation.
To view the Quick Setup Guide in other languages, please visit http://solutions.brother.com/.
WARNING
CAUTION
1
Unpack the machine and check the components
Drum Unit and Toner Cartridge Assembly
(pre-installed)
WARNING
Plastic bags are used in the packaging of your machine. Plastic bags are not toys. To avoid danger of
suffocation, please keep these bags away from babies and children and dispose of them properly.
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injuries.
CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injuries.
Installation CD-ROM,
Documentation CD-ROM
Basic User's Guide
MFC-7360N
MFC-7460DN
Product Registration
Sheet
(USA only)
Quick Setup Guide
Safety and Legal booklet
AC Power Cord
Telephone Line Cord
USA/CAN Version A
1

Advertisement

Table of Contents
loading

Related Manuals for Brother MFC-7360N

Summary of Contents for Brother MFC-7360N

  • Page 1 Please read the Safety and Legal booklet first before you set up your machine. Then, please read this Quick Setup Guide for the correct setup and installation. To view the Quick Setup Guide in other languages, please visit http://solutions.brother.com/. WARNING indicates a potentially hazardous situation which, if not avoided, WARNING could result in death or serious injuries.
  • Page 2 CAUTION CAUTION When you move the machine, grasp the side handholds that are under the scanner. DO NOT carry the machine by holding it at the bottom. Note • Keep a minimum gap around the machine as shown in the illustration. 9.85 in.
  • Page 3 Remove the packing Lift the elastic band off the drum. material from the machine IMPORTANT DO NOT connect the AC power cord yet. Remove the packing tape from the outside of the machine and the film covering the scanner glass. Open the front cover.

  • Page 4: Load Paper In Paper Tray

    Gently shake it from side to side several times Load paper in the paper to distribute the toner evenly inside the assembly. tray Pull the paper tray completely out of the machine. Put the drum unit and toner cartridge assembly back in the machine.
  • Page 5 Put paper in the tray and make sure: Note The paper is below the maximum paper  For Legal or Folio size paper, press the release mark (b b b) a. button in the bottom of the paper tray and then Over filling the paper tray will cause paper pull out the back of the paper tray.

  • Page 6: Connect The Power Cord

    WARNING Connect the power cord and telephone line The machine must be grounded using a 3-prong plug. Since the machine is grounded through the IMPORTANT power outlet, you can protect yourself from potentially hazardous electrical conditions on DO NOT connect the interface the telephone network by keeping the power cable yet.
  • Page 7 Note Choose your language If you are sharing one telephone line with an (if needed) external telephone answering machine, connect it as shown below. Before you connect the external telephone Press Menu, 0, 0. answering machine, remove the protective cap from the EXT.

  • Page 8: Choose The Correct Receive Mode

    Will you be using Voice Mail on the same telephone line as your Brother machine? If you have Voice Mail on the same telephone line as your Brother machine, there is a strong possibility that Voice Mail and the Brother machine will conflict with each other when receiving incoming calls. See Voice Mail in the Basic User’s Guide for instructions on setting up your machine using this service.

  • Page 9: Set The Date And Time

    Enter the two digits for the day on the dial pad, Set the LCD contrast and then press OK. (if needed) Date&Time Day:25 If you are having difficulty reading the LCD, try (e.g. Enter 2, 5 for 25th.) changing the contrast setting. Enter the time in 24-hour format on the dial pad, and then press OK.

  • Page 10: Set Your Station Id

    Press Three Four Five Set your Station ID time times times times times The machine displays the date and time, and if you set up the Station ID, it will add it to each fax you send. Press Menu, 0, 3. Enter your fax number (up to 20 digits) on the dial pad, and then press OK.

  • Page 11: Dial Prefix

    Fax Transmission Report Dial Prefix Your Brother machine is equipped with a The dial prefix setting will automatically dial a Transmission Verification Report that can be used as predefined number before every fax number you dial. confirmation that you sent a fax. This report lists the...

  • Page 12: Automatic Daylight Savings Time

    It will reset itself forward one CD-ROM or visit hour in the Spring and backward one hour in the Fall. http://www.brother.com/registration/. Press Menu, 0, 2, 2. Fill out the Product Registration and Test Press a or b to choose On (or Off).

  • Page 13: Choose Your Connection Type

    , go to page 14 Macintosh, go to page 16 For Wired Network ® Windows , go to page 18 Macintosh, go to page 20 Note You can download the latest drivers and utilities for your machine from the Brother Solutions Center at http://solutions.brother.com/.

  • Page 14: Install Mfl-Pro Suite

    • If there are any programs running, close Note them. If the Brother screen does not appear • The screens may differ depending on your automatically, go to My Computer (Computer), operating system. double-click the CD-ROM icon, and then double-click start.exe.
  • Page 15 The XML Paper Specification Printer Driver is ® the most suitable driver for Windows Vista ® Windows 7 when printing from applications that use the XML Paper Specification documents. Please download the latest driver by accessing the Brother Solutions Center at http://solutions.brother.com/.
  • Page 16 For Mac OS X 10.4.10 users, upgrade to Mac OS X 10.4.11 - 10.6.x. (For the latest drivers and information on the Mac OS X you are using, visit http://solutions.brother.com/.) Connect the USB cable to the USB connector marked with the symbol on your machine and then connect the cable to your Macintosh.
  • Page 17 Macintosh Download and install Presto! PageManager When Presto! PageManager is installed OCR capability is added to Brother ControlCenter2. You can easily scan, share and organize photos and documents using Presto! PageManager. On the Brother Support screen, click Presto! PageManager and follow the on-screen instructions.

  • Page 18: For Wired Network Interface Users

    MFL-Pro Suite, follow the on-screen Note instructions. If the Brother screen does not appear automatically, go to My Computer (Computer), • Disable all personal firewall software (other double-click the CD-ROM icon, and then ®...
  • Page 19 PaperPort™ 12SE or ScanSoft™ PaperPort™ software for information on how to add the 11SE installed, please purchase the Brother NL-5 following network ports. pack which is a multiple PC license agreement ...
  • Page 20 For Mac OS X 10.4.10 users, upgrade to Mac OS X 10.4.11 - 10.6.x. (For the latest drivers and information on the Mac OS X you are using, visit http://solutions.brother.com/.) Remove the protective cap from the LAN connector marked with a symbol.
  • Page 21 Network Configuration Report on page 22. When Presto! PageManager is installed OCR • If this screen appears click OK. capability is added to Brother ControlCenter2. You can easily scan, share and organize photos and documents using Presto! PageManager. On the Brother Support screen, click...

  • Page 22: For Network Users

    Print the Network Configuration (web browser) Report The Brother print server is equipped with a web server You can print the Network Configuration Report to that allows you to monitor its status or change some confirm the current network settings.

  • Page 23: Other Information

    Other Information Brother CreativeCenter Get inspired. If you're using Windows, double-click the Brother CreativeCenter icon on your desktop to access our FREE web site with many ideas and resources for personal and professional use. Mac users can access Brother CreativeCenter at this web address: http://www.brother.com/creativecenter/...
  • Page 24 Consumables When the time comes to replace consumable items, an error will be indicated by the LCD on the control panel. For more information about the consumables for your machine, visit us at http://solutions.brother.com/ or contact your local Brother reseller.
  • Page 25 The contents of this manual and the specifications of this product are subject to change without notice. Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.
