PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M8 Split Wave Washer
M6 Split
M8 x 25mm M10 x 25mm
Washer (95)––2
Washer
Washer (98)––6 Washer (36)––2
(83)––11
(111)––12
#10 x 12.7mm M4 x 16mm M8 x 19mm
M8 Locknut
Screw (59)––12 Screw
Screw (82)––15
(102)––4
(104)––10
M8 x 38mm
M8 x 56mm
Bolt (96)––4
Screw (94)––2
M8 x 80mm
M10 x 20mm
Screw (84)––2
Screw (66)––2
6
