Oregon Scientific BAA913HG User Manual

Digital weather forecaster with in-out thermo-hygrometer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
DIGITAL WEATHER FORECASTER
WITH IN-OUT
THERMO-HYGROMETER
MODEL : BAA913HG
USER'S MANUAL
INTRODUCTION
Congratulations on your purchase of the BAA913HG Digital
Weather Forecaster with In-Out Thermo-Hygrometer.The
BAA913HG is an all-in-one weather forecasting device and clock.
The BAA913HG, a weather forecasting device, has several weather
related functions. A main feature is that it takes and records
temperatures and humidities in more than one location. Using a
wireless remote thermo-hygro sensor, it can simultaneously monitor
temperatures and humidities in three remote locations. The unit
will show temperature and humidity trends as well as record
maximum and minimum temperature and humidity readings.
BAA913HG is able to receive and display readings from up to 3
remote sensors.
As part of the weather forecasting function, the unit has a built-in
barometer that displays atmospheric pressure.
graphics, the unit displays atmospheric pressure trends and
displays forecasts as sunny, partly cloudy, rainy and snowy.
913hg-e.p65
Other features of the BAA913HG include backlight, extra-large
liquid crystal display (LCD) and a daily crescendo alarm with an
eight minute snooze function.
No wire installation is required between the main and remote units
as the BAA913HG operates at 433 MHz.
A
A1
A3
A4
A5
B3
B4
Using animated
B5
1
1
MAIN FEATURES: MAIN UNIT
B7
B6
B8
Hr
04/30/2002, 5:59 PM
A2
B2
B1

Advertisement

Table of Contents
loading

Related Manuals for Oregon Scientific BAA913HG

Summary of Contents for Oregon Scientific BAA913HG

  • Page 1 BAA913HG is able to receive and display readings from up to 3 remote sensors. As part of the weather forecasting function, the unit has a built-in barometer that displays atmospheric pressure.

  • Page 2: Mode Button

    FRONT DISPLAY CONTROL BUTTONS The LCD is divided into five easy-to-read sections. Each CHANNEL CHANNEL CHANNEL CHANNEL] BUTTON B1. [CHANNEL section has a specific purpose that relates to weather Displays the temperature and humidity readings of the indoor forecasting, temperature, humidity, pressure and clock / or remote sensor calendar / alarm functions.

  • Page 3: Features: Remote Thermo-Hygro Sensor

    BACK PANEL FEATURES: REMOTE THERMO-HYGRO SENSOR C1. BATTERY COMPARTMENT Accommodates four UM-3 or “AA” size batteries C2. mb / hPa - inHg SLIDE SWITCH Selects between "mb / hPa" or "inHg" pressure unit display C3. RESET SLOT Resets the unit by returning all settings to their default values C4.

  • Page 4: Battery Installation: Main Unit

    TWO-LINE LCD BATTERY INSTALLATION: MAIN UNIT Displays the current temperature and humidity monitored by the remote unit 1. Gently lift the tab on the battery compartment door. LED INDICATOR 2. Insert four UM-3 or “AA” size batteries. Flashes when the remote unit transmits a reading °C/°F SLIDE SWITCH Selects between Centigrade (°C) and Fahrenheit (°F) CHANNEL SLIDE SWITCH...

  • Page 5: How To Set The Clock

    Press MODE again, the minute will flash. Again, use the UP(+) or DOWN(-) button to change the minutes. Note: When changes are made to this setting, the seconds will start from zero. Press MODE again, the calendar settings are displayed and the year is flashing.

  • Page 6: Alarm And Snooze Function

    HOW TO SET AND ACTIVATE THE PRE-ALARM FUNCTION FOR CHANNEL ALARM 1 REMOTE SENSOR To set the Alarm The alarm function also has a pre-alarm feature which can alert the AL AL AL AL / Press [AL ] button to display the daily alarm time (the icon "AL" user before their preset alarm time if weather conditions changes.

  • Page 7: Note On Remote Readings

    If that fails, check that the remote sensor is still in place. Make sure Note: The daily alarm will NOT function until the next day if the the transmission is within range and the path is clear of obstacles pre-alarm has been triggered beforehand. Deactivation of the alarm and interference.

  • Page 8: Temperature & Humidity Trend

    TEMPERATURE & HUMIDITY TREND WEATHER FORECAST The temperature and humidity trend indicator shows the trend of The unit is capable of detecting atmospheric pressure changes. temperatures and humidities collected at that particular sensor. Based on collected data, it can predict the weather for the forthcoming Three trends: rising, steady, and falling will be shown.

  • Page 9: Low Battery Indication

    The atmospheric pressure can be displayed in mb/hPa or inHg. The Indicator Shows that the Temperature Humidity pressure unit is selected on the atmospheric pressure slide switch displays Current Range Range inside the battery compartment. on the unit Environment If you want to check the pressure history for a particular hour Ideal range for during the past 24 hours, press the [HISTORY] button.

  • Page 10: How To Wall Mount Or Use The Table Stand (Main Unit)

    MAINTENANCE HOW TO WALL MOUNT OR USE THE TABLE STAND (MAIN UNIT) When handled properly, this unit is engineered to give you years of satisfactory service. Here are a few product care instructions: The unit can be wall-mounted using its recessed screw holes or 1.
  • Page 11 - Power Relative Humidity measurement Main unit : use four (4) UM-3 or “AA” Measuring Range : 25% RH to 95% RH at 25°C (77°F) 1.5V batteries Resolution : 1% RH Remote sensing unit : use two (2) UM-4 or “AAA” 1.5V batteries Remote unit Temperature measurement...

  • Page 12: Ec Declaration Of Conformity

    VS-Villingen / Germany August 2001 EC-DECLARATION OF CONFORMITY Gerhard Preis This product contains the approved transmitter module TX 01 and R&TTE Representative of manufacturer complies with the essential requirements of Article 3 of the R&TTE 1999/5/EC Directives, if used for its intended use and that the following standard(s) has/have been applied: Efficient use of radio frequency spectrum RTTE Compliant Countries :...
