- Page 1 E-TON Beamer & Beamer Matrix Scooters OWNER’S MANUAL Model years 2004 through 2008 Rev 3.01 8-0904 Copyright ©2008-2009 ETON America, all rights reserved.
-
Page 2: Important Notices
Dear Customer, Thank you for choosing the ETON Beamer. This scooter was made in accordance with the international QS9000 standards and the directives of the European parliament and council. It conforms to all Federal DOT regulations for a class A moped. It was engineered and designed to provide a reliable form of economic transportation for your life style. -
Page 3: Table Of Contents
Table of Contents Vehicle identification number location Controls, switches and feature locations Control feature operations Engine stop switch Turn Signal Switch Horn Button Engine Manual Choke Lever Head Light Control Switch Ignition Switch Instrument Cluster Throttle Control Throttle Cable Adjustment Brake Systems Front and Rear brakes Front Hydraulic Brake Inspection... -
Page 4: Vehicle Identification Number Location
Vehicle Identification Numbers Vehicle Identification Number (VIN) is Engine serial number is located on the located on the frame behind the foot left-hand side of the engine on the guard and is covered by a small plastic crankcase housing. cover plate which can be removed with a screwdriver. -
Page 5: Control Feature Operations
Control feature operations sound the audible horn signal. Releasing the button will silence the horn. Engine Manual Choke Lever The engine choke lever is used to enrich the fuel mixture when starting the engine from a cold start. Start by moving the lever to the left to choke the engine. -
Page 6: Ignition Switch
Instrument Cluster The instrument cluster provides you with operating conditions of your vehicle. To the left is the fuel gauge which indicates the fuel Ignition Switch level in the fuel tank. When the needle The ignition switch is located on the control reaches the red zone on the gauge, you are column’s right side below the handlebars. -
Page 7: Throttle Control
Throttle Cable Adjusting To adjust the throttle cable’s free play, slide the protective cover down the cable to expose the cable adjusting system. Loosen the locking nut and adjust the cable length by turning the adjusting collar. Check the free travel in the throttle hand grip until you have Throttle Control . -
Page 8: Front Hydraulic Brake Inspection
The fluid level should fill at least ¾ of site glass when the unit is setting on a level surface. Test the brakes by applying pressure to the brake lever and trying to push the unit forward. If the wheel rotates while the brakes are applied, check your fluid level and brake pads. -
Page 9: Purging The Brake Lines
the brake cable with a commercial cable Purging Brake Lines lubricant available through your dealer. For the hydraulic brake system to operate safely, the brake system must be purged of air in the lines and Test the rear brake by applying pressure to reservoir. -
Page 10: Fuel System
Fuel System or replace the seal if it becomes worn or torn. The seal must be in good condition to insure a proper seal of the cap to the tank to prevent fuel spills. DO NOT allow dirt or other debris to enter the tank when refueling. Replace the cap if damaged or if it will not seal to the tank. -
Page 11: Engine Oil
Engine Oil Your vehicle uses 2 cycle oil to lubricate the engine. The oil tank is located under the seat at the front of the unit. Oil is drawn from this tank by an oil injector pump when the engine is operating. Oil Level Warning Light tank cover retaining screw and lifting the cover. -
Page 12: Transmission Oil Change
Install the new plug screwing it in finger tight Changing Transmission Oil and then use the plug wrench to screw the 1. Place an oil catch pan under the unit plug in another ½ turn. directly below the transmission box. Inspect the spark plug wire for cuts, nicks or 2. - Page 13 To clean the filter Remove the air filter box cover. Remove the filter element from the air box. Wash the element in a non-flammable solvent such as Air-Filter cleaner from your local auto parts dealer. 1. Dry the element completely before continuing.
-
Page 14: Electrical Battery
There is an inline fuse on the positive lead of Electrical Battery the battery to protect the wiring system from over loads. If your starter motor will not turn over and the battery is fully charged, check the inline fuse on the unit. Replace the fuse with a 7A fuse. -
Page 15: Beamer Break-In Procedure
11. Insure you are wearing proper Beamer Break-In clothing and protective gear, such as procedures helmet and hard soled shoes. Your Beamer requires a break-In period just as with all other internal combustion engines. This Starting Procedure period allows the engine parts to seat and wear properly without undue strain which can cause The following procedure must be followed premature failure. -
Page 16: Parking
Beamer. When carrying a passenger, always It is not recommended to operate this vehicle insure that they place their feet on the passenger in slippery conditions such as on snow or ice pedals. Always keep your feet on the footrests covered roads. -
Page 17: Specifications
Beamer Scooter Specifications Beamer II & Matrix (Models - PN2B & PN2C) Engine Type Two cycle air cooled oil injected Displacement 49.3cc 40.0 * 39.2mm Bore / Stroke Compression 6.8 : 1 Power 5.2hp @ 7000rpm Transmission Type Automatic (C.V.T. V-Belt) Chassis Overall Length 1830mm / 72.0"... -
Page 18: Maintenance Schedule
I: Inspect and Clean, Adjust, Lubricate, or Replace (if necessary) C: Clean L: Lubricate R: Replace NOTE: E-TON recommends that all maintenance and inspections be performed ONLY by a qualified and fully trained technician! Page 17 Rev 3.01 8-0904 Copyright ©2008-2009 ETON America, all rights reserved. -
Page 19: Wiring Diagrams
2004-2006 Beamer, Beamer II & Matrix Wiring Diagram Page 18 Rev 3.01 8-0904 Copyright ©2008-2009 ETON America, all rights reserved. -
Page 20: Wiring Diagrams
2007-2008 Beamer III & Matrix II Wiring Diagram Page 19 Rev 3.01 8-0904 Copyright ©2008-2009 ETON America, all rights reserved. -
Page 21: Reporting Safety Defects
NHTSA Safety Notice If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying ETON America, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. -
Page 22: Manufacturer's Warranty
ETON AMERICA, LLC. LIMITED VEHICLE WARRANTY ETON America warrants all new ETON vehicles sold by authorized Eton Dealers to be free from defects in materials and workmanship, subject to the following exclusions and limitations. New vehicles sold by an authorized dealer to original retail consumers are covered by this policy for a period of six (6) months from the date of delivery. - Page 23 ETON AMERICA, LLC. LIMITED VEHICLE WARRANTY Scheduled maintenance service is the responsibility of the owner during and after the warranty period. In the event of a failure or required repair, the owner should take the vehicle to an authorized dealer for repair without undue delay and within a maximum of thirty (30) days of the occurrence of the problem.
-
Page 24: Owner's Notes
Owner’s Notes: Page 23 Rev 3.01 8-0904 Copyright ©2008-2009 ETON America, all rights reserved. - Page 25 Owner’s Notes: Page 24 Rev 3.01 8-0904 Copyright ©2008-2009 ETON America, all rights reserved.
- Page 26 ETON AMERICA, LLC. LIMITED VEHICLE WARRANTY ETON America warrants all new ETON vehicles sold by authorized ETON Dealers to be free from defects in materials and workmanship, subject to the following exclusions and limitations. New vehicles sold by an authorized dealer to original retail consumers are covered by this policy for a period of six (6) months from the date of delivery.
- Page 27 ETON AMERICA, LLC. LIMITED VEHICLE WARRANTY LIMITATIONS. This Limited Vehicle Warranty shall not cover any of the following: Repairs or replacement required as a result of (i) accident, (ii) misuse or neglect, (iii) lack of reasonable and proper maintenance, (iv) repairs improperly performed or replacement improperly installed, (v) use of replacement parts or accessories not conforming to ETON America LLC specifications which adversely affect performance and/or durability, (vi) alterations or modifications not recommended or approved in writing by ETON America LLC,...
- Page 28 ETON America LLC SCOOTER/MOPED LIMITED WARRANTY FEDERAL EMMISSION CONTROL SYSTEMS ETON America LLC warrants each new scooter/moped vehicle that includes as standard equipment a taillight and a stoplight; Is designed, built and equipped so as to conform at the time of initial retail purchase with all applicable regulation of the United States Environmental Protection Agency (“US EPA”) and: Is free from defects in material and workmanship which would cause such Scooter/moped vehicle to fail to conform with applicable regulations of the US EPA, for a time period of two and a half (2.5) years and, depending on the engine displacement:...
- Page 29 Page 28 Rev 3.01 8-0904 Copyright ©2008-2009 ETON America, all rights reserved.
