RADIAL DRILL PRESS
MODEL G7945/46
INSTRUCTION MANUAL
COPYRIGHT © 2001 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
JUNE, 2001 PRINTED IN CHINA.

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G7945

Summary of Contents for Grizzly G7945

  • Page 1 RADIAL DRILL PRESS MODEL G7945/46 INSTRUCTION MANUAL COPYRIGHT © 2001 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. JUNE, 2001 PRINTED IN CHINA.
  • Page 2 Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemi- cals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...

  • Page 3: Table Of Contents

    1. SAFETY SAFETY RULES FOR ALL TOOLS ...2-3 ADDITIONAL SAFETY INSTRUCTIONS FOR G7945/46 ...4 2. CIRCUIT REQUIREMENTS 110V OPERATION ...5 GROUNDING ...5 EXTENSION CORDS ...5 3. INTRODUCTION COMMENTARY...6 UNPACKING ...7 PIECE INVENTORY ...7 CLEAN UP...8 SITE CONSIDERATIONS ...8 4. ASSEMBLY BEGINNING ASSEMBLY ...9...

  • Page 4: Safety

    G7945/46 Radial Drill Press VISITORS...
  • Page 5 15. USE RECOMMENDED ACCESSORIES. Consult the owner’s manual for recom- mended accessories. The use of improper accessories may cause risk of injury. G7945/46 Radial Drill Press 16. REDUCE THE RISK OF UNINTENTION- 17. MANY WOODWORKING TOOLS CAN LENGTH 50ft 100ft 18.

  • Page 6: Additional Safety Instructions For G7945/46

    ALWAYS OPERATE YOUR DRILL PRESS AT SPEEDS that are appropriate for the drill bit size and the material that you are drilling. FEED THE DRILL BIT EVENLY INTO THE WORKPIECE. Back the bit out of deep holes and clear the chips with a brush after you have turned the machine off.

  • Page 7: Circuit Requirements

    SECTION 2: CIRCUIT REQUIREMENTS 110V Operation The Model G7945/46 is wired for 110V, single phase operation only. The ⁄ HP motor will safely draw 5 amps at 110V. If you operate this machine on any circuit that is already close to its capacity, it might blow a fuse or trip a circuit breaker.

  • Page 8: Introduction

    SECTION 3: INTRODUCTION Commentary We are proud to offer the Grizzly Model G7945/46 Radial Drill Press. The Model G7945/46 is part of a growing Grizzly family of fine woodworking machinery. When used according to the guide- lines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of Grizzly’s commitment to customer satis-...

  • Page 9: Unpacking

    Unpacking The Model G7945/46 is shipped from the manu- facturer in a carefully packed carton. If you dis- cover the machine is damaged after you’ve signed for delivery, immediately call Customer Service for advice. When you are completely satisfied with the con- dition of your shipment, you should inventory its parts.

  • Page 10: Clean Up

    Most commercial or home shop floors should be sufficient to carry the weight of the Model G7945/46. If you question the strength of your floor, you can opt to reinforce it. Ensure that the stand or bench you use with the Model G7945 is capable of supporting the machine.

  • Page 11: Assembly

    Failure to com- ply may result in serious personal injury. Most of your Model G7945/46 Radial Drill Press has been assembled at the factory, but some parts must be assembled or installed after deliv- ery. We have organized the assembly process into steps.

  • Page 12: Table Support

    Table Support The Model G7945 comes with a one piece square table and support as shown in Figure 4. The Model G7946 comes with a round table and two piece hinged table support. 1. Insert the pinion gear into the hole on the side of the bracket from the inside, starting with the shaft.

  • Page 13: Headstock

    Handles Three handles are supplied with the drill press. Thread them into the handle hub. G7945/46 Radial Drill Press Drill Chuck and Arbor The drill chuck is attached to the drill spindle by means of a machined taper between the chuck and spindle nose.

  • Page 14: Adjustments

    V-belt tension is achieved. Close the cover. Never operate drill press with belt cover in the open position. Your hand may become trapped in a belt and serious personal injury will occur. Figure 10. Loosening the lock knob. G7945/46 Radial Drill Press...

  • Page 15: Depth Stop

    Depth Stop Your radial drill press comes with a depth stop for use when drilling. Follow the instructions below for use. 1. Loosen the depth collar lock knob. See Figure 11. 2. Secure the wood stock you will be drilling onto the drill press table.

  • Page 16: Table Adjustments

    Table Adjustments The Model G7945 table can be adjusted for height and angle. The G7946 adds the adjust- ments of table distance from column and rotation. Follow these instructions to adjust height: Loosen the table support bracket lock han- dle. Turn the table hand crank to lift or lower the table.

  • Page 17: Head Adjustments

    Loosen the lock handle located on the right side of the headstock. Turn the black ribbed handle to move the headstock back and forth to desired position. Tighten the lock handle before operating the machine. G7945/46 Radial Drill Press Figure 16. Guide pin location. -15-...

  • Page 18: Operations

    Do not allow the chuck to grab the fluted body of the drill bit. Make sure small drill bits do not get trapped between the edges of two jaws. Tighten the chuck with the chuck key using any of the three key end locations.

  • Page 19: General

    5. Any other condition that could hamper the safe operation of this machine. G7945/46 Radial Drill Press The nonpainted surfaces on the Model G7945/46 adjust- should be protected against rust and pitting. Wiping the machine clean after every use ensures that wood dust will not trap moisture against bare metal surfaces.

  • Page 20: Closure

    -18- We recommend you keep a copy of our current catalog for complete information regarding Grizzly's warranty and return policy. If you need additional technical information relating to this machine, or if you need general assistance or replacement parts, please contact the Service Department listed in Section 3: General Information.

  • Page 21: Machine Data

    Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G7945 RADIAL DRILL PRESS Design Type ...Bench Model Overall Dimensions: Table ...8 Overall Height...31 Overall Width ...11 Overall Depth ...33 Column Diameter ...2.360"...
  • Page 22 Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G7946 FLOOR RADIAL DRILL PRESS Design Type ...Floor Model Overall Dimensions: Table ...12 Overall Height...64 Overall Width ...14'' Overall Depth...32'' Column Diameter ...2.790" (Vertical), 2.356" (Horizontal) Quill Diameter ...

  • Page 23: Parts Breakdown And Parts Lists

    G7946 ONLY...
  • Page 24 P7945078 10M CAPSCREW PW04M 10M FLATWASHER P7945080 RETAINER RING P7945081 HEX BOLT P7945082 WASHER P7945083 TABLE P7945084 COLUMN SUPPORT P7945084A TABLE SUPPORT EXTENSION P7945085 SAFETY GLASSES WARNING P7945086 CLOSE LID WARNING G7945/46 Radial Drill Press ⁄ " ⁄ " "...
  • Page 25 NOTES G7945/46 Radial Drill Press -23-...

  • Page 26: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.

  • Page 27: G7945/46 Radial Drill Press

    Do you think your purchase represents good value? ___Yes Would you recommend Grizzly Industrial to a friend? ___Yes Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than three times. ___Yes Comments:_________________________________________________...
  • Page 28 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
