EXHAUST
SYSTEM
REQUIREMENTS
Use only 4 inch (10.16 cm) diameter (minimum) rigid or flexible
metal duct and approved vent hood which has a swing-out
damper(s) that opens when the dryer is in operation. When the
dryer stops, the damper(s) automatically closes to prevent drafts
and the entrance of insects and rodents. To avoid restricting the
outlet, maintain a minimum of 12 inches (38.5 cm) clearance
between the vent hood and the ground or any other obstruction.
The following
are specific
requirements
for
proper and safe operation
of your laundry
center, Failure to
follow
these instructions
can create
excessive drying
times
and fire hazards.
[]
Do not use plastic flexible duct to exhaust the dryen Excessive
lint can build up inside the exhaust system and create a fire hazard
and restrict air flow. Restricted air flow will increase drying times.
If your present system is made up of plastic duct or metal foil
duct, _lace
it with a rigid or flexible metal duct. Ensure the
present duct is free of any lint prior to installing
laundry
center dryer duct.
[]
If the_Ly_r is not exhausted outdoors, some fine lint will be
_ed
into the Iaundr£area= An accumulation of lint in any area
of the home can create a health and fire hazard. The dryer
exhaust system MUST he exhausted to the outside of the
dwelling!
[]
Do not allow combustible materials (for example: clothing,
d raperiedcurtains_aper)
to come in contact with the exhaust
s._
The dryer MUST NOT be exLlausted into a chimney, a
wall, a ceiling, or any concealed space of a building which can
accumulate tint, resulting in a fire hazard.
[]
Do not exceed the
le__h__e
or number of elbows
allowed in the "EXHAUST DUCT LENGTHS"chart.
Lint can
accumulate in the system, plugging the systern and creating a fire
hazard, as well as increasing drying dmes
_l_Do
not screen the exhaust ends of the vent system, nor use
a_crews
or rivets to assemble the exhaust system. Lint can
become cauqht in the screen, on the screws or rivets, clogging
drying times. Use an approved vent hood to terminate the duct
outdoors, and seat all joints with duct tape. All male duct pipe
fittings MUST be installed downstream with the flow of air.
Explosion hazard. Do not install the dryer where
gasoline or other flammables are kept or stored. If the dryer is
installed in a garage, it must be a minimum of 18 inches (45.7 cm)
above the floor. Failure to do so can result in death, explosion, fire
or burns.
t.
The exhaust system back pressure MUST not exceed 0.6 inches
(! .52 cm) of water column,
measured with an inclined
manometer at the point the exhaust connects to the dryer.
.
The exhaust system should be inspected
and cleaned a
minimum of every two years with normal usage. The more
the dryer is used, the more often you should check the exhaust
system and vent hood for proper operation.
The maximum length of the exhaust system depends upon
the type of duct used, number of elbows and type of exhaust
hood.
The maximum length for both rigid and flexible duct is shown
in the chart below.
EXHAUST DUCT LENGTHS
EXHAUST HOOD TYPE
of 90_
_
Turrts
140_2
MAXIMUM
LENGTH OF 4-INCH 110,2 CM)
DIAMETER RIGID METAL DUCT
0
56 ft. ( 17.07 m)
42 ft. ( 12 8 m)
1
46ft.
(14.02 m)
36 ft.(10
97 m]
2
34 ft. (10.36 m)
28 ft. (8.53 m)
3
32 ft. (9.75 m)
18 ft (5.48 m)
MAXIMUM
LENGTH
OF 4-INCH
110.2 CM)
DIAMETER
FLEXIBLE
METAL
DUCT
0
I
2
3
30ft.(9.]4m)
22 ft.(67m)
16ft
(488m)
10 ft,(3OSm)
22 ft (67 m)
14ft
1427 m)
10 ft. (305m
5 ft 115 m)
The laundry center may be exhausted four (4) ways with
rear flush installation:
1.
Straight back.
2.
Down (8 inch (20.32 cm) length of 4 inch
rigid duct and I elbow down).
3,
Left (8 inch (20.32 cm) length of 4 inch
4.
10.16 cm)
10.16 cm)
rigid duct, 1 elbow down and 1 elbow left).
Right (8 inch (20.32 cm) length of 4 inch (10.16 cm)
rigid duct, t elbow down and 1 elbovv right).
To exhaust up, add an 11 inch (27.94 cm) length of standard
4 inch (I0.!6
cm) diameter duct and a 90 ° elbow. The unit
_i' I_<Do ! :r*'.d _:ho
_'
ir_che 111 43
(rn),_vva\
[f,,r
ibe wa[i (1lush to wall exhausting may be done by going
below the dryer then sideways).
An exhaust hood positioned to line up with the dryer exhaust
can be installed directly through the outside wall. To exhaust
up, add an 1! inch (27.94
cm) length
of standard 4
"_-
inch 110.16 cm) diameter
duct and a 90 ° elbow. The
unit will be positioned about
4V2 inches (11.43 cm) away
from the wall (flush to wall
exhausting may be done by
going below the dryer then
sideways). To exhaust to the
side or down, add an 8 inch
-..
(20.32
cm)
length
of
standard 4 inch 110.16 cm)
diameter
duct and a 90 °
elbow.
