Haier XQG50-11 User Manual

Haier XQG50-11 User Manual

Front load clothes washer & dryer combo
Hide thumbs Also See for XQG50-11:
Table of Contents

Advertisement

Quick Links

See also: Use and Care Manual , User Manual
XQG50-11 Manual
10/29/02
User Manual-
Guide de l'Utilisateur-
Manual del Usuario-
1:51 PM
Page 2
What The World Comes Home To
WATER
NO
XQG50-11
ON/OFF
SAVER
SPIN
Lave-Linge Sechant a
Lavadora y Secadora
Model #
Modèle
Modelo #
®
TM
Front Load
Clothes Washer &
Dryer Combo
Chargement Frontal
de Carga Frontal
XQG50-11

Advertisement

Table of Contents
loading

Related Manuals for Haier XQG50-11

Summary of Contents for Haier XQG50-11

  • Page 1 XQG50-11 Manual 10/29/02 1:51 PM What The World Comes Home To WATER XQG50-11 SAVER SPIN User Manual- Guide de l’Utilisateur- Manual del Usuario- Page 2 Clothes Washer & Dryer Combo ON/OFF Lave-Linge Sechant a Chargement Frontal Lavadora y Secadora de Carga Frontal Model # Modèle...

  • Page 2: Safety Instructions

    XQG50-11 Manual 10/29/02 1:51 PM English IMPORTANT SAFETY INSTRUCTIONS Warning – To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using the appliance.

  • Page 3: Save These Instructions

    XQG50-11 Manual 10/29/02 1:51 PM 20. This appliance must be connected to proper electrical outlet with the correct electrical supply. 21. Proper grounding must be ensured to reduce the risk of shock and fire. DO NOT CUT OR REMOVE THE GROUNDING PLUG. If you do not have a three-prong electric receptacle outlet in the wall, have a certified electrician install the proper receptacle.
  • Page 4 Risk of child entrapment. Before you throw away your old appliance, take off the door so that children may not easily get trapped inside. Thank you for purchasing our Haier product. This easy-to-use manual will guide you in getting the best use of your washer &...

  • Page 5: Table Of Contents

    XQG50-11 Manual 10/29/02 1:51 PM Table Of Contents SAFETY INSTRUCTIONS ...1 OPERATING INSTRUCTIONS ...4 Parts and Features...5 Operations ...7 Normal Operating Sounds...16 Care and Cleaning Guide ...16 Cleaning and Maintenance ...16 Moving and Vacationing ...17 Storage of Your Washer ...17 Troubleshooting...18...

  • Page 6: Operating Instructions

    XQG50-11 Manual 10/29/02 1:51 PM English OPERATING INSTRUCTIONS Parts and Features 1. Wash Cycle Selector Knob 2. Dry Cycle Select Knob 3. Power "On" Indicator Light 4. Power "On/OFF" Button 5. No Spin Selector Button 6. Water Saver Button Page 7 ®...

  • Page 7: Xqg50-11 Manual 10/29/02 1:51 Pm

    XQG50-11 Manual 10/29/02 1:51 PM Page 8 English 1. Water Inlets (Hot/Cold) 2. Power Cord (115 V / 60 Hz) 3. Drain Hose 4. Rear Adjustable Leveling Legs 5. "U" Clamp 6. Hose Retainer Clips...

  • Page 8: Operations

    Here there is no agitator to damage your clothes. Since there is no agitator in this style of washer, the washer runs quietly. This style of washer saves you money as it uses less water and detergent to clean your laundry.
  • Page 9 XQG50-11 Manual 10/29/02 1:51 PM Wash Cycle Wool Sottening Rinse Delicate Dry/Off spin Softening Rinse Synthetic Turn the knob CLOCKWISE only to your desired setting when selecting the cycle. Cotton Cycle 1-Pre-wash 2-Intense 3-Normal 4-Delicate 5-Rinse 6-Softening 7-Spin 8-Dry/Off Below is the cycle reference chart for your clothes.
  • Page 10 XQG50-11 Manual 10/29/02 1:51 PM English Cotton Cycle: Pre-Wash Cycle: The purpose of this cycle is that if you want to pre-wash heavily soiled clothes before the actual wash cycle begins. This cycle is configured in such a manner that it will go through Intense mode and then the rinse and spin cycles automatically to complete the wash.
  • Page 11 XQG50-11 Manual 10/29/02 1:51 PM Wool Cycle: Delicate Wash Cycle: This cycle is used for delicate fabrics that are often washed by hand. This cycle is approximately 32 minutes. • After the wash position of the cycle is complete (at "Soak" indication on control panel) the machine will stop.
  • Page 12 XQG50-11 Manual 10/29/02 1:51 PM English Temperature The water temperature is preset so when you select wash cycle it will set the proper temperature for that wash load. Please see the chart below to understand the proper temperature for each cycle:...

  • Page 13: Proper Use Of Dispenser

    1:51 PM Proper Use of Dispenser: The detergent/softener dispenser is located on the upper left corner of the washer. Open the dispenser by pulling it out. You will see that there are four compartments. "1" Compartment: This is used for liquid detergent for pre-wash. This is used when you want to pre-wash heavily soiled dirty clothes before going to actual wash cycle.

  • Page 14: Proper Use Of Detergent

    Note: The drying operation of this unit is different then other dryers you may have used in the past. Large household and laundromat dryer operate on 220 volt which supply more elctricity and allows faster drying time. Your washer & dryer combo unit operates on 115 volts; which supply less electricity, resulting in longer drying time.
  • Page 15 XQG50-11 Manual 10/29/02 1:51 PM Note: For full loads, you may want to remove remaining clothes seperately. This will be an efficient way to dry your clothes and will not take as long to dry. For less than full loads, you may want to reduce drying time.
  • Page 16 XQG50-11 Manual 10/29/02 1:51 PM English Button Trap • Button Trap is designed to collect small objects such as button, coins, etc. As this may happen very rarely, we recommend to check trap no more than twice a year. • Button trap is located on the bottom front right corner behind the small door cover.

  • Page 17: Normal Operating Sounds

    • Remove pins or other sharp objects from clothes to prevent scratching of the interior parts. • You should check the button trap at least twice a year. Do not use the washer without the button trap in place. • The Detergent Dispenser Compartment is removable. Over time, this compartment may accumulate dried detergent, dirt and debris.

  • Page 18: Moving And Vacationing

    • Disconnect electrical plug. • Dry inner wash tub. If moving washer, disconnect drain hose. • Turn the leveling legs clockwise all the way in. • Reinstall both shipping bolts and metal brackets in the back to prevent internal part from shaking when appliance is moving to another location.

  • Page 19: Troubleshooting

    • Check if the control knob is set properly. You may have to adjust the control knob. • The washer pauses in some cycles. This is normal in cycle, which has short soak period where your clothes are being soaked for very short period of time. You will not hear washer operation for a short period of time.

  • Page 20: Washer Is Making Noise

    Washer is making noise: • Washer may need to be reinstalled. (Check washer installation section) • Washer load may need to be re-balanced, as the load may be uneven. • Coins, loose change, buttons or other heavy objects could make noise (read Operating Guide –...
  • Page 21 XQG50-11 Manual 10/29/02 1:51 PM Dryer is working but not drying the clothes: • Unit may be over loaded. The dryer drum should only be half full. • Dryer load needs to be resorted. Heavy clothes may need to be separated from regular clothes.

  • Page 22: Installation Instructions

    XQG50-11 Manual 10/29/02 1:51 PM English INSTALLATION INSTRUCTIONS Tools and Materials Required You will need to have following tools to help you in the installation of your Washer: • Scissors • Phillips Screwdriver • Standard Screwdriver • Pliers • Wrench •...

  • Page 23: Unpacking Your Washer

    XQG50-11 Manual 10/29/02 1:52 PM Unpacking Your Appliance • Remove all packing materials including transportation bolts and brackets. Also remove adhesive tape holding the accessories inside and outside. • Inspect and remove any remains of packing, tape or printed materials before using the washer.

  • Page 24: Leveling Your Washer

    1. Insert a new flat washer into each end of the inlet hoses. Firmly put the washers in the coupling. Note: You may have to use pliers to tighten the coupling. Do not over tighten because you may cause damage to the valve.
  • Page 25 2. Connect the hot and cold water inlet hoses to the hot and cold water faucets respectively. 3. Connect the other end to their respective washer inlet located at the rear. Note: Hot water needs to be at a temperature of at least 120˚F – 140˚F.

  • Page 26: Unit Dimensions

    Note: Inspect carefully for any leaks around and back of the machine. If leak occurs, double check to see if any connections are loose. You may need to tighten any loose connections. 5. Plug in the Washer to a regular 115 volt / 60 Hz, 15 amp outlet. Unit Dimensions Page 27...

  • Page 27: Electrical Connections

    XQG50-11 Manual 10/29/02 1:52 PM Electrical Connections Grounding Instructions This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounded plug.

  • Page 28: Warranty

    Limited Warranty After one year from the original retail purchase date, Haier will provide a part at no cost, as indicated below, to replace said part as a result of a defect in materials or workmanship.
  • Page 29 10/29/02 1:51 PM IMPORTANT Do Not Return This Product To The Store If you have a problem with this product, please contact the "Haier Customer Satisfaction Center" at 1-877-337-3639. DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE IMPORTANT Ne pas Réexpédier ce Produit au Magasin Pour tout problème concernant ce produit, veuillez contacter le service des...
