WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY: Do not store or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
THE INSTALLATION MUST BE IN ACCORDANCE WITH LOCAL CODES OR, IN THE
ABSENCE OF LOCAL CODES, WITH THE CURRENT NATIONAL FUEL GAS CODE
ANSI Z223.1 (USA) OR THE CURRENT CAN/CGA B149 INSTALLATION CODES
PLEASE KEEP THIS INSTRUCTIONS MANUAL
SGS
OWNER`S MANUAL
(CANADA).
FOR FUTURE REFERENCE
S B I , 1700 LÉON-HARMEL, QUÉBEC, (QUÉBEC), CANADA, G1N 4R9
Tel : ( 418 ) 527-3060
Fax : ( 418 ) 527-4311
www.drolet.ca
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
010517/45047A_feb 03
Advertisement
Table of Contents
Related Manuals for Drolet SGS
Summary of Contents for Drolet SGS
- Page 1 ANSI Z223.1 (USA) OR THE CURRENT CAN/CGA B149 INSTALLATION CODES (CANADA). PLEASE KEEP THIS INSTRUCTIONS MANUAL FOR FUTURE REFERENCE S B I , 1700 LÉON-HARMEL, QUÉBEC, (QUÉBEC), CANADA, G1N 4R9 Tel : ( 418 ) 527-3060 Fax : ( 418 ) 527-4311 www.drolet.ca 010517/45047A_feb 03...
-
Page 2: Table Of Contents
Stove conversion for a "B-Vent" installation only ..................13 Gas Piping............................... 15 Logs Installation .............................. 15 Ember Kit Installation ............................16 Pedestal cover (model SGS and SGS II)......................16 OPERATING YOUR STOVE ............................... 17 For your safety ..............................17 Lighting Instructions ............................17 Shut down Instructions............................ -
Page 3: General Information
GENERAL INFORMATION The SGS GAS STOVE is a high-efficiency gas appliance with a maximum input rating of 28 500 BTU/h (8,4 kW) with natural gas or 26 000 BTU/h (7,6 kW) with propane. It features an adjustable millivolt valve and a constant pilot independent of any electrical source. -
Page 4: Technical Specifications
SGS GAS STOVES TECHNICAL SPECIFICATIONS SGS Dimensions Dimensions Height : 27 3/4 po / 706 mm Width : 24 1/2 po / 621 mm Depth : 23 po / 585 mm Ceramic Glass 8 3/4 po x 16 5/8 po... -
Page 5: Sgs Ii Dimensions
SGS GAS STOVES SGS II Dimensions Dimensions Height : 27 3/4 po / 706 mm Width : 24 1/2 po / 621 mm Depth : 23 po / 585 mm Ceramic Glass Front : 11 1/2 po x 12 1/2 po... -
Page 6: Burner
SGS GAS STOVES Burner Natural Gas Propane LP Maximum Input, BTU/h (kW) minimum : 19 000 (5,6) 20 000 (5,9) maximum : 28 500 (8,4) 26 000 (7,6) Inlet Pressure Inch WC (kPa) minimum : (1,3) 11,0 (2,8) maximum :... -
Page 7: Installation
Provide adequate clearances around air openings into the combustion chamber. Provide adequate accessibility clearances for servicing and proper operation. • The SGS may be installed in a bedroom provided that all required clearances are met and a wall thermostat is installed. •... -
Page 8: Clearances To Combustibles
SGS GAS STOVES Clearances to combustibles Clearance between the stove and any combustible material must also be maintained while installing your appliance. CLEARANCE Back (in) Side (in)) Corners (in) Top (in) Front (in) Pipe (in) 1 ½ Note 1 Floor... -
Page 9: Direct Vent Installation
SGS GAS STOVES Direct Vent Installation Critical Length of Venting Pipes The following table shows the maximum length to be respected while installing your appliance with venting pipes (4"X6 5/8") from Simpson Dura- Vent, Security Chimneys International (Secure Vent) or Selkirk (Direct-Temp) only. -
Page 10: Terminal Vent Location
Terminal Vent Location Your SGS stove vents through a vent terminal installed on the roof or on the outside of any exterior wall of your house. Many restrictions apply to the vent terminal location that should be considered before locating your stove. -
Page 11: Installation Of Drolet Wall Venting Kits
SGS GAS STOVES Installation of Drolet Wall Venting Kits Direct And Corner Vent Kit Installation AC02000: Coaxial 4" X 6 5/8" rigid vent system with black finish includes : 45° Elbow 24" Pipe 90° Elbow 24" Pipe Adjustable pipe Restrictor... - Page 12 SGS GAS STOVES Direct Vent Kit for Basement Installation AC02010: Coaxial 4" X 6 5/8" rigid vent system with black finish includes : 1- 45° Elbow 2- Two 24" Pipes 3- 90° Elbow 4- 24" Pipe 5- Adjustable pipe 6- Wall thimble cover...
-
Page 13: Vented Gas Stove Installation ("B-Vent")
SGS GAS STOVES Vented Gas Stove Installation ("B-Vent") Instead of using a standard B-vent pipe it is possible to use a 4" flexible aluminum chimney lining system into an existing chimney. The existing chimney must be a code complying masonry or listed fuel burning chimney system: ‘B’... -
Page 14: Stove Conversion For A "B-Vent" Installation Only
Stove conversion for a "B-Vent" installation only The following instructions are not for a direct vent installation. Your Drolet stove is coming to you ready for a direct vent installation. You can buy a conversion kit to be able to install it as a "B-Vent" unit. To convert your stove, just follow the instructions: 1. - Page 15 SGS GAS STOVES 5. Remove and discard the metallic plate (6) from the rear heat shield using a screw driver. Unscrew just a little bit the two screws located each side of the chimney connector. Install the venting hood (5) by sliding it into place.
-
Page 16: Gas Piping
SGS GAS STOVES Gas Piping • Route a 3/8" minimum NPT iron pipe gas line to the desired location. • Install a shutoff valve to the gas line. Tighten securely using a pipe joint compound. • Check the gas line piping for leaks. Use a soap and water solution. -
Page 17: Ember Kit Installation
1. Place some pieces of rock wool fibers approximately 1/2" large behind the front gas ports. 2. Light the stove. Modify the configuration of the rock wool near the gas ports until you reach the desired effect. Pedestal cover (model SGS and SGS II) 1. Screw the stove on the floor using the fixation holes each side of the pedestal;... -
Page 18: Operating Your Stove
SGS GAS STOVES OPERATING YOUR STOVE For your safety ATTENTION : • A QUALIFIED INSTALLER MUST PERFORM INSTALLATION OF THE APPLIANCE VENTING PIPING AND ADJUSTMENTS • D URING OPERATION THIS STOVE IS HOT O NOT TOUCH EEP CHILDREN CLOTHING FURNITURE AND FLAMMABLE MATERIALS AWAY •... -
Page 19: Shut Down Instructions
50 pi 12GA Thermocoup To use your SGS with the wall thermostat, follow the lighting procedure and set the gas control to the ON position. Simply set your wall thermostat to a comfortable temperature and the stove will do the rest. -
Page 20: The Benefits Of Installing A Blower
The benefits of installing a blower A blower can be installed at the back of your DROLET stove. This option is necessary if you wish to redistribute into a room the heat trapped at the back of your stove. By forcing hot air toward the front, the blower enables you to extend the radiation power of your stove. -
Page 21: Optional Thermodisc (Ac05530)
SGS GAS STOVES Optional Thermodisc (AC05530) Follow the installation instructions included with the optional thermodisc. The fixation holes are located at the back of the stove on the lower right corner. Refer to the drawing on this page. Note : The blower will start when the temperature at the... -
Page 22: Maintenance Instructions
When replacing the glass, you should change the glass gasket to make sure you keep it sealed. • If the gasket is damaged, replace it with an identical one. To get a new gasket, refer to your DROLET dealer. -
Page 23: Burner
SGS GAS STOVES Burner Removing the Burner • Open the glass door. Remove the burner contour (2) and the deflector (3). Unscrew the two screws on each side of the burner (1). • Slide the burner out from the ventury towards the left. Get it out from the stove. -
Page 24: Options
SGS GAS STOVES OPTIONS DESCRIPTION PART # Millivolt Wall Thermostat AC05558 Tangential blower with variable speed control AC02050 Direct Vent Kit and Corner Installation AC02000 Direct Vent Kit Basement Installation AC02010 REMPLACEMENT PARTS DESCRIPTION PART # 5 logs set AC05791... -
Page 25: Limited Warranty
Paint, gasket, blower, Blower thermoswitch and rheostat 1 year Gold plating (tarnishing) 5 years Shall your unit or a components be defective, contact immediately your Drolet dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: • •...
