Summary of Contents for Grundig RP 6402 DAB
-
Page 1: Dab Radio
PORTABLE DAB RADIO RP 6402 DAB... -
Page 2: Environmental Note
SAFETY, INFORMATION _____________________ ENGLISH Safety To ensure that this device provides you with long-term satisfaction and enjoyment, please observe the following instructions. This device is designed for the playback of audio signals. Any other use is expressly prohibited. Protect the device from moisture (water drops or splashes). Do not place any vessels such as vases on the device. - Page 3 OVERVIEW ____________________________________________ Controls Front Switches the device on and off. ON/OFF Switches between the DAB and FM (VHF) input sources. DAB/FM In DAB mode: press briefly to activate the “local” •FULL TUNE AUTO TUNE station search (Band III, 11B - 12D), hold down to activate the full station search (Band III, 5A - 13F).
- Page 4 OVERVIEW ____________________________________________ 6 V DC 1000 mA Top: Telescopic antenna for DAB and FM reception. Antenna Right side of device Volume control dial. – Left side of device Earphone socket (3.5 mm stereo socket); automatically switches off the loudspeaker. Connection socket for mains adapter supplied, DC 6V 1000 mA input voltage 6V (1000 mA).
-
Page 5: Power Supply
OVERVIEW ____________________________________________ Power supply Battery operation Open the battery compartment on the back of the device by pressing the marking and opening the lid. Insert the batteries (4 x 1.5 V, LR20/AM1/D-Size). Notes: 4 x 1.5 V (LR 20, AM1, D) The lifetime of the batteries with every day usage (at normal volume) is approximately 30 hours. - Page 6 SETTINGS ______________________________________________ Searching for and saving DAB stations Your device has a DAB (Digital Audio Broadcasting) input source which enables crystal-clear radio reception in CD quality, i.e. without hissing or crackling. DAB stations are combined into ensembles (multiplexes) at regional and national levels.
- Page 7 SETTINGS ______________________________________________ Sorting stations After the station search, the station list can be arranged in four different ways. Press »•MENU INFO« until » « appears in the Station order œ æ œ Station order æ display. Press » « to confirm the option. Station order œ...
- Page 8 SETTINGS ______________________________________________ Searching for and saving FM stations Automatic station search Press » « briefly. TUNING Press »SELECT SCAN«. 100.60MHz ST FM – Display: The automatic search stops at the next station up or down (depending on whether you first press » «...
-
Page 9: General Information
OPERATION __________________________________________ General information Switching on and off Press »ON/OFF« to switch the device on and off. – The device switches on with the DAB or FM station last selected. Selecting the input source Select the input source (DAB or FM) with »DAB/FM«. Now tuning... - Page 10 OPERATION __________________________________________ Selecting stored stations Select the preset number by pressing the station buttons »1 ... 5«. – The station is played. Checking the signal strength (only in DAB mode) You can check the signal strength of the station being listened to. Press »SELECT SCAN«...
-
Page 11: Displaying Rds Station Information
OPERATION __________________________________________ FM mode Selecting the FM input source Press »DAB/FM« to select FM as the input source. 100.60MHz ST FM – Display: »FM« and the frequency, soon followed by the station name of RDS stations. Selecting stored stations Select the preset number by pressing the station buttons »1 ... -
Page 12: Technical Data
INFORMATION _____________________________________ This device is noise-suppressed according to the applicable EU directives. This product fulfils the European directives 89/336/EEC, 73/23/EEC and 93/68/EEC. This device conforms to the safety regulation DIN EN 60065 (VDE 0860) and therefore the international safety regulation IEC 60065. Technical data Power supply Battery operation... - Page 13 Grundig Multimedia B.V. • Atrium, Strawinskylaan 3105 • NL-1077 ZX Amsterdam • http://www.grundig.com...
