Quick Reference
Konica 7013
Sending a fax using the ADF . . . . . . . . . . .. . . . . . . . . page
Sending a fax using the platen glass . . . . . . . . . .. . . . page
Broadcast . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . page
Cancel sending a fax . . . . . . . . . . . .. . . . . . . . . . . . . . . page
Basic copy . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . page
Sort copy . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . page
Enlarged/Reduced copy . . . . . . . . . . . .. . . . . . . . . . . . . page
Using the Bypass tray . . . . . . . . . . . .. . . . . . . . . . . . . page
Clearing original document jams . . . . . . . . . . .. . . . . page
Clearing printout jams . . . . . . . . . . . .. . . . . . . . . . . . . page
. . . . . . . . . . . .. . . . . . . . . . . page
2
3
4
5
6
7
8
10
12
14
16

Advertisement

Table of Contents
loading

Related Manuals for Konica Minolta 7013

Summary of Contents for Konica Minolta 7013

  • Page 1: Table Of Contents

    Quick Reference Konica 7013 Sending a fax Sending a fax using the ADF ....page Sending a fax using the platen glass ....page Broadcast .

  • Page 2: Sending A Fax

    Sending a fax Sending a fax using the ADF You can set up to 50 sheets of A4, A5 or F4 sized documents in the ADF at one time. Set the document in the Press to change COPY ADF face up and adjust to Fax mode.

  • Page 3: Sending A Fax Using The Platen Glass

    Sending a fax using the platen glass Place the document on the platen Press to change COPY glass face down and align it to the to Fax mode. right front corner. Close the platen cover. Open the platen cover. For ways to enter the fax number, refer to step 3 on page 2.

  • Page 4: Broadcast

    Broadcast Enter the fax number using the numeric keypad. Press the one-touch key*1 Press to change COPY Press and enter the three-digit identifier for to Fax mode. SPEED DIAL TEL INDEX the speed-dial number using the numeric keypad. *1: When you press a one-touch key, you do not need to press START Press Enter the fax number.

  • Page 5: Cancel Sending A Fax

    Cancel sending a fax Press to see the individual numbers within the broadcast. Press COMM CANCEL CONFIRM Press until you find the number you want to cancel. If you want to cancel the command Press to scroll through shown, press CANCEL CANCEL currently stored commands.

  • Page 6: Making A Copy

    Making a copy Basic copy Helpful Tip If you want to stop copying, press STOP Press to clear COPY RESET Press to change the previously entered copy COPY settings. to Copy mode. Adjust the following, Enter the number of Set the document in the if necessary.

  • Page 7: Sort Copy

    Sort copy Sort: Press to change Non-sort: COPY to Copy mode. Press to turn the Set the document in SORT Enter the number of sort setting to on or off. the ADF face up. copies using the numeric keypad. When the sort setting is On, the LED Adjust resolution and contrast, glows.

  • Page 8: Enlarged/Reduced Copy

    Enlarged/Reduced copy If you want enlarged copies, use the platen glass. Fixed ratio Choose the desired ratio by using or of the cursor key. Set the document in the ADF or on the platen glass. You can choose from: Adjust the document type and the •...
  • Page 9 Adjust by 1 percent increments Press to turn the light on. ZOOM ZOOM Adjust the ratio by 1 percent increments using or of the cursor key. You can set the ratio between 50% and 200%. Enter the number of copies using the numeric keypad.

  • Page 10: Using The Bypass Tray

    Using the Bypass tray Press to change Set the document in the ADF face up, COPY to Copy mode. or on the platen glass face down. Place the paper on the bypass tray Open the bypass tray on the right side face down.
  • Page 11 Helpful Tip If you want to change the default paper size for The LCD will show the default the bypass tray: paper size for the bypass tray. 1. Press Program key, , 1, 0, 1, ENTER 2. Press until “Bypass Tray” appears. ENTER 3.

  • Page 12: Just In Case

    Just in case Clearing original document jams In this step, if more than 60 seconds passes without pressing any keys, the machine will begin to send or copy the document(s) stored during this operation. Reset the document from Document Jam the jammed page and Contstor Enter/Cancl press...

  • Page 13: To Remove The Document

    To remove the document... Open the scanner cover. Open the inner cover. Remove the original document. Remove the original document. If you cannot remove it, go to step 2. Otherwise, skip to step 3. Gently close the scanner cover. Make sure both sides are If the document has become wrinkled or snapped down securely.

  • Page 14: Clearing Printout Jams

    Clearing printout jams CAUTION Shield the drum cartridge from light, especially strong light. CAUTION Remove the toner and Be careful not to put your hand between drum cartridge. the top cover and the machine. Pull up the top cover release and open the top cover.
  • Page 15 CAUTION The fuser unit becomes very hot. Do not touch the fuser unit when you are removing jammed paper. Remove the jammed paper. Reset the toner and drum cartridge. Open the side cover. Pull up the jam release lever to remove the jammed paper.

  • Page 16: Function Table

    For example, if you want to enter a Speed-Dial, press Program key, , , , ENTER Note: “Page” in the rightest column in this table means the pages in the Konica 7013 Operating Instructions. Level one function...
  • Page 17 Level one function Level two function Level three function Summary of setting Default setting Page B. User Settings 2.Fax Settings 01.Scan Parameters You can set the following settings for send fax message. • Primary resolution mode Normal • Primary contrast mode Normal 02.Print Parameter You can set the following settings for receive fax message.
  • Page 18 Level one function Level two function Level three function Summary of setting Default setting Page B. User Settings 5.Scanner Settings* 01.Scan Parameter Enter the scanning parameters. — — 02.Scan Size Set the scanning size. — — 03.Auto Reset Set the time (minutes) resetting the scan parameters. —...
  • Page 19 Level one function Level two function Level three function Summary of setting Default setting Page E. Print 1.List Print 01.Machine Settings Print a list of your machine settings. — 4.10 02.Fax Settings Print a list of the fax settings. — 4.10 03.Copy Settings Print a list of the copy settings.
  • Page 20 Konica Business Machines Deutschland GmbH Lilienthalstrasse 1, D-21337 Luneburg (Germany) Tel: (+49) 4131-886-320 Fax: (+49) 4131-886-307 D88-90320-60...
