SD-EX100H
1-BIT DIGITAL AUDIO SYSTEM
1
Accessories
Remote control
AM loop aerial
2
Battery installation of the remote control
Use 2 "AAA" size batteries (UM-4, R03, HP-16 or similar).
Remove the battery
1
cover.
TINSE0470AWZZ
SD-EX100H(E)_QG
"AAA" size battery
1
(UM-4, R03, HP-16 or similar)
1
Speaker wire
Insert the batteries
2
as shown.
1
This Quick Guide will help you to correctly install
and operate your system.
If you require any advice or assistance re-
garding your Sharp product, please visit
our web-site www.sharp.co.uk/support.
Customers without internet access may
telephone 08705 274277 during office
hours (or (01) 676 0648 if telephoning from
Ireland).
2
2
AC power lead
– 1 –
02.4.19, 5:17 PM
FM aerial
1
1
Speaker cushion
Replace the cover.
3
02D R HK 1
4
