Gigabyte 6BXC User Manual

Gigabyte 6BXC User Manual

For intel pentium ii / iii / celeron processor mainboard
Hide thumbs Also See for 6BXC:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
USER'S MANUAL
1.
System power on by PS/2 Mouse: First, enable this function
in CMOS Setup, then you can power on the system by
double clicking the right or left button of your PS/2 Mouse.
2.
System power on by Keyboard: If your ATX power supply
supports
larger
(dependent on the specification of keyboards), you can
power on your system by entering password from the
keyboard after setting the "Keyboard power on" password in
CMOS Setup.
3.
Supports 3 steps ACPI LED.
4.
Modem Ring-On. (COM A , B).
5.
Wake-Up on LAN. (on JP7) (The ATX power supply supports
larger than 720 mA 5V Stand-By current)
For Intel Pentium
6BXC
than
300
mA
5V
II / III / Celeron Processor MAINBOARD
REV. 2.0 First Edition
R-20-01-090429
Stand-By
current

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte 6BXC

Summary of Contents for Gigabyte 6BXC

  • Page 1 6BXC USER'S MANUAL System power on by PS/2 Mouse: First, enable this function in CMOS Setup, then you can power on the system by double clicking the right or left button of your PS/2 Mouse. System power on by Keyboard: If your ATX power supply...
  • Page 3 6BXC The author assumes no responsibility for any errors or omissions which may appear in this document nor does it make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 4 Quick Installation Guide I. Quick Installation Guide : CPU SPEED SETUP The system bus speed is selectable between 66 / 100 MHz. The user can select the system bus speed (SW1) and change the DIP SWITCH (SW2) selection to set up the CPU speed for 233 - 633MHz processor. Set System Bus Speed SW1: 100 MHz...
  • Page 5 6BXC + The black part in the picture is the white extruding piece of the DIP switch. 1. Pentium II /Celeron 233 / 66 MHz FSB Intel 440BX PIIX4 2. Pentium II /Celeron 266 / 66 MHz FSB 4 3 2 1 4 3 2 1 3.
  • Page 6 Quick Installation Guide 5. Pentium II /Celeron 366 / 66MHz FSB 4 3 2 1 4 3 2 1 6. Pentium II /Celeron 400 / 66MHz FSB 4 3 2 1 4 3 2 1 7. Pentium II /Celeron 433 / 66MHz FSB 4 3 2 1 4 3 2 1 8.
  • Page 7 6BXC 11. Pentium III 500 / 100 MHz FSB 4 3 2 1 4 3 2 1 12. Pentium III 550 / 100 MHz FSB 4 3 2 1 4 3 2 1 13. Pentium III 600 / 100 MHz FSB...
  • Page 8 Quick Installation Guide II. Jumper setting : SPK : Speaker Connector Function Intel 440BX Data PIIX4 RE : Reset Switch Open: Normal operation Intel 440BX Short: Reset system PIIX4...
  • Page 9 6BXC PW LED : Power LED Connector Function Intel 440BX LED anode(+) LED cathode( ) LED cathode( ) PIIX4 HD : IDE Hard Disk Active LED Function LED anode(+) Intel 440BX LED cathode( ) PIIX4 Function LED anode(+) LED cathode( )
  • Page 10 Quick Installation Guide IR : Infrared Connector (Optional) Function Intel 440BX IR Data Output IR Data Input PIIX4 POWER (+) GN : Green Function Switch Open: Normal operation Intel 440BX Short: Entering Green mode PIIX4...
  • Page 11 6BXC GD : Green LED Intel 440BX Function LED anode(+) LED cathode( ) PIIX4 PW: Soft Power Connector Intel Open: 440BX Normal Operation Short: Power On/Off PIIX4...
  • Page 12 Quick Installation Guide POWER1 : Power Connector Function Intel 3,5,7,13, 440BX 15-17 1,2,11 3.3V 4,6,19,20 VCC (+5V) PIIX4 +12V Power Good 5V SB (Stand by +5V) PS-ON (Soft ON/OFF) PS/2 Mouse / Keyboard Connector PS/2 Mouse PS/2 Mouse/Keyboard Function Data Intel 440BX VCC (+5V)
  • Page 13 6BXC CPU FAN : CPU Cooling Fan Power Connector Function +12V Intel SENSE 440BX PIIX4 IDE1: For Primary IDE port Intel 440BX PIIX4...
  • Page 14 Quick Installation Guide IDE2: For Secondary IDE port Intel 440BX PIIX4 FLOPPY : FLOPPY PORT Intel 440BX PIIX4...
  • Page 15 6BXC LPT PORT / COM A / COM B LPT PORT Intel 440BX PIIX4 COM B COM A JP1 : Keyboard Power On Selection Intel 440BX 1-2short: Enable Keyboard Power On. PIIX4 2-3short: (Default) Disable Keyboard Power On.
  • Page 16 Quick Installation Guide USB : USB Port Function USB V0 USB D0 Intel USB D0+ 440BX USB V1 USB D1 PIIX4 USB D1+ J15: System After AC Back Intel 440BX OPEN: Soft Off (Default) CLOSE: Full On Function PIIX4 Signal...
  • Page 17 6BXC JP7: Wake On LAN JP7 1 Intel 440BX Function +5V SB PIIX4 Signal JP8:SB-LINK Creative PCI Sound Card Support Intel 440BX Function Signal PIIX4 Signal Signal...
  • Page 18 Quick Installation Guide JP10 : System Acceleration 1-2 Turbo Intel 440BX 2-3 100MHz Normal Default: 2-3 100MHz Normal 1-2 Turbo: PIIX4 For 100MHz Turbo and BAT1 other frequencies 2-3 100MHz Normal: For 100MHz Normal Power FAN : Power Fan Power Connector Function +12V Intel...
  • Page 19 6BXC System FAN : System Fan Power Connector Intel 440BX Function PIIX4 +12V SENSE JP11:CLEAR CMOS FUNCTION Intel 440BX 1-2 Short :Clear CMOS 2-3 Short :Normal Default: 2-3 Short PIIX4 BAT1...
  • Page 20 Quick Installation Guide Internal Ring Power On Function Intel 440BX Function Signal PIIX4 BAT1 JP12 & JP13 (This function is support in PCB version 2.0 and above) JP13 JP12 Open :Normal (Default) Intel 440BX JP13 JP12 Close :For Voodoo3 VGA card PIIX4 BAT1...
  • Page 21 6BXC BAT1 :Battery Intel 440BX PIIX4 BAT1 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’ s instructions.
  • Page 22 Quick Installation Guide III. Top Performance Test Setting: The following performance data list is the testing results of some popular benchmark testing programs. Users have to modify the value for each item in chipset features as follow for top performance setting.
  • Page 23 6BXC These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (Different Hardware & Software configuration will result in different benchmark testing results.) Pentium II processor DRAM 128 MB SDRAM (SEC KM48S8030BT-GH)

  • Page 25: Table Of Contents

    Table of Contents TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE ...................... 1-1 1.2. KEY FEATHERS.................... 1-1 1.3. PERFORMANCE LIST .................. 1-2 1.4. BLOCK DIAGRAM..................1-3 1.5. INTRODUCE THE PENTIUM II / III PROCESSOR........1-4 1.6. WHAT IS AGP ....................1-5 SPECIFICATION 2.1.
  • Page 26 6BXC 3.11. PERIPHERAL DEVICE INSTALLATION ............ 3-9 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION........... 3-9 BIOS CONFIGURATION 4.1. ENTERING SETUP ..................4-1 4.2. CONTROL KEYS................... 4-1 4.3. GETTING HELP..................... 4-2 4.3.1. Main Menu ..................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu....... 4-2 4.4.

  • Page 27: Introduction

    Introduction INTRODUCTION 1.1. PREFACE Welcome to use the 6BXC motherboard. It is a Pentium II / III / Celeron Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.

  • Page 28: Performance List

    6BXC 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (Different Hardware & Software configuration will result in different benchmark testing results.)

  • Page 29: Block Diagram

    Introduction 14.318MHz 1.4. BLOCK DIAGRAM SLOT 1 3.3V SDRAM DIMM Sockets Host Bus 66 / 66 / 100 MHz 100 MHz INTEL 33MHz 82443BX AGP Bus 66 / CHIPSET 66MHz 100 MHz ICS 9148-26 33 MHz Ultra DMA/33 IDE Ports PCI Bus 33 MHz PIIX4...
  • Page 30 6BXC 1.5. INTRODUCE THE Pentium II / III Processor Figure 1: Universal Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor...

  • Page 31: What Is Agp

    Introduction Figure 3: OEM Pentium III Processor 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs.32-Bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing.

  • Page 33: Specification

    6BXC SPECIFICATION 2.1. HARDWARE Pentium II/ III/ Celeron processor 233 – 633 MHz. 242 pins 66 / 100MHz slot1 on board. 66/100 MHz system speed. SPEED 66 MHz AGP bus speed. (2X mode 133MHz) 33 MHz PCI-Bus speed. 8 MHz AT bus speed.

  • Page 34: Software

    Specification Suspend mode support. GREEN FUNCTION Green switch & ACPI LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. 2M bits FLASH RAM. BIOS Supports Plug & Play, DMI Function. ATX Form Factor, 4 layers PCB. DIMENSION 2.2.

  • Page 35: Hardware Installation

    6BXC HARDWARE INSTALLATION 3.1. UNPACKING The main board package should contain the following: The 6BXC main board. Universal Retention Mechanism & Attach Mount USER’ S MANUAL for main board. Cable set for IDE, Floppy devices. Diskette or CD for main board Utility.

  • Page 36: Mainboard Layout

    Hardware Installation 3.2. MAINBOARD LAYOUT PCB Ver : 1.9 COM A COM B PS/2 SLOT5 SLOT3 SLOT1 BIOS PCI 4 PCI 3 PCI 2 PCI 1 JP10 Intel 440BX SW 1 PWR FAN BANK 0 DIMM 1 PIIX4 BAT1 BANK 1 DIMM 2 BANK 2 DIMM 3...

  • Page 37: Quick Reference For Jumpers & Connectors

    6BXC 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. IDE 1 For Primary IDE port. IDE 2 For Secondary IDE port. PS/2 For PS/2 Keyboard port. PS/2 For PS/2 Mouse port. Floppy For Floppy port COM B For Serial port2 (COM B).[Support Modem ring on.]...
  • Page 38 Hardware Installation J15 : System After Ac Back Open Soft Off Short Full On JP1 : Keyboard Power On Selection Pin No. Function Enabled Keyboard power on. Disabled Keyboard power on.(Default) JP10 : System Acceleration 1-2 short For 100MHz Turbo and other frequencies 2-3 short For 100MHz Normal (Default) JP7 : Wake on LAN Connector...
  • Page 39 6BXC IR: INFRARED Connector (OPTIONAL) Pin No. Function IR DATA OUTPUT IR DATA INPUT POWER¡] ¡ Ï ¡ ^ JP12&JP13(This function is support in PCB version 2.0 and above) Pin No. Function Open Normal Close For Voodoo3 VGA card JP9 : 2*11PIN Jumper...

  • Page 40: Dram Installation

    Hardware Installation SPK: Speaker Connector PIN 1 : VCC (+) PIN 2 : NC PIN 3 : NC PIN 4 : Data ( HD: IDE Hard Disk Active LED PIN 1: LED anode (+) PIN 2: LED cathode ( ) GN: Green Function Switch Open : Normal operation Short : Entering Green Mode...

  • Page 41: Cpu Speed Setup

    6BXC 3.5. CPU SPEED SETUP The system bus speed can be set to 66 / 100MHz form the DIP SWITCH (SW1). The user can change the DIP SWITCH (SW2) selection to set up the CPU speed for different processors. The CPU speed must match with the frequency RATIO and Front Side Bus (FSB) speed.

  • Page 42: Cmos Rtc & Isa Cfg Cmos Sram

    Hardware Installation 3.6. CMOS RTC & ISA CFG CMOS SRAM There're RTC & CMOS SRAM on board; they have a power supply from external battery to keep the DATA inviolate & effective. The RTC is a REAL- TIME CLOCK device, which provides the DATE & TIME to system. The CMOS SRAM is used for keeping the information of system configuration, so the system can automatically boot OS every time.
  • Page 43 6BXC 3.11. PERIPHERAL DEVICE INSTALLATION After the I/O device installation and jumpers setup, the main board can be mounted into the case and fixed by screw. To complete the main board installation, the peripheral device could be installed now. The basic system needs a display interface card.
