Table of Contents
Before using
Names of Parts--------inside front cover
Matters Needing Attention------------1-3
Installation--------------------------------4-5
Control Panel-------------------------------6
Operational Functions----------------6-7
During using
Program Selection------------------------8
Preparation---------------------------------9
Washing Methods--------------------10-11
Maintenance
Maintenance -----------------------------12
Trouble Shooting------------------------13
Technical Specification----------------14
Wiring Circuit-----------------------------15
Advertisement
Related Manuals for Haier XQG50-600SW
Summary of Contents for Haier XQG50-600SW
-
Page 1: Table Of Contents
XQG50-600TXB XQG50-600SW Automatic Drum Washing Machine 0020502333 Table of Contents Before using Names of Parts--------inside front cover Matters Needing Attention------------1-3 Installation--------------------------------4-5 Control Panel-------------------------------6 Operational Functions----------------6-7 During using Program Selection------------------------8 Preparation---------------------------------9 Washing Methods--------------------10-11 Maintenance Maintenance -----------------------------12 Trouble Shooting------------------------13 Technical Specification----------------14 Wiring Circuit-----------------------------15... -
Page 2: Names Of Parts
Names of Parts Detergent distributor Door Porthole Power supply cable Earth terminal Back plate screw (3) Drainage hose Caution and Warning symbols For your safety, any instructions in this manual with this “Warning” sign shall be strictly followed. For your safety and to prevent damages to the washing machine, any instructions in this manual with this “Stop”... -
Page 3: Matters Needing Attention
4. For your safety, dry hands before touch- for 15A. Refer to a washing machine techni- ing the washing machine and wear appropri- cian or a Haier designated service point for ate footwear . power cable replacement. 5. Do not use flammable detergent or dry 6. - Page 4 Matters Needing Attention 9. The washing machine should be place in 8. The washing machine must not be used in a well ventilated area maintaing a space the open or in area of high moisture as water between walls or furniture. droplets may form on electrical components, Air dry the appliance if the washing machine components become wet.
- Page 5 Technical Specification Model Item XQG50-600TXB/XQG50-600SW Power supply Maximum working current Water pressure (MPa) Washing power Spinning power Max. washing load (kg) Spinning speed (r/min) Washing program Heating power Size (HXDXW) (mm) Weight (kg) Matters Needing Attention 3. Never place heavy objects ,a heating applianceor a water container on the top panel of the washing machine.
-
Page 6: Installation
Model XQG50-600TXB XQG50-600SW ==Remove the packing screws as shown in figure 2. The packing bolts protect the appliance from shock during trans- portation The steps below should be followed before using the appliance, 1. Remove the rear panel of the washing machine;... - Page 7 The power supply socket and the plug of the washing machine compatible,if they are not com- patible ,Refer to a washing machine technician or a Haier designated service point for power cable replacement.The washing machine should be connected to an earth before use.
-
Page 8: Control Panel
Select function buttons as required (refer to the directions printed on the control panel) , otherwise keep all the button released. 6. Washing XQG50-600SW Press the power button and the washing machine will automatically commence the pro- grammed washing process. -
Page 9: Operational Functions
Washing Methods 1. Laundry loading Reference loading Evenly load the laundry in the = Overalls washing machine and then tightly (cotton 950g) close the door of the washing machine =Blended Note: 1) When first using the fabric clothes washing machine, let it run un- (800g) loaded for one program to pre- =shirt... -
Page 10: Program Selection
Program Selection NOTE: ” o ”means softener liquid detergent canbe added when necessary. “ ”means detergent can be added when necessary. “ ”means no detergent can be added. Preparation 2. Water supply 1. Power supply Turn on the tap ensure that the water is clear. Plug in the power supply Caution: Before staring the washing machine turn on the 220V~/50Hz.
