Operating Instructions
DVD/CD PLAYER
DVD-S1
Model No.
Dear customer
Thank you for purchasing this product. Before connecting, operating or adjusting this
product, please read the instructions completely. Please keep this manual for future
reference.
Region number
Asia
The player plays DVD-Video marked with
labels containing the region number "3" or
"ALL".
Others
The player plays DVD-Video marked with
labels containing the region number "2" or
"ALL".
EB
E
GCU
GCS
GCA
Example:
3
ALL
Example:
2
ALL
GC
Table of contents
Getting started
Accessories .................................................................................................2
Safety precautions ......................................................................................2
Caution for AC Mains Lead .........................................................................3
Discs that can be played .............................................................................5
STEP 1 Connection to a television ............................................................6
STEP 2 The remote control .........................................................................7
Operations
Basic play .....................................................................................................8
Playing MP3/JPEG discs .............................................................................9
Convenient functions ................................................................................10
Skipping about 30 seconds forward/Zoom/Enjoying advanced surround ................ 10
Changing the play sequences ..................................................................11
Program play/Random play ...................................................................................... 11
Using On-Screen Menus ...........................................................................12
On-Screen Menu 1 ................................................................................................... 12
On-Screen Menu 2 ................................................................................................... 13
Changing the player settings ...................................................................14
Reference
Tips for making data discs .......................................................................16
1
Troubleshooting guide ..............................................................................17
3
4
Maintenance .............................................................................................. 19
Specifications ........................................................................................... 19
Main feature index ..................................................................... Back cover
1
2
Unless otherwise indicated, illustrations in these operating instructions are the
4
models for the United Kingdom and Continental Europe.
Note
"EB" on the packaging indicates the United Kingdom.
RQTC0077-B
