Pro-Form 800 Manual page 9

11. Insert two 19mm Round Inner Caps (33) into each
of the two Short Pad Tubes (34). Slide the Short
Pad Tubes through the holes in the Leg Lever (7).
Slide two Leg Pads (22) onto each of the Short
Pad Tubes.
12. Insert Weight Rest Inserts (20) into the top and
bottom of a Weight Rest (19). Slide the Weight
Rest onto the right Upright (1). Attach a Large
Adjustment Knob (21) to the welded nut on the
Weight Rest and tighten it with a wrench. Pull out
the Large Adjustment Knob and slide the Weight
Rest to the desired height. Snap the Knob into a
hole in the Upright and turn it clockwise to secure
it in place.
Insert a 76mm Round Inner Cap (18) into the top
of the right Upright (1).
Repeat this step for the left Upright (1).
Note: Always place both Weight Rests (19) at the
same height for use.
13. Make sure that all the bolts and nylon locknuts are properly tightened before using the weight
bench. The use of all remaining parts will be explained in Adjusting the Weight Bench, starting on page 10.
11
22
33
34
33
12
18
19
20
9
7
33
22
20
21
1
