Owner's Manual
Model(s):
GDST5244I
GDST5244IL
Direct Vent Gas Appliance
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or
the gas supplier.
This appliance may be installed as an OEM installation
in manufactured home (USA only) or mobile home and
must be installed in accordance with the manufacturer's
instructions and the manufactured home construction and
safety standard, Title 24 CFR, Part 3280 or Standard for
Installation in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas
indicated on the rating plate.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
• CAREFULLY SUPERVISE children in same room as
• A l e r t c h i l d r e n a n d a d u l t s t o h a z a r d s o f h i g h
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other combustibles
This appliance has been supplied with an integral
barrier to prevent direct contact with the fi xed glass
panel. Do NOT operate the appliance with the barrier
removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must
be performed by a licensed plumber or gas fi tter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Heatilator • GDST5244I • 4045-127 • Rev W • 11/08
Owner's Manual
Installation and Operation
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
appliance.
temperatures.
away.
Installation and service of this appliance should be performed
by qualifi ed personnel. Hearth & Home Technologies suggests
NFI certifi ed or factory-trained professionals, or technicians
supervised by an NFI certifi ed professional.
1
Advertisement
Table of Contents
Related Manuals for Heatilator Heatilator GDST5244I
Summary of Contents for Heatilator Heatilator GDST5244I
- Page 1 Model(s): GDST5244I GDST5244IL Direct Vent Gas Appliance • Important operating and maintenance instructions included. WARNING If the information in these instruc- tions is not followed exactly, a fi re may result causing property damage, personal injury, or death. • Do not store or use gasoline or other fl am- mable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Congratulations
Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations Congratulations on selecting a Heatilator gas fi replace, an elegant and clean alternative to wood burning fi replaces. The Heatilator gas fi replace you have selected is designed to provide the utmost in safety, reliability, and effi... -
Page 3: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... - Page 4 14 Appliance Setup A. Remove Fixed Glass Assembly B. Remove the Shipping Materials C. Clean the Appliance D. Accessories E. Install the Log Set Place the Rockwool G. Place the Lava Rock and Vermiculite H. Fixed Glass Assembly Firescreen Install Trim and/or Surround K.
-
Page 5: Warranty
B. Warranty Hearth & Home Technologies LIMITED WARRANTY Hearth & Home Technologies (“HHT”) and its respective brands extends the following warranty for HHT gas, wood, pellet and electric appliances purchased from an authorized HHT dealer and installed in the United States of America or Canada. - Page 6 B. Warranty (continued) This limited warranty does not extend to or include surface fi nish on the appliance or terminations, door gasketing, glass gasketing, glass discoloration, fi rebrick, pellet logs, kaowool or other ceramic insulating materials. Rust and/or corrosion on any of the metal surfaces, cast iron components, baffl es, fi repots, doors, or fi rebox area are not covered by this warranty.
-
Page 7: Listing And Code Approvals
Listing and Code Approvals A. Appliance Certifi cation MODELS: GDST5244I, GDST5244IL LABORATORY: Underwriters Laboratories, Inc. (UL) TYPE: Vented Gas Fireplace Heaters STANDARD: ANSI Z21.88-2005•CSA2.33-2005•UL307B This product is listed to ANSI standards for “Vented Gas Fireplace Heaters” and applicable sections of “Gas Burn- ing Heating Appliances for Manufactured Homes and Recreational Vehicles”, and “Gas Fired Appliances for Use at High Altitudes”. -
Page 8: Requirements For The Commonwealth Of Massachusetts
Note: The following requirements reference various Massachusetts and national codes not contained in this document. H. Requirements for the Commonwealth of Massachusetts For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) -
Page 9: User Guide
Operating Instructions A. Gas Fireplace Safety WARNING HOT SURFACES! Glass and other surfaces are hot during operation and cool down. Hot glass will cause burns. • Do not touch glass until it is cooled • NEVER allow children to touch glass •... -
Page 10: Fan Kit (Optional)
C. Fan Kit (optional) If desired, a fan kit may be added. Contact your dealer to order the correct fan kit. D. Clear Space WARNING! DO NOT place combustible objects in front of the fi replace or block louvers. High temperatures may start a fi... -
Page 11: Lighting Instructions (Ipi)
I. Lighting Instructions (IPI) • For normal use, activate/deactivate your fi replace with the wall switch or remote control. • The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery life, remove them when using the transformer. •... -
Page 12: After Fireplace Is Lit
J. After Fireplace is Lit Initial Break-in Procedure • The fireplace should be run three to four hours continuously on high. • Turn the fi replace off and allow it to completely cool. • Remove fi xed glass assembly. See Section 14.H. •... -
Page 13: Maintenance And Service
Maintenance and Service Any safety screen or guard removed for servicing must be replaced prior to operating the fi replace. When properly maintained, your fi replace will give you many years of trouble-free service. We recommend an- nual service by a qualifi ed service technician. A. -
Page 14: Maintenance Tasks-Qualifi Ed Service Technician
B. Maintenance Tasks-Qualifi ed Service Technician The following tasks must be performed by a qualifi ed service technician. Gasket Seal and Glass Assembly Inspection Frequency: Annually By: Qualifi ed Service Technician Tools needed: Protective gloves, drop cloth and a stable work surface. -
Page 15: Installer Guide
Getting Started A. Typical Appliance System NOTICE: Illustrations and photos refl ect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual Noncombustible roof flashing maintains minimum clearance around pipe (SECTION 10) Vent Pipe (SECTIONS 7, 8, 10) -
Page 16: Design And Installation Considerations
B. Design and Installation Considerations Heatilator direct vent gas appliances are designed to op- erate with all combustion air siphoned from outside of the building and all exhaust gases expelled to the outside. No additional outside air source is required. Installation MUST comply with local, regional, state and national codes and regulations. -
Page 17: Framing And Clearances
Framing and Clearances A. Select Appliance Location When selecting a location for the appliance it is important to consider the required clearances to walls (see Figure 5.1). WARNING! Risk of Fire or Burns! Provide adequate clearance around air openings and for service access. Due to high temperatures, the appliance should be located out of traffi... -
Page 18: Clearances
C. Clearances NOTICE: Install appliance on hard metal or wood surfaces extending full width and depth. DO NOT install directly on carpeting, vinyl, tile or any combustible material other than wood. WARNING! Risk of Fire! Maintain specifi ed air space clearances to appliance and vent pipe: •... -
Page 19: Mantel And Wall Projections
D. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances to combustibles as specifi ed. Framing or fi nishing material closer than the minimums listed must be construct- ed entirely of noncombustible materials (i.e., steel studs, concrete board, etc). -
Page 20: Termination Locations
Termination Locations A. Vent Termination Minimum Clearances WARNING Fire Risk. Maintain vent clearance to combustibles as specifi ed. • DO NOT pack air space with insulation or other materials. Failure to keep insulation or other materials away from vent pipe may cause overheating and fi re. 20 in. - Page 21 Measure vertical clearances from this surface Measure horizontal clearances from this surface. Dimension Descriptions A Clearance above the ground, a veranda, porch, deck or balcony - 12 in. (30 cm) minimum. * B Clearance to window or door that may be opened – 10,000 BTUs or less, 6 in.
-
Page 22: Vent Information And Diagrams
Vent Information and Diagrams A. Approved Pipe This appliance is approved for use with Hearth & Home Technologies DVP and/or SLP venting systems. Refer to Section 16.B. for vent component information. DO NOT mix pipe, fi ttings or joining methods from differ- ent manufacturers. -
Page 23: Vent Diagrams
E. Vent Diagrams To replace the fi rst starter elbow with two 45° elbows, refer to Figure 7.4. All other 90° elbows can be replaced with two 45° elbows. General Rules: • SUBTRACT 3 ft. from the total H measurement for each 90°... - Page 24 1. Top Vent - Horizontal Termination - (continued) Two 45° Elbows replacing One 90° Elbow Figure 7.4 Two Elbows Figure 7.5 25 ft max. (7.62 m) Installed Horizontally Heatilator • GDST5244I • 4045-127 • Rev W • 11/08 4 ft min. (1.22 m) min.
- Page 25 1. Top Vent - Horizontal Termination - (continued) Three Elbows Figure 7.6 Heatilator • GDST5244I • 4045-127 • Rev W • 11/08 min. max. 0.30 7.32 Installed Vertically max. 5.79...
- Page 26 2. Top Vent - Vertical Termination No Elbow Note: If installing a verti- cal vent/termination off the top of the appliance, the fl ue restrictor should be used. 12 ft (3.66 mm) min. 60 ft (18.29 m) max. Figure 7.7 Two Elbows 12 ft (3.66 m) min.
- Page 27 2. Top Vent - Vertical Termination - (continued) Three Elbows Figure 7.9 Maximum horizontal run is 100% of vertical, but cannot exceed 26 ft (7.92 m) 12 ft (3.66 m) min. 60 ft (18.29 m) max. Heatilator • GDST5244I • 4045-127 • Rev W • 11/08...
-
Page 28: Vent Clearances And Framing
Vent Clearances and Framing A. Pipe Clearances to Combustibles WARNING! Risk of Fire! Maintain air space clearance to vent. DO NOT pack insulation or other combustibles: • Between ceiling fi restops • Between wall shield fi restops • Around vent system Failure to keep insulation or other material away from vent pipe may cause over heating and fi... -
Page 29: Install The Ceiling Firestop
C. Install the Ceiling Firestop A ceiling fi restop MUST be used between fl oors and attics. • DVP pipe only - Frame an opening 10 in. by 10 in. (254 mm by 254 mm) whenever the vent penetrates a ceiling/fl oor (see Figure 8.3). -
Page 30: Install Attic Insulation Shield
D. Install Attic Insulation Shield WARNING! Fire Risk. DO NOT allow loose materials or insulation to touch vent. Hearth & Home Technologies Inc. requires the use of an attic shield. The National Fuel Gas Code ANSI Z223.1 and NFPA 54 requires an attic shield constructed of 26 gauge minimum metal that extends at least 2 in. -
Page 31: Appliance Preparation
Appliance Preparation A. Secure and Level the Appliance WARNING! Risk of Fire! Prevent contact with: • Sagging or loose insulation • Insulation backing or plastic • Framing and other combustible materials Block openings into the chase to prevent entry of blown-in insulation. -
Page 32: Install Vent Pipe
Install Vent Pipe A. Assemble Vent Sections (DVP Only) Attach Pipe to the Firebox Assembly Note: The end of the pipe sections with the lanced tabs will face towards the appliance. Attach the fi rst pipe section to the starting collar: •... -
Page 33: Assemble Vent Sections (Slp Only)
B. Assemble Vent Sections (SLP Only) To attach the fi rst vent component to the starting collars of the appliance • Attach an SLP-DVP24 adapter to the starting collar of the appliance. • Lock the vent components into place by sliding the pipe section onto the collar. -
Page 34: Secure The Vent Sections
D. Secure the Vent Sections • Vertical runs of DVP pipe must be supported every 8 ft. (2.44 m) after the 25 ft. (7.62 m) maximum unsupported rise. • Vertical runs of SLP pipe must be supported every 8 ft. (2.44 m). -
Page 35: Install Decorative Ceiling Components (Slp Only)
F. Install Decorative Ceiling Components (SLP only) A decorative ceiling thimble can be installed on a fl at ceil- ing through which the vent passes. The decorative ceiling thimble is used to cover the fi restop. • Seal the gap between the vent pipe and firestop using high temperature silicone to prevent cold air infi... -
Page 36: Assemble And Install Storm Collar
20 in. 24 in. min. (508 mm) (610 mm) Lowest Discharge Opening Termination Storm Collar Roof Flashing H (min.) - Minimum height from roof to lowest discharge opening. Roof Pitch H (Min.) Ft. Roof Pitch Flat to 6/12 1.0* Over 11/12 to 12/12 Over 6/12 to 7/12 1.25* Over 12/12 to 14/12... -
Page 37: Install Rf4-8
I. Install RF4-8 The RF4-8 may be used in place of the roof fl ashing and storm collar. Pipe must be supported within 12 in. (305 mm) of the roofl ine using plumbers strapping or an SLP-FS when using the RF4-8 Flashing. Refer to Sect. 10.D. Securing Vent Sections. -
Page 38: Install Vertical Termination Cap
J. Install Vertical Termination Cap • Attach the vertical termination cap by sliding the inner collar of the cap into the inner fl ue of the pipe section while placing the outer collar of the cap over the outer fl ue of the pipe section. •... -
Page 39: Install Horizontal Termination Cap
M. Install Horizontal Termination Cap WARNING! Risk of Fire! The telescoping fl ue section of the termination cap MUST be used when connecting vent. • 1-1/2 (38 mm) minimum overlap of fl ue telescoping section is required. Failure to maintain overlap may cause overheating and fi... -
Page 40: Gas Information
11 11 Gas Information A. Fuel Conversion • Make sure the appliance is compatible with available gas types. • Conversions must be made by a qualified service technician using Hearth & Home Technologies specifi ed and approved parts. B. Gas Pressure •... -
Page 41: Electrical Information
Electrical Information A. Wiring Requirements NOTICE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA 70-latest edition or the Canadian Electric Code CSA C22.1. •... -
Page 42: Junction Box Installation
E. Junction Box Installation If the box is being wired from the OUTSIDE of the appli- ance: • Remove the cover plate located on the outer shell - right side (see Figure 12.2). • Install the supplied Romex™ connector in the cover plate. -
Page 43: Finishing
Finishing A. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances to combustibles as specifi ed. Framing or fi nishing material closer than the minimums listed must be construct- ed entirely of noncombustible materials (i.e., steel studs, concrete board, etc). -
Page 44: Appliance Setup
Appliance Setup A. Remove Fixed Glass Assembly See Section 14.H. B. Remove the Shipping Materials Remove shipping materials from inside or underneath the fi rebox. C. Clean the Appliance Clean/vacuum any sawdust that may have accumulated inside the fi rebox or underneath in the control cavity. D. - Page 45 Notch Figure 14.4 Place Top - Left Log (#7) Placed on Pin P3 and Lays Across Notch in Middle Base Log Notch Figure 14.5 Place Top - Middle, Back Log (#8) Placed on Pin P4 and Lays on Notch of Log 6 Figure 14.6 Place Top - Right, Back Log (#9) Placed on Pins P5 &...
-
Page 46: Place The Rockwool
F. Place the Rockwool WARNING! Risk of Explosion! Follow rockwool placement instructions. DO NOT place rockwool directly over burner ports. Replace rockwool material annually. Improperly placed rockwool interferes with proper burner operation. • Rockwool is shipped with this gas appliance. •... -
Page 47: Troubleshooting
Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualifi ed service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualifi ed service technician. Con- tact your dealer to arrange a service call by a qualifi... - Page 48 Intellifi re Ignition System - (continued) Symptom 4. Pilot lights but continues A. A shorted or loose connection to spark, and main burner in fl ame sensing rod. will not ignite. (If the pilot continues to spark after the pilot fl ame has been lit, fl...
-
Page 49: Reference Materials
Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. Electrical Access Gas Line Access 3-1/8 in. (80 mm) 6-7/8 in. (175 mm) (127 mm) 4-7/8 in. (124 mm) Figure 16.1 Appliance Dimensions 12 in. -
Page 50: Vent Components Diagrams
B. Vent Components Diagrams Pipe DVP4 DVP6 Effective DVP12 Height/Length DVP24 DVP36 DVP48 DVP6A DVP12A DVP Pipe (see chart) Assembled Height: 24 in./610 mm Diameter: 10 in./254 mm DVP-AS2 10 in. (254 mm) 5 in. (127 mm) DVP-HVS Vent Support Figure 16.2 DVP Vent Components Effective Height/Length inches... - Page 51 B. Vent Components Diagrams (continued) 13-1/4 in. (367 mm) 24-5/8 in. (698 mm) (625 mm) RF6M Roof Flashing Multi-pak 13-3/4 in. (349 mm) 13-3/4 in. (349 mm) Trap Cap Brick Extension DVP-TRAPFL Flashing 26 in. (660 mm) DVP-HSM-B Extended Heat Shield Figure 16.3 DVP Vent Components 27-1/2 in.
- Page 52 B. Vent Components Diagrams (continued) 1-1/2 in. (38 mm) 14 in. (356 mm) 12 in. (305 mm) DVP-TB1 Basement Vent Cap 7-1/4 in. (184 mm) 5-1/4 in. (133 mm) DVP-TVHW Vertical Termination Cap (High wind) 16-7/8 in. (429 mm) 12 in. (305 mm) 7-1/8 in.
- Page 53 B. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
- Page 54 B. Vent Components Diagrams (continued) 15 in. (381 mm) Effective Length 5-3/4 to 8-3/8 in. 146 to 213 mm Figure 16.6 DVP Vent Components Fillers DVP-TRAP to DVP-HPC Side Filler Kit 8-1/8 in. 13 in. (206 mm) (330 mm) DVP-HRC-SS 5-1/2 in.
- Page 55 B. Vent Components Diagrams (continued) 8-3/4 in. 222 mm 6-5/8 in. 168 mm SLP-45 - 45° Elbow Effective Height/Length Pipe SLP4 Effective Height/ SLP6 Length SLP12 SLP24 SLP36 SLP48 SLP6A SLP-Pipe SLP12A SLP-HVS Horizontal Pipe Support SLP-FS Ceiling Firestop Wall Shield Firestop Figure 16.7 SLP Series Vent Components 6-1/2 in.
- Page 56 B. Vent Components Diagrams (continued) SLK-SNKD Snorkel Termination Cap DVP-FBHT Firebrick Termination Cap (This termination cap requires an SL-2DVP adapter when used with SLP Pipe) SLP-TRAP1 Horizontal Termination Cap SLP-TRAP2 Horizontal Termination Cap Figure 16.8 SLP Series Vent Components SLP-CCS-BK Cathedral Ceiling Sup- port Box-Black Termination Cap...
-
Page 57: Service Parts
C. Service Parts Heatilator • GDST5244I • 4045-127 • Rev W • 11/08... - Page 58 C. Service Parts (continued) Heatilator • GDST5244I • 4045-127 • Rev W • 11/08...
-
Page 59: Optional Components
D. Optional Components Optional Accessories (shipped separately) FFSTM44 Modernist-style black decorative faux front (one side only) FFSTM44PT Modernist-style pewter decorative faux front (one side only) FFSTAC44 Arts & Crafts-style black decorative faux front (one side only) FFSTAC44PT Arts & Crafts-style pewter decorative faux front (one side only) TKD6B Accent trim Brass (both sides) TKD6BN... -
Page 60: Contact Information
E. Contact Information Please contact your Heatilator dealer with any questions or concerns. ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ • Important operating a n d m a i n t e n a n c e instructions included. This product may be covered by one or more of the following patents: (United States) 4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 5113843, 5191877, 5218953, 5263471, 5328356, 5341794, 5347983, 5429495, 5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743, 6019099, 6048195, 6053165, 6145502, 6170481, 6237588,...
