RocketFish RF-AHD25 User Manual

RocketFish RF-AHD25 User Manual

2.5" sata hard drive enclosure kit
Hide thumbs Also See for RF-AHD25:
Table of Contents

Advertisement

Quick Links

See also: User Manual
v4
R1
2.5" SATA Hard Drive Enclosure
Kit
RF-AHD25
User Guide

Advertisement

Table of Contents
loading

Related Manuals for RocketFish RF-AHD25

Summary of Contents for RocketFish RF-AHD25

  • Page 1 2.5" SATA Hard Drive Enclosure RF-AHD25 User Guide...

  • Page 2: Table Of Contents

    Introduction Congratulations on your purchase of the Rocketfish RF-AHD25 SATA Hard Drive Enclosure Kit. You can install a high-speed SATA hard drive into this enclosure and connect it to a computer using either a USB 2.0 or eSATA port. This kit offers a backup function, allowing you to backup, restore, and synchronize your data.

  • Page 3: Safety Information

    • One-button backup to easily backup, restore, and synchronize data between your Windows PC and the enclosure in USB mode. • Has one power on with backup active indicator. • Rapid heat dissipation. • Supports Plug-and-Play and is hot swappable. RF-AHD25...

  • Page 4: Package Contents

    Package contents • 2.5" SATA hard drive enclosure • USB cable • eSATA cable • Two CDs • Quick Setup Guide • 5 Volt/1 amp AC adapter • An extra swappable cover plate • Carrying bag • Accessories: • Screwdriver •...

  • Page 5: Identifying Components

    Identifying components Front DC power jack Backup button eSATA port Mini USB port Back Switch lock RF-AHD25...

  • Page 6: Using The Hard Drive Enclosure

    Status indicators Operation Description mode Starting mode Solid The hard drive is turned on. Active mode Flashing Data is being transmitted between your computer and the hard drive. Disconnect mode The hard drive is turned off. Using the hard drive enclosure Installing your hard drive in the enclosure Read these safety precautions before you install your hard drive in the enclosure:...
  • Page 7 To install your 2.5" SATA hard drive in the enclosure: 1 Move the switch lock from the locked to the unlocked position, then open the case. 2 Remove the four screws from the printed circuit board and remove the circuit board from the enclosure. RF-AHD25...
  • Page 8 3 Securely connect the drive to the SATA connector on the printed circuit board. 4 Secure the drive to the bottom of the printed circuit board with the four provided screws.
  • Page 9 6 Insert the tab from the top of the enclosure into the slot and snap the lid into place. Then slide the switch to the locked position. Slot RF-AHD25...

  • Page 10: Connecting The Enclosure To Your Computer

    Connecting the enclosure to your computer Before connecting your external storage enclosure: • Confirm that your system supports SATA. If your system does not support SATA, please install an eSATA host card. • Confirm that the eSATA port on your system is working properly.
  • Page 11 If your motherboard does not, follow these steps to set up your RF-AHD25: 1. Shut down your computer. 2. Turn on your RF-AHD25, then connect it to your computer. 3. Power on your computer. Notes: Windows 2000/XP/Vista/7 No drivers are necessary when using Windows XP/2000/Vista.

  • Page 12: Installing The Software

    To disconnect the enclosure from your Macintosh computer without shutting it down: 1 Drag the USB icon into the TRASH. 2 Unplug the enclosure. Installing the software The installation CD includes backup software to enable you to back up your files. Note: This Roxio BackOnTrack software runs only on Windows 7, Windows Vista, and Windows XP computers using USB.
  • Page 13 3 Click Install Roxio® BackOnTrack™ 3 LE. The Welcome screen opens. RF-AHD25...
  • Page 14 4 Click NEXT. The Roxio End-User License Agreement screen opens.
  • Page 15 5 Read the license agreement, then click NEXT to agree. The Customer Information screen opens. RF-AHD25...
  • Page 16 6 Enter your information, then click NEXT. The Choose Setup Type screen opens.
  • Page 17 7 Choose the setup type, then click Install to start installation. It may take several minutes to install the software. RF-AHD25...
  • Page 18 8 When installation is complete, the Setup Wizard Completed screen opens. 9 Click FINISH to complete the installation.

  • Page 19: Using Your Enclosure

    Using your enclosure Starting Roxio BackOnTrack To start Roxio BackOnTrack: 1 Press the backup button (the button with the Rocketfish logo on it) on the front of the enclosure. Or, click Start, BackOnTrack, then click BackOnTrack Home. The first time you run the software, the Product Registration screen opens.

  • Page 20: Appendix

    2 Complete the Product Registration information as prompted (first time only). The main screen opens. 3 To back up or restore files, follow the on-screen guide. For help, press F1 or click Help. Appendix Creating A New Partition Note: The best way to partition a new hard drive is by using the manufacturers program.
  • Page 21 If you are using a new hard drive, you may need to initialize it first. Initialize your internal hard drive using Drive Setup from the Mac OS CD that came with your computer. 1 Start up your computer from the Mac OS CD. RF-AHD25...
  • Page 22 2 Locate the Utilities folder on the Mac OS CD and double-click it to open the folder. 3 Double-click the Drive Setup icon to open the program. 4 In the list of drives, select the drive you want to initialize. 5 Click Initialize.

  • Page 23: Troubleshooting

    • Your computer may not be able to recognize the partition on the hard drive because it is damaged or not a valid format. Refer to “Creating A New Partition” on page 20. for information on how to create a useable partition on your drive. RF-AHD25...
  • Page 24 My computer does not detect the enclosure • Check the power adapter and make sure the adapter is working. • Make sure all of the cables and plugs are securely fastened. • Make sure that the SATA cable or the USB cable is connect firmly to your enclosure and computer.

  • Page 25: Specifications

    One power on with backup active indicator OS compatibility • Windows 2000 • Windows XP • Windows Vista • Windows 7 • Mac OS X 10.3 or higher Operating temperature 32°F~104°F (0°C~40°C) Operating humidity 20% ~ 80% RH Certification FCC Class B, ICES-003 RF-AHD25...

  • Page 26: Legal Notices

    Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 27 Canada ICES-003 statement This Class B digital apparatus complies with Canadian ICES-003. RF-AHD25...

  • Page 28: One-Year Limited Warranty

    Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you. If service of Products and parts are required after the Warranty Period expires, you must pay all labor and parts charges.
  • Page 29 • Damage due to incorrect operation or maintenance • Connection to an incorrect voltage supply • Attempted repair by anyone other than a facility authorized by Rocketfish to service the Product • Products sold as is or with all faults • Consumables, such as fuses or batteries...
  • Page 30 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2010 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 31 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2010 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
