Furuno 1835 Quick Manual

10.4 Multi-Color LCD RADAR
1835/1935/1945
Model
SPECIFICATIONS OF MODEL 1835/1935/1945
ANTENNA RADIATOR
Type
MODEL 1835 Printed array
MODEL 1935/1945 Slotted waveguide array
Length and Rotation Speed
MODEL 1835 Radome 60 cm (RSB-0071) 24 RPM
MODEL 1935 Open 100 cm (XN10A) 24 or 48 RPM
MODEL 1945 Open 120 cm (XN12A) 24 or 48 RPM
Wind Load (for MODEL 1935/1945)
24 RPM 100 kn relative wind
48 RPM 70 kn relative wind
Beamwidth
ANT9210: Hor. 4.0°, Vert. 20°
XN10A: Hor. 2.4°, Vert. 22°
XN12A: Hor. 1.9°, Vert. 22°
RF TRANSCEIVER
9410 ± 30 MHz (X-band)
Frequency
Output Power
MODEL 1835/1935 4 kW
MODEL 1945 6 kW
DISPLAY
Screen Size 10.4" color LCD
640 (H) x 480 (V), VGA
Pixel Number
158 mm
Effective Diameter
32 levels
Echo Colors
Head-up, Course-up*, North-up*,
Display Modes
True view*, True motion**
* Heading data required
** Heading and position data required
nm, sm, km
Range Units
Range Scales and Range Ring Intervals (nm)
Range: 1/16, 1/8, 1/4, 1/2, 3/4, 1, 1.5, 1.6, 2, 3,
3.2, 4, 6, 8, 12, 16, 24, 32, 36, 48*, 64**
Rings: 1/32, 1/16, 1/8, 1/4, 1/2, 0.8, 1, 2, 3, 4,
6, 8, 12*, 16**
* For MODEL 1935/1945
** For MODEL 1945
25 m
Minimum Range
25 m
Range Discrimination
Echo Trails
Type True or relative trails
Trail Length: 15, 30 sec., 1, 3, 6, 15, 30 min.,
or continuous Trail
Trail Width: Narrow, Normal
Target Tracking (Required optional board ARP-11)
Acquisition: Auto, Manual
Number of targets: 10 targets max
AIS Functions (Data input from AIS is required)
Symbols: Sleeping, Activated, Dangerous, Selected, Lost targets
Number of targets: 100 targets max.
INTERFACE
AD-10 or IEC 61162 NMEA0183 Ver. 1.5/2.0/3.0
Input
IEC 61162 NMEA0183 Ver. 1.5/2.0/3.0
Output
ENVIRONMENT
Temperature
Antenna Unit: -25°C to +55°C (-13°F to +131°F)
Display Unit: -15°C to +55°C (5°F to +131°F)
Waterproofing
Antenna Unit: IEC60529 IP26
Display Unit: IEC60529 IP55
POWER SUPPLY
MODEL 1835 12-24 VDC: 4.1-2.0 A
MODEL 1935 12-24 VDC: 6.8-3.3 A for 24 rpm
8.2-3.8 A for 48 rpm
MODEL 1945 12-24 VDC: 7.3-3.5 A for 24 rpm
8.8-4.1 A for 48 rpm
EQUIPMENT LIST
Standard
1. Display Unit 1 unit
2. Antenna Unit (Specify when ordering) 1 unit
3. Antenna Cable
MODEL 1835 10, 15, 20 or 30 m 1 pc
MODEL 1935/1945 10, 15, 20 or 30 m 1 pc
4. Power Cable 5 m 1 pc.
5. Installation materials and spare parts 1 set
Option
1. Auto Plotter ARP-11
2. Rectifier
MODEL 1835 PR-62
MODEL 1935/1945 RU-3423
3. External Alarm Buzzer OP03-21
4. Interface Cable
MJ-B24LPF0010 10, 20, or 30 m
MJ-A7SPF0007-050C 5 m
MJ-A6SPF0007-100C 10 m
MJ-A10SPFW0001+R 0.2 m
5. Antenna Bracket (for MODEL 1835) OP03-92
All brand and product names are registered trademarks, trademarks
or service marks of their respective holders.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
12033SK Printed in Japan
Catalogue No. R-196b
10.4 Multi-Color LCD RADAR
1835/1935/1945
Model
Enhanced
Bonded
Target
AUTO AIS
Sunlight Viewable
LCD
Tracking
Auto Tuning AIS Target Tracking Bonded LCD Enhanced
(Sensitivity) Sunlight Viewable
