Summary of Contents for Chauvet Cubix 2.0

  • Page 1 User Manual...

  • Page 2: Table Of Contents

    Master/Slave Mode ....................11 5. Technical Information ..............11 Product Maintenance .................. 11 6. Technical Specifications ..............12 Contact Procedure ..................13 Returning Products to CHAUVET® .............. 13 CHAUVET® Contact Information ..............13 Page 2 of 13 Cubix™ 2.0 User Manual (Rev. 1)

  • Page 3: Before You Begin

    CHAUVET®. Failure to do so in a timely manner may invalidate your claim with the carrier. In addition, keep the container and all the packing material for inspection.

  • Page 4: Product At A Glance

    Product at a Use on Dimmer Auto Programs   Glance Outdoor Use Auto-ranging Power Supply   Sound Activated Replaceable Fuse   User Serviceable   Master/Slave Duty Cycle   Safety Notes Please read the following Safety Notes carefully before working with the product. The Notes include important safety information about installation, usage, and maintenance.

  • Page 5: Introduction

    2. I NTRODUCTION Product Overview LED Display Fuse Holder Safety Loop DMX In/Out Power In/Out Cubix™ 2.0 User Manual (Rev. 1) Page 5 of 13...

  • Page 6: Product Dimensions

    Product Dimensions Page 6 of 13 Cubix™ 2.0 User Manual (Rev. 1)

  • Page 7: Setup

    The power linking diagram corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region.

  • Page 8: Mounting

    Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The Cubix™ 2.0 may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes.

  • Page 9: Operation

    The Cubix™ 2.0 uses up to 6 DMX channels in its 6-channel DMX mode, which defines the highest configurable address to 507. If you are not familiar with the DMX protocol, download the DMX Primer from the CHAUVET® website. To select the starting address, do the following: Press <MENU> repeatedly until 512 shows on the display.

  • Page 10: Dmx Channel Assignments And Values

    DMX Channel Assignments and Values 6-CH Channel Function Value Setting 000  004 No function 005  028 Red 029  056 Green 057  084 Blue 085  112 Cyan Colors 113  140 Purple 141  168 Yellow Perimeter Effect 169 ...

  • Page 11: Master/Slave Mode

    Master/Slave The Master/Slave mode allows a single Cubix™ 2.0 unit (the “master”) to control the actions of one or more Cubix™ 2.0 units (the “slaves”) without the need of a DMX Mode controller. The master unit will be set to operate in either Automatic or Sound Active mode, while the slave units will be set to operate in Slave Mode.

  • Page 12: Technical Specifications

    6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 10.5 in (267 mm) 12 in (305 mm) 11.6 in (296 mm) 8.1 lbs (3.7 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection Switching (internal)

  • Page 13: Contact Procedure

    If you live in the U.S., contact CHAUVET® World Headquarters (see below). • If you live in the UK or Ireland, contact CHAUVET® Europe Ltd. (see below). • If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your distributor of record.
