ABLE OF ONTENTS 1. Before You Begin................3 What Is Included ................... 3 Unpacking Instructions .................. 3 Claims ........................3 Text Conventions ..................3 Symbols ......................3 Disclaimer ..................... 3 Product at a Glance ..................4 Safety Notes ....................4 2. Introduction..................5 Product Overview ..................
CHAUVET® assumes no responsibility or liability for any errors or omissions that may appear in this manual. CHAUVET® reserves the right to update the existing document or to create a new document to correct any errors or omissions.
Product at a Use on Dimmer Auto Programs Glance Outdoor Use Auto-ranging Power Supply Sound Activated Replaceable Fuse User Serviceable Master/Slave Duty Cycle Safety Notes Please read the following Safety Notes carefully before working with the product. The Notes include important safety information about installation, usage, and maintenance.
The power linking diagram corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region.
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The Cubix™ 2.0 may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes.
The Cubix™ 2.0 uses up to 6 DMX channels in its 6-channel DMX mode, which defines the highest configurable address to 507. If you are not familiar with the DMX protocol, download the DMX Primer from the CHAUVET® website. To select the starting address, do the following: Press <MENU> repeatedly until 512 shows on the display.
DMX Channel Assignments and Values 6-CH Channel Function Value Setting 000 004 No function 005 028 Red 029 056 Green 057 084 Blue 085 112 Cyan Colors 113 140 Purple 141 168 Yellow Side Lens 169 ...
Master/Slave The Master/Slave mode allows a single Cubix™ 2.0 unit (the “master”) to control the actions of one or more Cubix™ 2.0 units (the “slaves”) without the need of a DMX Mode controller. The master unit will be set to operate in either Automatic or Sound Active mode, while the slave units will be set to operate in Slave Mode.
6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 10.5 in (267 mm) 12 in (305 mm) 11.6 in (296 mm) 8.1 lbs (3.7 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection Switching (internal)
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. CHAUVET® reserves the right to use its own discretion to repair or replace returned product(s). Contact Us World Headquarters United Kingdom &...
