Instructions for Set-up, Operation, Maintenance & Storage
H
W
OT
ATER
This pressure washer produces both cold and hot water high-pressure spray as well as steam spray.
Cleaning chemicals may be incorporated into the spray if desired. The pressure pump for this equipment
is powered by a gasoline internal combustion engine and the water is heated by a kerosene/fuel-oil fired,
open flame burner.
READ and UNDERSTAND this Owner's Manual and the Engine Owner's Manual
completely before attempting to set up and use the pressure washer! Failure to properly set
up, operate, and maintain this pressure washer could result in serious injury or death to operator
or bystanders.
•
CO Poisoning
•
Skin/Eye
Injury
•
•
Burns
•
Slips/Falls
•
•
Flying Debris
•
Fire/
Explosion
•
•
Chemical
Exposure
•
Electric shock
A summary of important safety information is provided at the end of the manual.
Any Questions, Comments, Problems, or Parts Orders
Owner's Manual
/S
P
TEAM
RESSURE
Portable Outdoor-Use Only
WARNING – READ THIS MANUAL
WARNING – SPECIAL HAZARDS
Exhaust from both the engine and burner contains carbon monoxide, a
poisonous gas that can cause carbon monoxide poisoning and possible
death if inhaled.
High-pressure spray can cause serious skin or eye injury, including injection injury
if fluid pierces the skin. Injection injury can result in blood poisoning and/or
severe tissue damage.
Hot spray can scald and burn skin.
Hot surfaces of wand, engine and burner, as well as hot exhaust from both
the engine and burner can cause burns.
Spray discharge can cause puddles and slippery surfaces.
Spray-gun kickback can cause operator loss of balance and falls.
High-pressure spray can cause surface damage and flying debris.
Engine and burner sparking can ignite fuel or other flammable liquids or
vapors in the vicinity.
Hot exhaust from engine and burner can ignite combustible materials.
Cleaning chemical vapors or contact with skin may be hazardous.
Spray contact with electrical sources can cause electric shock.
Call NorthStar Product Support 1-800-270-0810
M157309M.1
ITEM NUMBER: 157309
SERIAL NUMBER: _____________
®
W
ASHER
1
– 2750
/ 2.5
PSI
GPM
Advertisement
Table of Contents
Related Manuals for North Star M157309M.1
Summary of Contents for North Star M157309M.1
- Page 1 M157309M.1 ITEM NUMBER: 157309 SERIAL NUMBER: _____________ ® Owner’s Manual Instructions for Set-up, Operation, Maintenance & Storage – 2750 / 2.5 ATER TEAM RESSURE ASHER Portable Outdoor-Use Only This pressure washer produces both cold and hot water high-pressure spray as well as steam spray.
-
Page 2: Hazard Signal Word Definitions
Hazard Signal Word Definitions Equipment Protection Quick Facts STOP! Closely inspect to make sure no components are missing or damaged. See the Inspect Upon “Assembly and Initial Set-Up” section for instructions on whom to contact to report missing or Delivery damaged parts. -
Page 3: Table Of Contents
Table of Contents About Your Pressure Washer ......................4 Specifications ............................5 Component Identification .......................6 Safety Labeling..........................8 Special Equipment Safety Features....................9 Assembly and Initial Set-Up ......................10 Step 1. Unpacking & Delivery Inspection ..................10 Step 2. Assembly...........................12 Step 3. Initial Pump & Engine Preparation...................13 Step 4. -
Page 4: About Your Pressure Washer
About Your Pressure Washer Thank you for purchasing a NorthStar hot water pressure washer! Your machine is designed for long life, dependability, and the top performance you demand. This pressure washer is designed to: 1) Produce a high-pressure steam spray or water spray (heated or unheated) -- up to 2.5 gallons per minute at 2750 psi. -
Page 5: Specifications
Specifications MODEL Model # 157309 FLOW OUTPUT Pressure Rating 2750 psi Flow Rate 2.5 gpm Maximum Temperature 250° F DIMENSIONS / COMPONENTS Length 44” Width 27” Height 42” Weight (fueled) 400 lbs. Pump Type Comet BXD Engine Displacement 205cc High Pressure Discharge Hose 3/8”... -
Page 6: Component Identification
Component Identification Ref # Description Ref # Description Ref # Description High Pressure Relief Valve Engine Control Panel Exhaust Vent Control Panel Circuit Breaker Heating Coil High Pressure Outlet Heat Switch Garden Hose Water Inlet Fuel Filter Thermostat Pump Burner Indicator Lights LED Battery location Gas Cap... - Page 7 Component Identification cont’d REFERENCE GUIDE 1. High Pressure Relief Valve A safety valve that relieves pressure; to eliminate over pressurization. 2. Exhaust Vent Provides an out for burner exhaust gases. Steel piping wound together with an inlet for incoming cold 3.
-
Page 8: Safety Labeling
Safety Labeling WARNING - BATTERY HAZARDS BATTERIES: 1) contain caustic acid, 2) emit explosive gases, 3) can cause electric shock ALWAYS use eye protection. Caustic acid and explosive gases can cause blindness or severe burns. NO smoking, sparks, or flames. NEVER touch both battery terminals at the same time with your hand or any non-insulated tools. -
Page 9: Special Equipment Safety Features
Special Equipment Safety Features High Pressure WARNING: If the high-pressure relief valve ever discharges water, Relief Valve turn the engine off and do not use the machine. Call Product Support at 1-800-270-0810. This unit is equipped with a high-pressure relief valve, which acts as a backup safety feature. -
Page 10: Assembly And Initial Set-Up
Assembly and Initial Set-Up Steps for Assembly / Initial Set-Up Step 1. Unpacking & Delivery Inspection Step 2. Assembly Step 3. Initial Pump & Engine Preparation Step 4. Battery Installation Each of these steps is discussed below: Step 1. Unpacking & Delivery Inspection Find and separate the components identified in Figure 2 –... - Page 11 Assembly and Initial Set-Up 5/16 Flat Washer 5/16-18 x 2” Flange Bolt Qty-4 Qty-4 Part # 82021 Part # 82018 Nozzles Qty-6 Part # 38531 & 778198 Grommets Qty-6 Part # 35198 Wheel Retainers Qty-4 Part # 305200 Hose Hook Qty-1 Part # 38510 5/16-18 Flange Nut...
-
Page 12: Step 2. Assembly
Assembly and Initial Set-Up Step 2. Assembly You must assemble your pressure washer before it can be used. Refer to Figure 4 and follow the steps listed below: Install One (1) Gun Hook Install One (1) Gun on Left side of Base Hooks into Left Side of Handle using Two (2) 5/16-18 Flange Nuts... -
Page 13: Step 3. Initial Pump & Engine Preparation
Assembly and Initial Set-Up Step 4. Install one (1) Gun Hook on left side of pressure washer base (below engine). Screw hook directly into base until tight. Step 5. Install Grommets and Nozzles into Holes in Control Panel. Step 6. Install Wheels: WARNING : The pressure washer is heavy. -
Page 14: Step 4. Battery Installation
Assembly and Initial Set-Up Fill the engine with oil. Prepare Engine Note: The engine is shipped without oil. Refer to the Engine Manual to locate oil-fill port and for instructions on filling. Use the oil grade and quantity specified in the Engine Manual. Step 4. - Page 15 Assembly and Initial Set-Up • ALWAYS use eye protection and protective clothing when handling General Battery batteries. • Safety Rules NEVER smoke or work near sparks or other sources of ignition. • NEVER touch both battery terminals at the same time with your hand or any non-insulated tools.
-
Page 16: Moving And Handling
Moving and Handling WARNING The pressures washer is heavy. It can crush and cause serious injury if it rolls out of control or tips over. Follow the instructions below for safely moving the pressure washer. Moving and Handling Lift Here Handle FIG02237 Figure 7... -
Page 17: Before Each Use
Before Each Use Follow the steps below prior to each use of the pressure washer. Steps to Follow Before Each Use Step 1. Check Equipment Step 2. Add Fuel(s) Step 3. Select Suitable Worksite Step 1. Check Equipment Check/add Check/add pump oil. pump oil Caution: Never run the pump without sufficient lubrication! 1. -
Page 18: Step 2. Add Fuel(S)
Before Each Use 1) Check hoses, fittings, wand, trigger gun and connections for signs of wear, cracks, looseness, or leaks. Replace as required. 2) Check and clean the nozzle orifice. 3) Clean inlet filter. (See Maintenance instructions) Inspect fuel Always inspect (engine and burner) fuel systems & check for leaks system BEFORE starting pressure washer. - Page 19 Before Each Use 2) Fill fuel tank OUTDOORS – never indoors. Fuel vapors can ignite if they collect inside an enclosure and explosion can result. 3) Stay away from all sources of heat, sparks, and flames. Do not smoke. 4) Never pump fuel directly into the gas tank or burner at a gas station – it could cause a static electric spark.
-
Page 20: Step 3. Select A Suitable Worksite
Before Each Use Step 3. Select Suitable Outdoor Worksite Before using the pressure washer, you must understand the criteria for selecting a suitable location for operation. Note that this pressure washer is for OUTDOOR USE only. WARNING You must choose a suitable site for operating your pressure washer to avoid equipment damage and/or injury and possible death from carbon monoxide poisoning, fire/explosion, uncontrolled equipment movement/tip over, or slips and falls. - Page 21 Before Each Use 2. Away from Do not locate and use the pressure washer in the presence of flammable combustible vapors, dust, gases, or other potentially combustible materials. Burner is an open flame, which can ignite airborne dusts and flammable vapors. Operate only dust, liquids, or vapors where open flame or torch is permitted.
-
Page 22: Operation
Operation After you have checked and fueled the equipment and positioned it in a suitable worksite, it is time to start your pressure washer. The following are the procedures necessary for safe, successful operation of your pressure washer. WARNING Carefully read and make sure you understand all instructions and safety information before using the pressure washer. - Page 23 Operation Attach garden Acquire a suitable garden hose and attach to the water supply. hose to water 1. Acquire a suitable garden hose: supply a. The water supply garden hose must have an inside diameter of at least 5/8”. If the hose is more than 100 ft. long, the diameter must be at least 3/4”.
- Page 24 Operation 3. Release the collar, making sure it springs back and re-seats to its original (non-retracted) position. (Figure 8b). Check the connection by pulling on the hose to ensure a positive connection. Correct Insertion Not Fully Inserted Figure 8b Collar Seated Collar NOT Seated Select spray Your pressure washer is equipped with five high-pressure nozzles and one...
-
Page 25: Step 2. Set Up For Chemical Spray (If Desired)
Operation 1. Make sure the engine is off and the hose line depressurized. 2. To install the nozzle, pull the collar back and twist the nozzle firmly into the coupler on the end of the wand. (Figure 9a) Lance Coupler Nozzle Collar Figure 9a... - Page 26 Operation The introduction of cleaning chemicals via the chemical injection point affords the following advantages: • It protects the pump from damage because no chemical passes through the pump. CAUTION: Certain chemicals, such as bleach or those containing muriatic acid, will cause pump damage if introduced upstream through the pump’s water inlet.
-
Page 27: Step 3. Spraying
Operation Step 3. Spraying Safety rules for Before starting the pressure washer, review the following general safety operation rules for operation: Conditions for Use Know how to stop. Be thoroughly familiar with proper use of the equipment and all controls and connections. Know how to stop the pressure washer and depressurize system quickly if needed (see “Step 6. - Page 28 Operation Lock trigger safety latch when not spraying. Spray gun is equipped with a built-in trigger safety latch to guard against accidental trigger release. Rotate safety latch to the locked position when not spraying. Leaving unattended. Always turn off the pressure washer and relieve system pressure before leaving the sprayer unattended.
- Page 29 Operation Start engine Start the engine to power the pump. 1. Make sure water supply is connected and primed. CAUTION: Running the pump dry will cause damage and void the warranty. 2. To prevent accidental spraying, engage the safety latch on spray gun trigger by rotating it to the locked position.
- Page 30 Operation 3. Make sure the engine throttle is all the way open. If it is not, the engine will not supply adequate voltage to the burner, resulting in smoke coming from the heat exchanger during operation. Turn the heat switch ON and adjust the thermostat to the desired temperature.
- Page 31 Operation If spraying from an elevated surface, use fall protection because spray gun kickback can propel you off the elevated surface. When spraying from a ladder or scaffolding, ensure it is firmly anchored from sway or tip-over. Be aware of puddles and slippery surfaces. Ensure there is adequate drainage to prevent pooling of water.
- Page 32 Operation 8. The pressure washer is set and locked to the maximum rated pressure when it leaves the factory. To reduce the pressure, turn the unloader knob counterclockwise. (See Figure 11 below) WARNING: Do not attempt to alter the unloader valve’s maximum pressure. Excess pressure could cause serious injury from escaping high- pressure fluids and/or pump damage.
-
Page 33: Step 4. Stopping
Operation Step 4. Stopping Stop the engine using the following steps: WARNING: Never disconnect the high-pressure hose from the pump or spray gun while the system is pressurized. Relieve pressure by squeezing the spray gun trigger after the engine is turned OFF. -
Page 34: Storage
Storage Storage When you are finished using the pressure washer, you must prepare the sprayer for storage and store it in a proper location. Note: o If you will be storing the sprayer in freezing conditions, follow the instructions for preparing the sprayer for storage in freezing conditions. - Page 35 Storage RV Antifreeze Funnel Hose Figure 12 Water Inlet 1. Drain the water from the high-pressure hose and spray gun by depressing the trigger on the spray gun until all water drains out. 2. Using a wrench, disconnect the plumbing that connects to the pump outlet.
- Page 36 Storage b. Add fuel stabilizer to fuel tank. c. Run pressure washer with high pressure hose at least 5 minutes after adding stabilizer to allow it to enter the fuel system. d. Shut off engine 2. Lubricate cylinder and piston: a.
-
Page 37: Burner Adjustment
Burner Adjustment Oil Burner Adjustment (only needed if white exhaust smoke appears) The oil burner is preset and performance tested at the factory (elevation 1100 feet). Different altitudes may require a one-time initial burner adjustment. CAUTION: If white smoke appears from the burner exhaust vent during start-up or operation, discontinue use and readjust air bands. - Page 38 Burner Adjustment 5. Loosen the locking screw and rotate the air band closed until black smoke appears from the burner exhaust vent. Note which number the arrow now points to. 6. Slowly open the air band until white smoke just starts to appear. 7.
-
Page 39: Maintenance And Repair
Maintenance & Repair Inspect and maintain your pressure washer as specified below in order to keep it in safe and optimal working order. Follow all safety rules and recommended maintenance instructions. WARNING ALWAYS shut off water supply, bleed water pressure, turn off engine and disconnect the spark plug before cleaning, adjusting, or servicing the pressure washer. - Page 40 Maintenance & Repair • Replacement parts. If a part needs replacement, only use factory approved repair parts. Replacement parts that do not meet specifications may result in a safety hazard or poor operation of the pressure washer and will void the warranty.
- Page 41 Maintenance & Repair Good Water dripping or spraying, or localized moisture Exposed wire mesh due to wear Figure 15 Clean inlet filter Clean the inlet filter before each use. WARNING: When cleaning filters, check whether dangerous chemicals have been used with the filter and take any precautions that may be recommended by the manufacturer of these chemicals.
- Page 42 Maintenance & Repair 3. Spark plug cleaning and replacement 4. Fuel filter check/replacement 5. Inspecting and cleaning muffler (and spark arrestor if equipped) Change pump oil Change the pump oil after the first 40 hours of use, and then after every 3 months or 500 hours of use after that.
- Page 43 Maintenance & Repair Maintain burner’s Drain water from burner’s filter bowl as needed, and replace filter fuel filter/water after every 500 hours of use or as needed. separator 1) After each use of the burner, visually check the filter bowl. If any water has accumulated, drain it via the water drain at the bottom of the bowl.
- Page 44 Maintenance & Repair FIG02333 Figure 18 Cleaning Flow Inspect and clean the flow switch as needed Switch Mineral build-up and/or debris within the flow switch can occur and may affect burner operation if not periodically cleaned. Mineral build-up and/or debris can stop the movement of the shuttle inside the flow switch body. Shuttle movement is important because the burner will not fire if the shuttle does not move.
- Page 45 Maintenance & Repair 3) Unthread the removable outlet fitting with the swivel still attached from the flow switch assembly 4) Remove the shuttle 5) Clean the inside of the brass flow switch body and the shuttle with water and a soft brush 6) Insert the shuttle into the brass flow switch in the orientation shown Note: Aligning the male tabs on the shuttle to the female guides inside the brass flow switch body can be difficult since the shuttle is magnetic...
- Page 46 Maintenance & Repair Inspect heating coil Inspect and desoot coil annually. and desoot as Most coils never require desooting. However, poor grades of fuel oil or inadequate combustion air will cause heavy soot build-up on the outside needed surface of the heating coil tubing. These deposits will insulate the coil, which then restricts airflow through the heat exchanger and further aggravates the soot build-up.
- Page 47 Maintenance & Repair Inspect electrodes Inspect electrodes yearly and make adjustments as needed. 1) Remove the 4 nuts that attach the burner to the heating chamber. You do not have to disconnect the fuel lines or the electric cords. 4 nuts Figure 22 FIG02335 2) Pull the burner out from underneath the heat exchanger.
- Page 48 Maintenance & Repair 4) Reset the spacing as shown below in Figure 24. Electrodes 1/16” 1/8” 5/16” Figure 24...
- Page 49 Maintenance & Repair NOTE TO COMMERCIAL USERS: All mechanical equipment, no matter how well designed, will need maintenance and repairs. A NorthStar pressure washer is no exception. At times, a NorthStar pressure washer may become inoperable because repairs are required. NorthStar Product Support will assist in these repairs as needed, but if an inoperable pressure washer creates a major expense to your business, then we strongly recommend the following: •...
-
Page 50: Troubleshooting
Troubleshooting Engine Will Not Start Causes Solutions Low Oil Shutdown Fill engine with the adequate amount of oil. Cold Engine Choke engine to start. No Fuel Add gas to engine, make sure fuel shutoff valve is open. Dead Battery Recharge/Replace battery. Spark plug wire not attached Attach spark plug wire to spark plug. -
Page 51: Parts Explosion
Parts Explosion – Rev M.1... - Page 52 Parts Explosion – Rev M.1 ITEM PART# DESCRIPTION ITEM PART# DESCRIPTION 777904 Quick Coupler, 1/4” FPT 38578 T-Handle Knob 22622 Gun Grip 30754 Leather Washer, .28 ID 1.00 OD 779168 Gun Trigger Assembly 777946 Tank and Base Weldment 313107 Coupler, 3/8” FPT 778049 Side Rail Weldment 777915...
-
Page 53: Wiring Diagrams
Wiring Diagram – Rev M.1 Ref # Description Part Number Burner Wire Harness 777661 Engine/Control panel Wire Harness 783421 Yellow Lead Wire - Switch to Relay 777663 Red Lead Wire – Circuit Breaker to Relay 777664 Black Battery Cable 777108 Wire Nut 5265 Red LED with wire leads... - Page 54 Control Panel Wiring Diagram – Rev M.1 Red LED 12V Relay Thermostat Switch Circuit Breaker...
- Page 55 Burner Wiring Diagram – Rev M.1...
-
Page 56: Summary Of Important Safety Information
Summary of Important Safety Information This section provides a summary of the various safety procedures and measures that have been presented throughout the manual. Keep this summary handy and refer to it to refresh your memory about how to safely use your pressure washer. WARNING Carefully read and understand the following safety information before using the pressure washer. - Page 57 Summary of Important Safety Information o When CONNECTING the battery, connect the RED cable to the POSITIVE terminal FIRST. o When DISCONNECTING the battery, disconnect the BLACK cable from the NEGATIVE terminal FIRST • Acid/skin contact. If battery acid contacts skin or clothing, flush immediately with water and neutralize with baking soda.
-
Page 58: During Use
Summary of Important Safety Information Safety – Operation Pre-start • Review safety rules. Before each use of this pressure washer, review the “Rules for Safe Operation.” Failure to follow these rules may result in serious injury or death. • Know how to stop. Be thoroughly familiar with proper use of the equipment and all controls and connections. - Page 59 Summary of Important Safety Information liquid under the skin. Injection injury can result in blood poisoning and/or severe tissue damage leading to infection, gangrene and possibly amputation. • Prevent surface damage & flying debris – Surfaces being sprayed must be strong enough to withstand high- pressure spray, or damage may result.
-
Page 60: After Use
Summary of Important Safety Information • Other exhaust dangers. This product contains or emits chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Avoid inhalation of exhaust. After use • Cool engine before storing. Let engine cool for at least five minutes before storing. A hot engine is a fire hazard. -
Page 61: Limited Warranty
Limited Warranty Dear Valued Customer: The NorthStar Product you just purchased is built with the finest material and craftsmanship. Use this product properly and enjoy the benefits from its high performance. By purchasing a NorthStar product, you show a desire for quality and durability. - Page 62 ® Manufactured by Northern Tool + Equipment Co., 2800 SouthCross Drive West P.O. Box 1499 Burnsville, MN 55337-0499...
