Trouble-shooting
If the laundries fall to the outer side of the spin tub
If the laundries fall to the outer side of the spin tub,
Please contact the after-sales service department.
(If there's breakdown, please pull off the power plug before checking) The following
phenomena are not breakdowns sometimes. Please confirm again before sending
it to repair. If there are real breakdowns, please come to the special maintenance
department or after-sale service department of our company. Do not repair it by yourself.
The reason
Phenomena
Is there power failure?
Is the power plug loose?
The machine does
Is the pulsator twisted by
not function.
foreign materials?
Has the drain hose being
laid down?
The draining does
Is the drain hose blocked
by foreign material?
not function
Are there any laundries
trapped at the outer side
of the spin tub?
Are there hair pin, coins
There's abnormal
or meta items brought
sound during
inside the tub?
washing
Is the machine slanting?
There's abnormal
Is the gland pressed evenly?
sound and violent
Are there any laundries trapped
vibration during
at the outer side of the spin tub?
spinning
Are the laundries in spin tub over
loaded?
How to settle
Use it when the power is on.
Insert the power plug tightly.
Remove the foreign materials?
Put down the drain hose?
Remove the foreign material?
Please contact the after-sales
service department.
Remove the hair pin, coins or
metal items
Pressed the gland evenly
Level the machine properly.
Remove the laundries
Remove a little laundries
14
USER
WASHING MACHINE
SEMI AUTO WASHING MACHINE
AWT-80LI
Manual
CONTENTS
Packing list
Specification
Names of the parts
Safety precautions
Installation and adjustment
Preparation before washing
Do s and don ts
Usage of the detergent
Washing sequence
Maintenance
Trouble-Shooting
Advertisement
Table of Contents
Related Manuals for Haier AWT-80LI
Summary of Contents for Haier AWT-80LI
-
Page 1: User Manual
Remove the hair pin, coins or metal items Pressed the gland evenly Level the machine properly. Remove the laundries Remove a little laundries SEMI AUTO WASHING MACHINE AWT-80LI Manual CONTENTS Packing list Specification Names of the parts Safety precautions Installation and adjustment... -
Page 2: Packing List
× ° Ï ä Ë µ Ã ÷ Packing list Quantity Name User's manual Water inlet hose Gland Semi Auto washing machine Specification × ° Ï ä Ë µ Ã ÷ Rated voltage frenquency 220V Maximum/58 Medium/49 Minimum/43 Water level Water quantity estimated (L) The Rated washing capacity(kg) The Rated spinning capacity(kg) Injection pressure(MPa) -
Page 3: Names Of The Parts
Ï ´ º ó ´ ¦ À í Maintenance Ï ´ º ó ´ ¦ À í After using, please clean the lint and eyewinker of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. -
Page 4: Safety Precautions
× ¢ Ò â Ê Â Ï î Safety precautions Please insert the power cord into When the machine is normally special receptacle with rated vol- using, please put the power plug tage.Be sure to use single-phase at the location easily to be insert- three pins receptacle.The earthing ed and extracted by hand. -
Page 5: Rinse With Water-Filling
Rinsing Rinse with water-filling 1.Put the laundries Put the laundries into the wash tub. Select suitable current according to the laundries. 2.Adjust the water level Set the water level with water level adjusting lever according to the laundries quantity. Then fill suitable water continuously. 3.Rinse Adjust the wash timer to 5-7 minutes to do rinsing. -
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter After opening the package,please take out the lint filter from the document bag,install it to the overflow filter of the wash tub.See to the figure. -
Page 7: Washing Sequence
Washing sequence Wash timer Wash selector (To set to below 2 minute, (Strong current, first set to 5 minute then standard current) turn it back. it can increase the service life of the timer). STRONG STRONG STANDARD STANDARD DRAIN DRAIN WASH SELECTOR WASH SELECTOR WASH TIMER... -
Page 8: Preparation Before Washing
Preparation before washing Ï ´ Ç ° × ¼ ± ¸ Preparation before washing 1.Connect the water inlet hose. 2.Confirm that the washing machine is earthed reliably . Then insert the power plug into the receptacle. Do not connect the earth terminal to the gas pipe and tap water pipe.
