VRTIKL-CE
FREESTANDING STOVE
MODEL:
VRT-BZ-N-CE
VRT-GY-P-CE
VRT-GR-N-CE
VRT-BZ-B-CE
VRT-GY-N-CE
VRT-GR-B-CE
VRT-BZ-P-CE
VRT-GY-B-CE
VRT-GR-P-CE
• Important operating
and maintenance
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other gas stove.
• What to do if you smell gas
- Do not try to light any gas stove. Do not
touch any electrical switch. Do not use
any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
These instructions are valid for the following countries:
GB, IE
Heat & Glo • VRTIKL-CE • 7031-292 Rev E • 12/07
Installer's Guide
Installation and Operation
• Leave this manual with
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer if the barrier is not present or help is
needed to properly install one.
Installation and service of this gas stove should be performed
by qualifi ed personnel.
0063-06
