Page 1: Instruction Manual
9" BANDSAW MODEL G1052 INSTRUCTION MANUAL COPYRIGHT © 1995 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. APRIL, 1999 PRINTED IN U.S.A. -
Page 3: Table Of Contents
TEST RUN...17 BLADE INFORMATION...18 RIPPING ...18 CROSSCUTTING ...19 CUTTING CURVES...19 STACKED CUTS...19 MAINTENANCE GENERAL ...20 LUBRICATION ...20 TABLES...20 CLOSURE...21 MACHINE DATA ...22 PARTS BREAKDOWN AND PARTS LISTS...23-28 TROUBLESHOOTING ...29 WARRANTY AND RETURNS ...30 G1052 9" Bandsaw Table Of Contents PAGE... -
Page 4: Safety
G1052 9" Bandsaw VISITORS... - Page 5 12. SECURE WORK. Use clamps or a vise to hold work when practical. It’s safer than using your hand and frees both hands to operate tool. G1052 9" Bandsaw 13. DON’T OVERREACH. Keep proper foot- 14. MAINTAIN TOOLS WITH CARE. Keep 15. DISCONNECT TOOLS before servicing 16.
-
Page 6: Additional Safety Instructions For Bandsaws
Make sure blade has been properly ten- sioned. Like all power tools, there is danger associ- ated with the Model G1052 9" Bandsaw. Use the tool with respect and caution to lessen the possibility of mechanical damage or operator injury. If normal safety precau- tions are overlooked or ignored, serious injury may occur. -
Page 7: Circuit Requirements
110V outlet. The G1052 motor will safely draw about 8 amps at 110V under load. If you operate the bandsaw on any circuit that is already close to its capacity, it might blow a fuse or trip a circuit breaker. -
Page 8: Introduction Commentary
SECTION 3: INTRODUCTION Commentary Grizzly Industrial, Inc. is proud to introduce the Model G1052 9" Bandsaw. This saw is a part of Grizzly’s growing family of fine woodworking machinery. When used according to the guide- lines stated in this manual, you can expect years of trouble-free, enjoyable operation, and proof of Grizzly’s commitment to customer satisfaction. -
Page 9: Unpacking
When you are completely satisfied with the con- dition of your shipment, you should inventory its parts. The G1052 is a heavy machine with a ship- ping weight of 100 lbs. DO NOT over-exert yourself while unpacking or moving your machine –... -
Page 10: Clean Up
Most com- mercial or home shop benches should be suffi- cient to carry the weight of the G1052. If you question the strength of your workbench, you can opt to reinforce it, or consider placing the band- saw on a freestanding bench like Grizzly’s Shop... -
Page 11: Assembly
SECTION 4: ASSEMBLY Bandsaw Unit For maximum stability, the G1052 must be securely mounted to your workbench. NOTICE The numbers in parentheses following part names correspond with numbered parts in the diagrams in the back of this manual. To mount the bandsaw: Place the bandsaw unit on it’s intended work... -
Page 12: Adjustments
(#2) to modify the ten- sion until it is correct. If the tension seems correct, make the other adjustments to the saw and test run it. Re-adjust tension if the blade does not cut correctly. -10- Figure 4. Checking blade deflection. -
Page 13: Co-Planarity
If one step works, immediately proceed to the tracking adjustment instructions. Turn the tracking knob to adjust the angle of the upper wheel. G1052 9" Bandsaw Add washers behind the upper or lower wheels as needed. Remove washers behind the UPPER WHEEL ONLY. -
Page 14: Tracking
1/64" behind the blade. Re-tighten the setscrews. Blade Support Bearing Blade Tracking Control Knob Guide Bearings Figure 9. Blade guide assemblies. Blade Guides Guide Post Support Bearing Shaft Guide Bearing Shafts Guide Bearing Shaft Setscrew G1052 9" Bandsaw... - Page 15 Figure 11. Use extreme care when making adjust- ments that require contact between the bandsaw blade and your hand. G1052 9" Bandsaw Gullet Line Figure 11. Bearing set back from gullet line Re-tighten the setscrews. Spin the bearings by hand. They should spin freely.
-
Page 16: Table Adjustments
Secure the table by re-tightening the locking handle. Check table position to ensure that undesirable shifting did not occur during re- tightening. If the table will not shift adequately, you will need to reposition the blade. G1052 9" Bandsaw... -
Page 17: Changing Blades
See Figure 15 for typical blade geometry. Put on heavy gloves, remove the blade, and twist it until it is right side out. Re-install the blade. G1052 9" Bandsaw Gullet Tooth Gullet Line Figure 15 Side and front views of a standard bandsaw blade. -
Page 18: Guide Post
Repeat guide post bracket adjustments. This concludes the instructions for adjust- ment and assembly. To ensure your own safety while operating the Model G1052 Bandsaw, please refer to the Safety Rules for Bandsaws in Section 1 of this manual. Bracket Bolts Bracket "... -
Page 19: Operations
Test Run Once you have completed the instructions for assembly and adjustments, you are ready to give the Model G1052 its first test run. Re-connect the Model G1052 to its power source. Keeping one finger on the OFF switch to be ready for a quick shut off in the case of prob- lems, turn on the bandsaw. -
Page 20: Blade Information
Maximum cutting height for this bandsaw is 4 The G1052 bandsaw is capable of ripping, pro- vided the saw is set up properly. Use common sense when ripping. Attempting to rip too wide or too dense a board may put excessive strain on the blade and be dangerous. -
Page 21: Crosscutting
MINIMUM RADII " " " " G1052 9" Bandsaw One of the benefits of a bandsaw is its ability to ". cut multiple copies of a particular shape by stack- ing a number of workpieces together. Before making stacked cuts, it is essential to ensure that both the table and the blade are prop- erly adjusted to 90°. -
Page 22: Maintenance
-20- Table The table and other non-painted surfaces on the Model G1052 should be protected against rust and pitting. Wiping the saw clean after every use ensures that moisture from wood dust isn’t allowed to trap moisture against bare metal sur- faces. -
Page 23: Closure
Washington location using the address in the Introduction. The specifications, drawings, and photographs illustrated in this manual represent the Model G1052 as supplied when the manual was prepared. However, due to Grizzly’s policy of continuous improvement, changes may be made at any time with no obligation on the part of Grizzly. -
Page 24: Machine Data
Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G1052 9" BANDSAW Design Type ... Bench Model Overall Dimensions: Table ...11 Overall Height ...31" Height From Bench to Table ...13 Table Tilt ...15 Overall Depth including Fence ...18... -
Page 25: Parts Breakdown And Parts Lists
PARTS DIAGRAMS MAIN BODY MAIN BODY G1052 9" Bandsaw -23-... -
Page 26: Bearing Guides
-24- BEARING GUIDES G1052 9" Bandsaw... - Page 27 TABLE AND FENCE G1052 9" Bandsaw -25-...
- Page 28 MOTOR AND GEARBOX -26- G1052 9" Bandsaw...
-
Page 29: Parts Lists
SETSCREW 10 - 32 x 035 PS16 PHLP HD SCRW 6 - 32 x 036 P1052036 GUARD 037 P1052037 BLADE GUIDE SHAFT W/039 G1052 9" Bandsaw PARTS LISTS REF# PART# 038 P1052038 BLADE BACKUP SHAFT W/039 039 P2921001 BEARING 040 PR03 041 CATALOG BLADE "... - Page 30 " - 20 x " 104 P1052104 FAN COVER 105 P1052105 CAPACITOR COVER 106 PC150 DESCRIPTION KEY 4 x 4 x 15mm KEY 4 x 4 x 10mm LOCK WASHER " " FLAT WASHER #6 SWITCH CAPACITOR 150MFD G1052 9" Bandsaw...
-
Page 31: Troubleshooting
Blade does not cut even- Ticking sound when the saw is running. Blade contacting table insert. Excessive vibration. G1052 9" Bandsaw CORRECTIVE ACTION Low voltage. Open circuit in motor or loose connections. Short circuit in line cord or plug. -
Page 32: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. -
