Reset And Initialization - Mitsubishi Electric WD-60735 Service Manual

MODELS: WD-60735 / WD-60C8 / WD-65735 / WD-65736 / WD-65835 / WD-65C8 / WD-73735 /
Reset / Initialization
SERVICE TIP:
Many customer generated symptoms, intermittent symptoms or no symptom found can be resolved by using the
various Reset and Initialization options. Before visiting the customer's home ask the customer 1
Reset button on the control panel and if this does not resolve the issue, then they can perform an A/V Reset by
pressing the Guide + Format buttons on the front panel at the same time. Then, if necessary, perform a user level
Initialization by pressing MENU-123-ENTER with the remote. The customer should be made aware when settings
and/or options will be reset. For more information, see the chart below.
NOTE: During Initialization, the set will reboot. Wait until the Power
LED stops flashing before unplugging or powering ON the TV.
Reset Name When to use
Remote Returns the remote control TV
Control TV layer to normal operation.
Layer Reset
Remote Returns the volume and mute
Control TV functions of the remote control to
Volume/Mute TV volume and mute for TV,
functions Cabl e/Sat, VCR and DVD layers
after the Audio Lock for AV
Recei ver feature has been used.
A/V Memory When the audio and or video
Reset, by settings for a single input seems to
indi vidual input be incorrect.
A/V Reset, all To reset audio and video
inputs adjustments for all inputs to the
original factory setti ngs.
System Reset To reset the TV when it does not
turn on or off, does not respond to
the remote control, front panel
buttons or has other unusual
symptoms.
Initi alize User To reset al l customer settings
Level except V-Chi p
Initi alize - To reset al l customer settings
Service Level
V-Chip If V-Chip password is not known
Password
Bypass
Unlock Front To unlock the front panel if it has
Panel been locked in the V-Chip Menu.
WD-73736 / WD-73835 / WD-73C8
Reset / Initialization Guide
How to use
1) Set the slide switch to TV
2)
position.
2) Press and hold the POWER button until it flashes
3)
twice then releas e the button.
3)
Enter the code 0 0 9 3 5 .
1) (1) Set the slide switch to TV position.
2)
(2) Press and hold the POWER button until it
2)
flashes twice then release the button.
3)
(3) Enter the code 9 9 3 VOL UP .
MENU --> Audio/Video--> AV Reset
W hile viewing the TV, press the front panel buttons
GUIDE + FORMAT at the same time.
Press the SYSTEM RESET button on the front panel
with a pointed object such as a pencil or paperclip.
Press MENU - 123 - ENTER
MENU - 2470. Highlight INITIALIZE and press ENTER
Press QV + 9 at the same time.
Press and hold the front panel MENU button for 8
seconds.
Page 21
st
to try the System
Resulting Action
Once the valid code has
been entered and
confi rmed, the temot
contrrol has been reset.
The remote wil l now
operate the TV's volume
and mute when the slide
swi tch is in the TV,
CABLE/SAT, VCR or
DVD positions.
All Audio and Video
settings for the individual
input are reset except for
the Listen To, Language,
Bal ance and Closed
Caption settings.
All Audio and Video
settings are reset to the
factory default settings.
No other menu options
are changed.
TV Micro Re-boots. Note:
The changes made during
the current TV-On period
may be lost. All other
previous user settings are
not lost.
All customer menu
opti ons and A/V settings
except V-Chip are res et to
factory default.
All customer menu
opti ons and A/V settings
are reset to factory
default.
Pas sword will be
bypassed. If in the V-Chip
menu, enter a new
pas sword.
Front Panel becomes
operational. Other V-Chip
settings not changed.
Note: Cannot be
performed while in the
Low Power mode and the
set is Off.
