Appendix C: Specifications

General
Standards
Protocols
Ports
Cabling Type
LEDs
Safety & Emissions
Wireless
Frequency Band*
Radio Data Rate
Frequency Expansion
Modulation
Security
Sensitivity @PER
Environmental and Physical
Temperature
Humidity
* Only 2.412GHz~2.462GHz is allowed to be used in USA, which means only channel 1~11 is available for
American users to choose.
Archer C7
IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE
802.11a, IEEE 802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X,
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
1 10/100/1000M Auto-Negotiation Internet RJ45 port;
4 10/100/1000M Auto-Negotiation Ethernet RJ45 ports supporting
Auto MDI/MDIX;
2 USB ports supporting storage/FTP/Media/Print Server;
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Power, System, Wireless 2.4GHz, Wireless 5GHz, Ethernet (1-4),
Internet, WPS
FCC, CE
2.4GHz, 5GHz
11b: 1/2/5.5/11Mbps
11a/g: 6/9/12/18/24/36/48/54/Mbps
11n: 45/90/135/180/270/360/405/450Mbps
11ac: up to 1.3Gbps
DSSS (Direct Sequence Spread Spectrum)
11ac: 256-QAM for OFDM
11n/g/a: QPSK,BPSK,16-QAM, 64-QAM for OFDM
11b: CCK,DQPSK,DBPSK
WEP, WPA/WPA2, WPA2-PSK/WPA-PSK
5G：
11a 6Mbps：-96dBm
11a 54Mbps：-79dBm
11ac HT20：-71dBm
11ac HT40：-66dBm
11ac HT80：-63dBm
Operating: 0℃~40℃ (32℉~104℉)
Storage: -40℃~70℃ (-40℉~158℉)
Operating: 10% - 90% RH, Non-condensing
Storage: 5% - 90% RH, Non-condensing
- 134 -
AC1750 Wireless Dual Band Gigabit Router
2.4G：
11g 54M：-77dBm
11n HT20：-74dmB
11n HT40：-72dBm
