Congratulations! You have purchased the finest wireless system in its
class. Your Shure wireless system is engineered to provide a clean, low-
noise sound comparable to other systems costing much more. Built in the
tradition of reliability that has made Shure a symbol of American quality for
more than half a century, this wireless system should provide you with ex-
cellent sound for years.
To get the most out of your T Series wireless system, please read the ap-
plicable section in this Guide before you attempt to use the system. If you
have any questions that are not answered in this booklet, please contact
Shure Customer Service at (847) 866-2553, Monday through Friday, from
8:00 am to 4:30 pm, Central Standard Time.
INTRODUCTION
Your new T Series system is designed to give you the best of both sound reinforce-
ment worlds: the freedom of a wireless system, and the world-famous Shure sound
quality. This manual covers both Standard and Diversity versions of each of the
T Series systems: the Guitarist , the Vocal Artist , and the Presenter .

SYSTEM TYPES

The Guitarist – Body-Pack system designed for use with electric guitars, basses,
and other electric instruments. The Guitarist systems are designed for guitarists who
want the freedom of going wireless, but insist on the highest quality sound and reli-
ability.
The Vocal Artist – Hand-Held system designed for singers; includes a Shure SM58
or BG 3.1 dynamic microphone with a built-in transmitter. The Vocal Artist systems
are designed for singers and other performers who prefer the sound of Shure micro-
phones and the freedom of wireless performance.
The Presenter – Body-Pack system designed for public speaking applications such
as lectures and business presentations; it features an omnidirectional Shure WL93
micro-miniature lavalier microphone. The Presenter systems are designed for public
speakers who prefer an inconspicuous, "hands-free" lavalier microphone.
Component
Transmitter
Microphone
Receiver
Power Supply
Cables
Battery
Supplied
Accessories
The Guitarist
T1G Body–Pack
—
T3 Standard or T4G
Diversity
PS20 (105–125 Vac, 60 Hz) or PS20E (220 Vac, 50 Hz)
Two guitar–to–
transmitter
Vinyl transmitter bag
Receiver feet
Receiver VELCRO
mounting strips
The Vocal Artist
T2 Microphone–
Transmitter
SM58 or Beta Green 3.1
T3 Standard or T4V
Diversity
—
9–volt alkaline
Vinyl transmitter bag
Microphone stand
adapter
2
The Presenter
T1 Body–Pack
WL93 subminiature
lavalier
T3 Standard or T4V
Diversity
—
Vinyl transmitter bag
Receiver feet
Receiver VELCRO
mounting strips
