ASSEMBLY

Assembly requires two persons. Place all parts of the elliptical crosstrainer in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the
included allen wrenches, assembly requires a phillips screwdriver
wrench , and a rubber mallet
As you assemble the elliptical crosstrainer, use the drawings below to identify the small parts used in assembly.
The number in parenthesis below each drawing refers to the key number of the part, from the PART LIST on
page 14. The second number refers to the quantity used in assembly. Note: Some small parts may have been
pre-assembled for shipping. If a part is not in the parts bag, check to see if it has been pre-assembled.
M8 Nylon
Locknut (38)–4
Console
Screw (59)–4
M8 x 19mm Button
Screw (56)–2
M8 x 45mm Button Bolt (50)–4
M10 x 74mm Bolt (7)–2
1. Identify the Front Stabilizer (10), which has round
Endcaps (21) on it. While another person lifts the front
of the Frame (1), attach the Front Stabilizer to the
Frame with two M10 x 75mm Carriage Bolts (34) and
two M10 Nylon Locknuts (33).
M10 Nylon M10 Split
Locknut (33)–6 Washer (45)–2
M10 x 27mm
Patch Screw (40)–2
.
Handlebar
Washer (55)–2
M10 x 27mm
Carriage Bolt (27)–2
M10 Bolt Set (25)–2
M10 x 75mm Carriage Bolt (34)–4
1
34
34
21
5
, an adjustable
M10
Washer (29)–2
Spring Bracket
Washer (35)–2
1
10
33
