Model No. WLEX21490
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Patent Pending

Advertisement

Table of Contents
loading

Related Manuals for Weslo Pursuit 700s

Summary of Contents for Weslo Pursuit 700s

  • Page 1 Patent Pending Mon.ÐFri., 6 a.m.Ð6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.weslo.com this equipment. Keep this manual for future reference. new products, prizes, fitness tips, and much more!

  • Page 2: Table Of Contents

    ¨ TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the WESLO ¨ PURSUIT 700s. 1. Read all instructions in this manual before 9. If you feel pain or dizziness at any time using the exercise cycle.

  • Page 4: Before You Begin

    PURSUIT 700s (see the front cover of this manual for the location of the decal). For your benefit, read this manual carefully before you use the PURSUIT 700s.

  • Page 5: Assembly

    ASSEMBLY Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench and phillips screwdriver PART CHART Use the drawings below to identify the small parts used in assembly.
  • Page 6 1. Carefully slide the Handlebar Post (3) onto the Frame (1) while pulling the excess Reed Switch Wire (42) and Resistance Cable (31) up through the Handlebar Post. Attach the Handlebar Post with three M10 x 25mm Button Head Screws (53) and three M10 Split Washers (54).
  • Page 7 5. Attach the Seat Upright (64) to the Seat Frame (2) with four M8 x 54mm Carriage Bolts (11), four M8 Flat Washers (51), and four M8 Nylon Locknuts (55). Note: It may be helpful to tip the exercise cycle on its side to attach the Seat Upright.
  • Page 8 8. Attach the Seat (44) to the Seat Bracket (63) with four M6 x 16mm Screws (46). 9. Attach the Seat Handles (25) to the Seat Bracket (63) with two M10 x 97mm Hex Head Bolts (12), and two M10 Nylon Locknuts (26). 10.

  • Page 9: How To Use The Exercise Cycle

    11. Identify the Left Pedal (39) (there is an ÒLÓ on the Left Pedal for identification). Using an adjustable wrench, tighten the Left Pedal counterclockwise into the left arm of the Crank (8). Tighten the Right Pedal (not shown) clockwise into the right arm of the Crank (8).
  • Page 10 DESCRIPTION OF THE CONSOLE HOW TO OPERATE THE CONSOLE Note: The console requires two ÒAAÓ batteries. See assembly step 3 on page 6 for battery installation Mode On/Reset instructions. Button Button 1. To turn on the power, press the on/reset button or simply begin pedaling.

  • Page 11: Maintenance And Storage

    MAINTENANCE AND STORAGE Inspect and tighten all parts of the exercise cycle reg- With the left side shield removed, locate the Reed ularly. The exercise cycle can be cleaned with a soft, Switch (42) (see the drawing below). Turn the Crank damp cloth.

  • Page 12: Conditioning Guidelines

    CONDITIONING GUIDELINES Aerobic Exercise WARNING: Before beginning this or any If your goal is to strengthen your cardiovascular sys- exercise program, consult your physician. tem, your exercise must be Òaerobic.Ó Aerobic exercise This is especially important for individuals is activity that requires large amounts of oxygen for over the age of 35 or individuals with pre- prolonged periods of time.
  • Page 13 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretchÑnever bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 14: Part List

    PART LISTÑModel No. WLEX21490 R0999A Key No. Qty. Description Key No. Qty. Description Frame Right Pedal Seat Frame Left Pedal Handlebar Post Idler Arm Spring Idler Arm Resistance Strap Idler Wheel Reed Switch w/Wire Drive Belt M4 x 16mm Screw M5 Nut Seat 12Ó...

  • Page 15: Exploded Drawing

    EXPLODED DRAWINGÑModel No. WLEX21490 R0999A 53 54...

  • Page 16: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: ¥ The MODEL NUMBER of the product (WLEX21490) ¥ The NAME of the product (WESLO ¨ PURSUIT 700s exercise cycle) ¥...
