1.5

SPECIFICATIONS

1.5.1 GENERATOR

Rated Max. Continuous Power
Capacity (Watts*)
Rated Voltage
Rated Max. Continuous Load
Current (Amps)
120 Volts +
240 Volts
Main Line Circuit Breaker
Phase
Number of Rotor Poles
Rated AC Frequency
Power Factor
Recommended Air Filter
Battery Requirement
Weight
Output Sound Level @ 23 ft (7m)
at full load
Normal Operating Range
* Maximum wattage and current are subject to and limited by such factors as fuel Btu content, ambient temperature, altitude, engine power and condition, etc. Maximum power
decreases about 3.5 percent for each 1,000 feet above sea level; and also will decrease about 1 percent for each 6° C (10° F) above 16° C (60° F).
+ Total current in TWO separate curcuits. Current in each curcuit must not exceed the value stated for 240V .

1.5.2 ENGINE

Type of Engine
Number of Cylinders
Rated Horsepower
Displacement
Cylinder Block
Valve Arrangement
Ignition System
Recommended Spark Plug
Spark Plug Gap
Compression Ratio
Starter
Oil Capacity Including Filter
Recommended Oil Filter
Recommended Air Filter
Operating RPM
6
Section 1 — General Information
Air-cooled 7 kW, 12 kW and 15 kW Generators
Model 04758
6,000 NG/7,000 LP
120/240
50.0 NG/58.3 LP
25.0 NG/29.2 LP
30 Amp
60 Hz
Part # 0C8127
Group 26/26R
12 Volts and
350 Cold-cranking
Amperes Minimum
375 Pounds
68 db (A)
Model 04758
GH-410
14.5 @ 3,600 rpm
410cc
Aluminum w/Cast
Iron Sleeve
Overhead Valves
Solid-state w/Magneto
RC14YC
0.76 mm (0.030 inch)
8.6:1
12 Vdc
Approx. 1.5 Qts
Part # 070185B
Part # 0C8127
3,600
Model 04759
12,000 NG/12,000 LP
100.0 NG/100.0 LP
50.0 NG/50.0 LP
1
2
1
Part # 0C8127
Group 26/26R
12 Volts and
525 Cold-cranking
Amperes Minimum
-20°F (-28.8°C) to 104°F (40°C)
Model 04759
1
30 @ 3,600 rpm
Aluminum w/Cast
Overhead Valves
Solid-state w/Magneto
0.508 mm (0.020 inch)
Approx. 1.7 Qts
Part # 070185B
Part # 0C8127
120/240
50 Amp
1
2
60 Hz
1
470 Pounds
70.5db (A)
GT-990
2
992cc
Iron Sleeve
RC12YC
0.508 mm (0.020 inch)
9.5:1
12 Vdc
3,600
Model 04760
13,000 NG/15,000 LP
120/240
108.3 NG/125.0 LP
54.2 NG/62.5 LP
65 Amp
1
2
60 Hz
1
Part # 0C8127
Group 26/26R
12 Volts and
525 Cold-cranking
Amperes Minimum
487 Pounds
71.5 db (A)
Model 04760
GT-990
2
30 @ 3,600 rpm
992cc
Aluminum w/Cast
Iron Sleeve
Overhead Valves
Solid-state w/Magneto
RC12YC
9.5:1
12Vdc
Approx. 1.7 Qts
Part # 070185B
Part # 0C8127
3,600
