Summary of Contents for Zanussi ZGF 780 IT
- Page 1 Instruction booklet Gas hob ZGF 780 IT...
- Page 2 Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances.
-
Page 3: Table Of Contents
Step by step instructions for an operation Hints and Tips Environmental information This appliance is manufactured according to the following EEC directives: 2006/95 EEC - 2004/108 EEC - 90/396 EEC, current edition. MANUFACTURER : ELECTROLUX ITALIA S.p.A. C.so Lino Zanussi, 30 33080 Porcia (PN) - ITALY... -
Page 4: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 727 727. I I I I I nstallation nstallation nstallation nstallation nstallation This appliance must be installed and serviced by a competent person as stated in the Gas Safety (Installation and Use) Regulations Current Editions and the IEE Wiring Regulations. - Page 5 Ensure a good ventilation around the appliance. A poor air supply could cause lack of oxygen. When using the hob for a long period time, the ventilation should be improved, by opening a window or increasing the extractor speed. Do not use this hob if it is in contact with water. Do not operate the hob with wet hands.
-
Page 6: Description Of The Hob
Description of the Hob 1. Hob Top 2. Auxiliary Burner 3. Semi-rapid Burner 4. Rapid Burner 5. Triple Crown 6. Control knobs... -
Page 7: Instructions For The User
Instructions for the User INSTALLATION Any gas installation must be carried out by a registered competent person, and in accordance with existing rules and regulations. The relevant instructions are to be found in the second section of this manual. Please, ensure that, once the hob is installed, it is easily accessible for the engineer in the event of a breakdown. -
Page 8: Operation
Operation Operation Operation Operation Operation Hob burners control knobs Hob burners control knobs Hob burners control knobs Hob burners control knobs Hob burners control knobs The symbols on the knobs mean that : there is no gas supply (“off” position) there is maximum gas supply there is minimum gas supply Lighting the burners... - Page 9 Do not keep the control knob pressed for more than 15 seconds. If the burner does not light even after 15 seconds, release the control knob, turn it the "off" position and wait for at least 1 minute before trying to light the burner again. When switching on the mains, after installation or a power cut, it is quite normal for the spark generator to be activated automatically.
- Page 10 Carefully supervise cooking with fat or oil, since these types of foodstuff can result in a fire, if over-heated. The stainless steel can become tarnished if excessively heated. Therefore prolonged cooking with potstones, earthenware pans or cast-iron plates is inadvisable. Also, do not use aluminium foil to protect the top during use.
-
Page 11: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. This appliance cannot be cleaned with steam or with a steam cleaning machine. - Page 12 Pan Supports Pan Supports Pan Supports Pan Supports Pan Supports Wash the pan supports using hot soapy water. If necessary, a paste cleaner or a soap impregnated steelwool pad can be used with caution. The pan supports are not dishwasher proof;...
-
Page 13: Something Not Working
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. SYMPTOM SOLUTION There is no spark when Check that the unit is plugged lighting the gas. in and the electrical supply is switched on. -
Page 14: Engineer Technical Data
Instructions for the Installer Engineer technical data Engineer technical data Engineer technical data Engineer technical data Engineer technical data OVERALL DIMENSIONS Width: 744 mm Depth: 510 mm CUT OUT DIMENSIONS Width: 560 mm Depth: 480 mm SUPPLY CONNECTIONS Gas: R 1/2 inch (1/2 inch male) Rear right hand corner Electric: 230 V 50 Hz supply, 3 core flexible cable with... - Page 15 Gas burners Gas burners Gas burners Gas burners Gas burners BURNER RAPID SEMI-RAPID A U X I L I A R Y TRIPLECROWN TYPE OF GAS POSITION MAX MIN NOMINAL THERMAL POWER 0.75 0.45 0.33 NATURAL GAS 20 mbar NOMINAL FLOW VALUE = RATE 0.286 0.057...
-
Page 16: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S. - Page 17 Location Location Location Location Location The hob may be located in a kitchen, a kitchen/diner or bed sitting room, but not in a bathroom or shower room. Ensure that there is a minimum distance of 55 mm between the rear cut out edge and the wall.
-
Page 18: Installation
Installation IMPOR IMPOR T T T T T ANT IMPOR IMPOR IMPOR Any gas installation must be carried out by a GAS SAFE REGISTER installer. Please, ensure that, once the hob is installed, it is easily accessible for the engineer in the event of a breakdown. The manufacturer will not accept liability, should the above instructions or any of the other safety instructions incorporated in this instruction booklet be ignored. -
Page 19: Building In
Building In Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface. It is also recommended to carry out the electrical connection to the hob as shown in diagrams 1 and 2. -
Page 20: Fitting The Hob Into The Worktop
Fitting the Hob into the Worktop Carry out the building in of the hob as follows: • place the seals supplied with the hob on the front edge of the cut out. Then, place them at 86 mm from the side edges and at 10 mm from the rear edge, as shown in the diagram, taking care that the seals meet without overlapping. -
Page 21: Electrical Connections
Electrical Connections Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS HOB MUST BE EARTHED. Electrical Requirements Electrical Requirements Electrical Requirements Electrical Requirements Electrical Requirements Any permanent electrical installation must comply with the latest I.E.E. -
Page 22: Wiring Diagram
3) Connect the brown (live) wire to the terminal in the plug which is marked with the letter 'L' or coloured red. Upon completion there must be no cut, or stray strands of wire present and the cord clamp must be secure over the outer sheath. A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard. -
Page 23: Fault Finding
Fault Finding Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Blue Brown S T A R T S T A R T S T A R T S T A R T S T A R T Isolate appliance and carry out:... - Page 24 A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK Appliance must be electrically disconnected - meter set on W (Ohms) x 1 scale and adjust zero if necessary. — Test leads from any appliance earth point to earth pin on plug. Resistance should be less than 0.1 W (Ohm), check all earth wires for continuity and all contacts clean and tight.
- Page 25 Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse and Light burner manually replace if necessary Check polarity and Check by pass simmer...
-
Page 26: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. 1) Turn the gas tap to the MAX position and ignite. 2) Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 27: Conversion From Natural Gas To Lpg
Conversion from Natural Gas to LPG IMPORTANT The replacement/conversion from natural gas to LPG should only be undertaken by a competent person. It is important to note that this model is designed for use with natural gas but can be converted for use with butane or propane gas providing the correct injectors are fitted. - Page 28 39712-8001 04/09...
