English Important Safety Information These warnings are provided in the interest of safety. You read them carefully before installing MUST or using the appliance. • Under no circumstances should you attempt to repair About Installation, Cleaning the appliance yourself. Repairs carried out by and Manteinance unexperienced persons may cause injury or serious malfunctioning.
Contents For the Installer For the User Technical Data Important Safety Information Instruction for the Installer Instruction for the User Electrical connection Maintenance and Cleaning Adaptation to different types of gas Service and original spare parts Building In This appliance complies with the following E.E.C.
Maintenance and Cleaning Disconnect the appliance from the electrical supply, before carrying out any cleaning or manteinance work. Wash the enamelled components with warm soapy water. Never use abrasive cleaners Frequently wash the "caps" and the "crowns" with hot soapy water, carefully taking away any built-up of food. Carefully wash the stainless steel components with water, then wipe them dry with a soft cloth.
Periodic Maintenance Service and original spare parts This machine, before leaving the factory, has been Periodically ask your local Service Centre to check the tested and studied by many experts and specialists, in conditions of the gas supply pipe and the pressure order to give you the best results.
Instruction for the Installer The following instructions about installation and Gas Connection maintenance must be carried out by qualified personnel in compliance with the regulation in Choose fixed connections or use a flexible pipe in force. stainless steel. If using flexible metallic pipes, be careful they do not The appliance must be electrically disconnected come in contact with mobile parts or they are not before all interventions.
Electrical connection The appliance is designed to be connected to 230 V monophase electricity supply. The connection must be carried out in compliance with the laws and regulations in force. Before the appliance is connected: 1) check that the main fuse and the domestic installation can support the load (see the rating label);...
Adaptation to different types of gas Injectors replacement • Remove the pan supports. • Remove the burner's caps and crowns. • With a socket spanner 7 unscrew and remove the injectors (Fig. 7), and replace them with the ones required for the type of gas in use (see Table 2). •...
Building In Fig. 9 A = Auxiliary burner SR = Semi rapid burner R = Rapid Burner UR = Ultra rapid burner These hobs can be inserted in a built-in kitchen unit whose depth is between 550 and 600 mm. The hobs dimensions are shown in Fig.
Page 10
Installation and Assembly These hobs can be installed in a kitchen unit with an opening for insertion whose dimensions are shown in Fig. 10. The edge of the cut out must have a minimum distance from the rear wall of 55 mm. If there are side walls, or sides of the furniture unit near the hob, the cut out edges must have a minimum distance of 150 mm as shown in Fig.
Page 11
Possibilities for Fig. 13 Fig. 14 insertion Kitchen unit with door Proper arrangements must be taken in designing the forniture unit, in order to avoid any contact with the bottom of the hob which can be heated when it is operated. The recommended solution is shown in Fig.
