INTRODUCTION
Congratulations on your purchase of the BAA928U Top Weather
Station. The BAA928U is all all-in-one weather device and clock.
The BAA928U, a weather forecasting device, and has several weather
related functions. One function is that it takes and records tempera-
tures. Using the remote thermo-sensor, included with your pur-
chase, the unit can simultaneously monitor two temperature read-
ings. The unit will show temperature trends and record maximum
and minimum temperature readings.
Another weather function is the humidity readings. It shows the
indoor relative humidity and rates the comfort level. It can retain
the maximum and minimum relative humidity readings.
A built-in barometer displays the atmospheric pressure with a user-
select altitude adjustment. A bar graph shows the pressure trend for
the last 24 hours.
The unit includes a moon phase scanner. This feature graphically
illustrates the current moon phase and lets you check the moon
phase of any date between 1990 and 2089.
Other features of the BAA928U include a clock and calendar, HiGlo
backlight, extra-large liquid crystal display (LCD), and a daily
crescendo alarm with an eight minute snooze function.
No wire installation is required between the main and remote units.
As the BAA928U operates at 418 MHz, it can be used in the USA and
most places in Continental Europe.
MAIN FEATURES : MAIN UNIT
LEFT PANEL AND DISPLAY
The extra-large LCD occupies the left panel. The LCD is sub-
divided into seven easy-to-read sections. Each section has
specific purposes that relate to weather functions, or clock/
calendar functions.
WEATHER FORECAST WINDOW
Graphically illustrates a weather forecast
MAIN UNIT BATTERY LOW (
Lights up and blinks when batteries of the main unit are low
REMOTE BATTERY LOW (
Lights up and blinks when the batteries of the remote unit are
low
TEMPERATURE WINDOW
Shows current temperatures, minimum/maximum temperatures,
temperature readings from the remote sensor, and temperature
trends
TEMPERATURE TREND ARROWS
Indicates the trend of temperature changes
IN/OUT REMOTE INDICATOR
Indicates if the current temperature is displayed as indoors or
outdoor-remote
TOP WEATHER STATION
MODEL: BAA928U
USER'S MANUAL
) INDICATOR
) INDICATOR
RELATIVE HUMIDITY WINDOW
Displays the indoor relative humidity
COMFORT INDICATOR
Indicates the comfort level of the indoor relative humidity
ATMOSPHERIC PRESSURE BAR GRAPH
Indicates the atmospheric pressure for the latest 24 hour period
ATMOSPHERIC PRESSURE WINDOW
Displays the current atmospheric readings
PRESSURE HISTORY INDICATOR
Indicates the pressure history of previous hours
MOON PHASE SCANNER
Graphically illustrates the phases of the, and moon
phases for other specified dates
