USE THE RIGHT TOOL. Do not force tool or attachment to do a job for which it was not designed. INFLUENCE ALCOHOL. Model H8115/H8117 Spray Gun WORKSHOP CHILD UNDER DRUGS...
17. REDUCE UNINTENTIONAL SPRAYING. Do not carry tool with hand on trig- ger and always disconnect from air when not in use. Model H8115/H8117 Spray Gun 18. DISCONNECT TOOLS before ser- vicing and changing accessories. 19. USE ACCESSORIES. owner’s manual for recommended accessories.
NOT exceed the recommended inlet air pressure. Excessive pres- sure could cause the spray gun to blow seals or cause other internal equipment damage. 14. LOCAL authorities regarding exhaust and waste disposal requirements. PRESSURE. LAWS. Consult local Model H8115/H8117 Spray Gun...
SECTION 2: INTRODUCTION Foreword We are proud to offer the Grizzly Model H8115/H8117 Spray Gun, part of a grow- ing Grizzly family of fine pneumatic tools. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation, and proof of Grizzly’s commitment to customer...
45-60 PSI Stainless Steel " @ 8" Polished Metal/Plastic Small to Medium Liquid Particles H8117 150ml Gravity 0.8mm 5 CFM 3.0-4.0 BAR 43-60 PSI Stainless Steel " @ 8" Polished Metal/Plastic Small to Medium Liquid Particles Model H8115/H8117 Spray Gun...
E. Service Wrench ... 1 F. Cleaning Brushes ... 2 G. Filters ... 2 Figure 2. Model H8117 inventory. H8115 Assembly Follow Steps 2-5 of the H8117 Assembly instructions. H8117 Assembly Insert the filter into the gun body as shown in Figure 3.
Air Flow Control Figure 4. H8115 Controls. Atomizing Cap Trigger Air Flow Control Figure 5. H8117 Controls. Fluid Control: Controls the volume of material that travels through the fluid tip. Pattern Control: Adjusts the spray pattern from a round pattern to a wide fan.
Model H8115/H8117 Spray Gun Spraying The Model H8115/H8117 is designed to spray liquids paints and lacquers that are low viscosity or have been thinned down. It is ideal for auto body touch-ups, wood- working projects, and projects with hard to reach areas.
Page 12
Continue the motion for a few inches past the work until you are ready for the return stroke. NOTICE Tipping the Model H8117 spray gun may cause material to spill out of the cup. Always hold the spray gun perpendicular to the ground to avoid potential spills and gravity feed prob- lems.
Figure 7. Set up for horizontal stroke, Model H8115. Holes Stroke Figure 8. Set up for horizontal stroke, Model H8117. Model H8115/H8117 Spray Gun Pattern Control Stroke Figure 9. Set up for vertical spray stroke, Model H8115. Stroke Pattern Control Figure 10.
H3174—Air Blow Gun with 2 Tips This air blow gun includes a safety tip and rubber tip for all normal air cleaning jobs. ⁄ " NPT. Figure 15. H3174 Air Blow Gun with 2 Model H8115/H8117 Spray Gun pressure regulator. Tips.
Atomizing Spring & Needle Figure 16. Typical disassembly for clean- ing. Model H8115/H8117 Spray Gun 5. Unscrew the atomizing cap with your fingers and the fluid tip with the ser- vice wrench. The fully disassembled gun should look like Figure 16.
Lubrication Lubricate the following areas on the Model H8115 (Figure 17) and Model H8117 (Figure 18) with spray oil, grease, or petroleum jelly after cleaning. A. Atomizing Cap Threads B. Air Valve Packing C. Trigger Pin D. Air Flow Control Valve E.
4. Material is too thin. No spray output. 1. No pressure at gun. 2. Fluid passages dirty. 3. Fluid control closed. 4. Out of paint. Model H8115/H8117 Spray Gun Troubleshooting Solution 1. Tighten fluid tip or replace seat with new one. 2. Add material.
Page 18
1. Lower inlet air pressure. 2. Keep gun at recommended distance. 3. Slow down and maintain consistent even parallel stroke. 1. Clean or replace both. 1. Install an in-line air filter, or replace air line. Model H8115/H8117 Spray Gun...
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
