Curves Dialog Box

Curves Dialog Box

This dialog box appears when you click the Curves button on the Color Settings Sheet. You can set Channel and
other settings.
• Channel
Select from among RGB, Red, Green, or Blue.
•
Gray is displayed for monochrome printing and this selection cannot be changed.
Note
• Input
Enter an input value.
•
The allowed entry range is 0 to 255.
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
• Output
Enter an output value.
•
The allowed entry range is 0 to 255.
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
• Load Curves button
Click the button to load stored data for a tone curve.
• Save Curves button
Click the button to stores the current tone curve settings.
