Page 1: User Manual
Snapshot Kinta™ X OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ..........................2 What is included ............................2 Unpacking Instructions ..........................3 AC Power ..............................3 Safety Instructions ............................ 3 2. Introduction ............................4 Features ..............................4 DMX Channel Summary ..........................4 Product Overview............................5 4. -
Page 3: Unpacking Instructions
There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Kinta™ X User Manual 12/16/2008 2:53 PM... -
Page 4: Introduction
2. I NTRODUCTION Features 2-channel DMX-512 LED derby effect Continuous rotation or back and forth motor control Built-in automated programs via master/slave or DMX Built-in sound activated programs via master/slave or DMX Additional Features High-power, 3W (730mA) LEDs Linkable with LED Mushroom and Double Derby™ X Mount multiple units together with adjustable, optional bracket (XBRACKET) Additional power output: max 37 units @ 120V and 70 units @ 230V DMX Channel Summary... -
Page 5: Product Overview
Product Overview DMX Out Dipswitches DMX In Sound sensitivity adjustment Power Power link Hanging/mounting bracket Bracket adjustment knob Kinta™ X User Manual 12/16/2008 2:53 PM... -
Page 6: Setup
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 7: Cable Connectors
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. Note! CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion: IN TO... -
Page 8: Master/Slave Fixture Linking
Master/Slave Fixture Linking 1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. 2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the input connector of the next fixture consisting of a (male) 3 pin connector. -
Page 9: Operation
5. O PERATING NSTRUCTIONS Operation Stand-Alone Mode (Sound-Active, Auto Mode): This mode allows a single unit to run to the beat of the music. Set dipswitches position to Sound Active or Auto Mode. Mode Dipswitches Sound Active 1-10= Off The unit will react to the low frequencies of music via the internal microphone in Sound Active mode Use the audio sensitivity knob on the back of the unit to make the unit more or less sensitive in Sound-Active mode. -
Page 10: Setting The Starting Address
SET T I NG T HE ST ART I NG ADDRESS This DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start address" from 1 to 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. - Page 11 233 – (128) = 105, Turn ON Dip # 8 Resolving address (DMX V IPSWITCH ALUE 105 – (64) = 41, Turn ON Dip # 7 using simple math. 41 – (32) = 9, Turn ON Dip # 6 9 – (8) = 1, Turn ON Dip # 4 Address 233 1 –...
-
Page 12: Dmx Quick Reference Chart
DMX Q UI CK REF ERENCE CH ART DMX Address Quick Reference Chart Dip Switch Position DMX DIP #9 0 0 0 SWITCH SET 0=OFF #8 0 0 0 1=ON #7 0 0 1 X=OFF or ON #6 0 1 0 #1 #2 #3 #4 #5 0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480... -
Page 13: Appendix
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) Kinta™... -
Page 14: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 15: General Troubleshooting
power the fixture and it will automatically enter into this mode If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. Kinta™ X User Manual 12/16/2008 2:53 PM... -
Page 16: Contact Us
Contact Us World Wide General Information CHAUVET 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084 Technical Support CHAUVET 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 (Press 4) fax: 954.929.5560 (Attention: Service) World Wide Web www.chauvetlighting.com...
