Summary of Contents for Chauvet Kinta X
-
Page 1: User Manual
Snapshot Kinta™ X OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL 5200 NW 108th Avenue, Sunrise, FL 33351 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. BEFORE YOU BEGIN ............................... 3 ....................................3 HAT IS NCLUDED ..................................3 NPACKING NSTRUCTIONS AC P ......................................3 OWER ..................................3 AFETY NSTRUCTIONS 2. INTRODUCTION ................................4 ......................................4 EATURES DMX C ..................................4 HANNEL UMMARY .................................... -
Page 3: Before You Begin
Do not daisy chain power to more than 37 units @ 120V and 70 @ 230V Caution! There are no-user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Kinta™ X User Manual Rev. 4... -
Page 4: Introduction
2. I NTRODUCTION Features • 2-channel DMX-512 LED derby effect • Continuous rotation or back and forth motor control • Built-in automated programs via standalone or DMX • Built-in sound activated programs via standalone Additional Features • High-power, 3W (730mA) LEDs •... -
Page 5: Product Overview
Product Overview DMX Out Dipswitches DMX In Sound sensitivity adjustment Power Power link Hanging/mounting bracket Bracket adjustment knob Kinta™ X User Manual Rev. 4... -
Page 6: Setup
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 7: Mounting
Mounting Orientation This fixture may be mounted in any safe position, provided there is adequate room for ventilation. Rigging Hanging Clamp It is important never to obstruct the fan or vents pathway. Mount the fixture using, a suitable “C” or “O” type clamp. Adjust the angle of the fixture by loosening both knobs and tilting the fixture. -
Page 8: Operating Instructions
5. O PERATING NSTRUCTIONS Operation Standalone Mode (Sound-Active, Auto Mode): This mode allows a single unit to run to the beat of the music. Set dipswitches position to Sound Active or Auto Mode. Mode Dipswitches Sound Active 1-10= Off The product will react to the low frequencies of music via the internal microphone in Sound Active mode Use the audio sensitivity knob on the back of the unit to make the unit more or less sensitive in Sound-Active mode. -
Page 9: Setting The Starting Address
Setting the Starting Address This DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start address" from 1 to 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. -
Page 10: Dmx Quick Reference Chart
DMX Quick Reference Chart DMX Address Quick Reference Chart Dip Switch Position DMX DIP #9 0 0 0 SWITCH SET 0=OFF #8 0 0 0 1=ON #7 0 0 1 X=OFF or ON #6 0 1 0 #1 #2 #3 #4 #5 0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480 1 0 0 0 0... -
Page 11: Appendix
Products returned without an RMA # will be refused. Call CHAUVET® and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the customer’s responsibility. -
Page 12: General Troubleshooting
power the fixture and it will automatically enter into this mode If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. Kinta™ X User Manual Rev. 4... -
Page 13: Technical Specifications
DMX Channels ..................................2 ORDERING INFORMATION Kinta™ X ..................................KINTAX Optional bracket ..............................XBRACKET WARRANTY INFORMATION Warranty ............................2-year limited warranty Contact Us World Wide General Information CHAUVET 5200 NW 108th Avenue Sunrise, FL 33351 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084...
