- Page 1 Handleiding_Studio_Final01.fm Page 1 Tuesday, April 19, 2005 10:14 AM SER MANUAL OHANNUS TUDIO...
- Page 2 All rights reserved. Nothing in this publication may be reproduced, stored in a data file or made public in any form or in any way either electronically, mechanically by way of photocopying, recording or in any other way without the prior written permission of Johannus Orgelbouw b.v.
-
Page 3: Table Of Contents
Handleiding_Studio_Final01.fm Page 3 Tuesday, April 19, 2005 10:14 AM ABLE OF CONTENTS SAFETY ........... . 5 Safety precautions . - Page 4 Handleiding_Studio_Final01.fm Page 4 Tuesday, April 19, 2005 10:14 AM...
-
Page 5: Safety
Keep this user manual with the organ. The organ may only be opened by a technician authorised by Johannus Orgelbouw b.v. The organ contains static-sensitive components. The warranty is void if the organ is opened by a non-authorised person. -
Page 6: Installation
Handleiding_Studio_Final01.fm Page 6 Tuesday, April 19, 2005 10:14 AM NSTALLATION Placement and connection 1. Place the organ on a stable, horizontal surface. 2. Lean the organ slightly backward. 3. Slide the pedal (A) against the pedalboard (B). 4. Set the organ upright. 5. -
Page 7: Switching On
Handleiding_Studio_Final01.fm Page 7 Tuesday, April 19, 2005 10:14 AM Switching on 1. Switch on the organ with the on/off button at the right, next to the manuals. The lamps of the on/off, 0 and SET buttons go on. 2. Wait several seconds. Starting the control functions and the settings takes a little time. -
Page 8: Description Of The Organ
Handleiding_Studio_Final01.fm Page 8 Tuesday, April 19, 2005 10:14 AM ESCRIPTION OF THE ORGAN Overview of the main components Stops Pedalboard Music desk Expression pedal Manuals Loudspeakers Organ bench... -
Page 9: Overview Of Controls
Handleiding_Studio_Final01.fm Page 9 Tuesday, April 19, 2005 10:14 AM Overview of controls AKOESTIEK VOLUME 3D SURROUND MF FF FF M1 M1 M2 M2 M3 TRANS TUNE FF FF TUNE TRANS Acoustic volume 0-button or reset button Accessories Manual Bass Pedal stops Transposer Great stops TUNE... -
Page 10: Operation
Handleiding_Studio_Final01.fm Page 10 Tuesday, April 19, 2005 10:14 AM PERATION Volume adjustment You can set various volume adjustments: Volume control: Adjusts the volume of the complete organ. Expression pedal: Adjusts the volume of the swell, independent of the volume of the complete organ. Acoustic volume: Activates and adjusts the length of the spatial reproduction. -
Page 11: Couplers
Handleiding_Studio_Final01.fm Page 11 Tuesday, April 19, 2005 10:14 AM Couplers Manual coupler: Couples all of the keys for the swell stops to the great stops. Use the accessory Swell organ - Great organ to activate the Manual coupler. Pedal coupler: Couples all of the keys for the great stops or the swell stops to the pedal. -
Page 12: Tune
Handleiding_Studio_Final01.fm Page 12 Tuesday, April 19, 2005 10:14 AM 4.6.1 Tune Checking the pitch 1. Press the TUNE button. The lighted button (P through 0) indicates the pitch. The light in the TUNE button must remain lit while the pitch programming is changed. -
Page 13: Stop Memory
Handleiding_Studio_Final01.fm Page 13 Tuesday, April 19, 2005 10:14 AM Changing the pitch 1. Press the TRANS button. 2. Press the button (P through 0) for the desired pitch shift. 3. Wait until the lights in the TRANS button and the P through 0 buttons go out. -
Page 14: Capture Memory Location
Handleiding_Studio_Final01.fm Page 14 Tuesday, April 19, 2005 10:14 AM Programming a fixed memory location The current setting of the fixed memory location will be lost. 1. Select the desired stops. 2. Push in the SET button. Hold in the button. 3. -
Page 15: Factory Intonation
1. Connect a PC to the organ. Use the MIDI connection. See § 2.3. 2. Save the intonation settings on the PC using the intonation program from Johannus. Restoring the factory intonation The current intonation settings will be lost if the settings are not saved on a PC. -
Page 16: Maintenance, Problems And Warranty
Handleiding_Studio_Final01.fm Page 16 Tuesday, April 19, 2005 10:14 AM AINTENANCE PROBLEMS AND WARRANTY Maintenance Overview Component Maintenance Frequency Cabinet Cleaning. See § 5.1.1. As required Manuals Cleaning and removing scratches. As required See § 5.1.2. 5.1.1 Cabinet maintenance The cabinet is made of solid wood and wood veneer. Do not use furniture polish or teak oil to clean the organ cabinet. -
Page 17: Problems
6. Contact your dealer if the pedalboard does not work properly. Warranty The conditions are specified in the warranty certificate. The warranty is void if changes or repairs are made to the organ by persons or organisations that are not authorised by Johannus Orgelbouw b.v. - Page 18 Handleiding_Studio_Final01.fm Page 18 Tuesday, April 19, 2005 10:14 AM...
-
Page 19: Index
