TABLE OF CONTENTS
1.
1.1. PREFACE.............................................................................................................1-1
1.2. KEY FEATURES ..................................................................................................1-1
1.3. PERFORMANCE LIST.........................................................................................1-2
1.4. BLOCK DIAGRAM ...............................................................................................1-2
1.6. What is AGP .......................................................................................................1-6
2.
2.1. HARDWARE ........................................................................................................2-1
2.2. SOFTWARE.........................................................................................................2-2
2.3. ENVIRONMENT...................................................................................................2-2
3.
3.1. UNPACKING ........................................................................................................3-1
3.2. MAINBOARD LAYOUT ........................................................................................3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS ................................3-2
3.4. DRAM INSTALLATION........................................................................................3-5
3.5. CPU SPEED SETUP ...........................................................................................3-5
3.6. CMOS RTC & ISA CFG CMOS SRAM................................................................3-6
3.7. SPEAKER CONNECTOR INSTALLATION ........................................................3-6
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION.......................3-7
3.9. POWER LED CONNECTOR INSTALLATION ...................................................3-7
II Processor ..........................................................1-3
Table of Contents
Advertisement
Table of Contents
Related Manuals for Gigabyte 6BXS
Summary of Contents for Gigabyte 6BXS
-
Page 1: Table Of Contents
Table of Contents TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM ....................1-2 1.5. INTRODUCE THE Pentium II Processor ............1-3 1.6. What is AGP .......................1-6 SPECIFICATION 2.1. HARDWARE ......................2-1 2.2. SOFTWARE......................2-2 2.3. ENVIRONMENT....................2-2 HARDWARE INSTALLATION 3.1. - Page 2 6BXS 3.10. IDE & ATAPI DEVICE INSTALLATION.............3-7 3.11. SCSI DEVICE INSTALLATION ................3-7 3.12. PERIPHERAL DEVICE INSTALLATION............3-10 3.13. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-10 BIOS CONFIGURATION 4.1. ENTERING SETUP .....................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.3.1. Main Menu....................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu.......4-2 4.4.
-
Page 3: Introduction
Introduction INTRODUCTION 1.1. PREFACE Welcome to use the 6BXS motherboard. It is a Pentium II Processor based PC / AT compatible system with AGP / PCI / SCSI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
6BXS 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware &... -
Page 5: Block Diagram
Introduction 1.4. BLOCK DIAGRAM 14.318MHz SLOT1 3.3V EDO/SDRAM DIMM Sockets Host Bus INTEL 66/100 82443BX AGP Bus 66/100 CHIPSET DRAM Bus 66MHz Clock Gen Buffer 66/100MH Clock Gen Ultra DMA/33 IDE Ports PCI Bus 66 / 100 PIIX4 48MHz 82371EB 14.318MHz USB Ports IDE Bus... -
Page 6: Introduce The Pentium Ii Processor
6BXS 1.5. INTRODUCE THE Pentium II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor... - Page 7 Introduction Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...
-
Page 8: What Is Agp
6BXS 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32- bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. -
Page 9: Specification
Specification SPECIFICATION 2.1. HARDWARE Pentium II processor 200 – 633 MHz. 242 pins 66/100MHz slot1 on board. Speaker Alarm when detect "CPU FAN Failure" or PROTECTION “ CPU Overheat” . Automatically slow down CPU speed when "CPU Overheat". Intel LDCM supported. -
Page 10: Software
6BXS Supports 1 Ultra Wide SCSI port. SCSI PORTS Supports 1 Ultra SCSI port. Supports 2 16550 COM ports. I/O PORTS Supports 1 EPP/ECP LPT port. Supports 1 Floppy port. Supports 2 USB ports. Supports PS/2 Mouse & Keyboard. Suspend mode support. -
Page 11: Hardware Installation
Hardware Installation HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 6BXS mainboard. The Retention Mechanism & Attach Mount USER'S MANUALS for mainboard & . SCSI device. Cable set for IDE, Floppy, SCSI & I/O devices. Diskettes and CD for Mainboard Utility. -
Page 12: Mainboard Layout
6BXS 3.2. MAINBOARD LAYOUT COM A COM B PS/2 ISA3 ISA2 ISA1 BIOS SLOT1 PCI4 PCI3 PCI2 PCI1 INTEL 443BX BANK0 PIIX4 BANK1 BANK2 BANK3 6BXS FLOPPY adaptec AIC-7880P IDE2 IDE1 Soft Power PW Led ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. - Page 13 Hardware Installation SPK : SPEAKER Connector Pin No. Function Output RST : RESET Switch Pin No. Function RESET Input PWR : POWER ON LED ( PW-LED) Pin No. Function LED POWER (+) HD : Hard Disk active LED (HD-LED) Pin No. Function LED POWER (+) LED POWER (-)
- Page 14 6BXS Soft PWR : Soft Power Switch Pin No. Function CTRL-Signal FAN PWR: CPU cooling FAN Power Connector Pin No. Function GND. +12V SENSE J13 : System After Ac Back Pin No. Function Signal JP1 : Keyboard Power On Selection Pin No.
-
Page 15: Dram Installation
Hardware Installation 3.4. DRAM INSTALLATION The mainboard can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO & 67~100 MHz for SDRAM. The DRAM memory system on mainboard consists of bank 0, 1, 2 &... -
Page 16: Cmos Rtc & Isa Cfg Cmos Sram
6BXS DIP SWITCH (SW) FREQ. EXT.CLK. INT.CLK. CPU Type RATIO Pentium II 233 MHz Pentium II 266 MHz Pentium II 300 MHz Pentium II 333 MHz Pentium II 366 MHz Pentium II 300 MHz Pentium II 350 MHz Pentium II 400 MHz... -
Page 17: Hardware Reset Switch Connector Installation
Hardware Installation 3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION The RESET switch on panel provides users with HARDWARE RESET function. The system will do a cold start after the RESET switch is pushed and released by user. The RESET switch is a 2 PIN connector and should be installed to RST on mainboard. - Page 18 6BXS Terminator ON/OFF rules CASE 1: BIOS SETUP (Signal Ended Termination: Both) System has 16 bit SCSI 16 bit 16 bit SCSI DEVICE SCSI DEVICE SCSI ID SCSI ID Mainboard No.15 No.0 Terminator ON Terminator OFF Terminator ON System has only 8 bit SCSI device...
- Page 19 Hardware Installation CASE 2: BIOS SETUP (Signal Ended Termination: High Byte) System has 16 bit & 8 bit SCSI device 16 bit 16 bit 8 bit 8 bit SCSI DEVICE SCSI DEVICE SCSI DEVICE SCSI DEVICE Mainboard Terminator ON Terminator OFF Terminator OFF Terminator ON High byte Terminator ON...
-
Page 20: Peripheral Device Installation
6BXS 3.12. PERIPHERAL DEVICE INSTALLATION After the I/O device installation and jumpers setup, the mainboard can be mounted into the case and fixed by screw. To complete the mainboard installation, the peripheral device could be installed now. The basic system needs a display interface card.
