- Page 1 MCDV72iP /iPhone/iPad DVD Micro Hi-Fi System with Docking for iPod USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN...
- Page 2 South Australia Victoria South South South Australia Australia Australia Victoria Victoria Victoria Thank Thank selecting selecting selecting a a a a TEAC TEAC TEAC product product Thank Thank you you for for selecting TEAC product product TEAC TEAC Customer Customer...
- Page 3 TEAC PRODUCT WARRANTY PERIOD TEAC TEAC TEAC PRODUCT PRODUCT PRODUCT WARRANTY WARRANTY WARRANTY PERIOD PERIOD PERIOD...
- Page 4 CAUTION! Dangerous voltage may be present inside the product! To reduce the risk of electric shock, do not open or remove the cover or back. No user-serviceable parts inside. Only qualified service personnel can repair and maintain this product. Place the product on a straight, solid and stable place. Place the product in a sufficiently ventilated place to avoid overheating.
- Page 5 Never turn the unit off or disconnect a USB Storage Device (Flash Drive) when it is being accessed. Doing so could damage the MCDV72iP and the connected USB storage device. Do not use a device that has a maximum current consumption of 100 mA or more.
- Page 6 - Troubleshooting..............................12 - Specifications.................................13 INTRODUCTION Thank you for choosing this TEAC product. It is equipped with Ipod docking ,enabling you to enjoy the music and video from your ipod /ipod touch/ iphone/ipad Equipped with a digital PLL tuner, enabling you to easily search and memorise FM radio channels,...
- Page 7 1.OPEN/CLOSE 7.DISPLAY 2.SOURCE 8.REMOTE CONTROL SENSOR 3.PREV 9.POWER 4.VOL- 10.NEXT 5.PLAY/PAUSE 11.ENTER 6.DVD TRAY 12.VOL+ 13.USB PORT 1.Component(Y Cb Cr) Video Output 5.AUX IN L/R 2.L/R Stereo audio Output 6.Composite Video 3.Coaxial Output 7.FM Antenna 4.Speaker L/R 8.S-video Output...
- Page 8 1. Power/Standby 21. Open/Close 2. Source 22. Subtitle 3. OSD 23. Repeat 4. Step 24. A-B 5. V-Mode 25. CD Ripping 6. N/P 26. Slow 7. Title 27. Zoom 8. Menu/PBC 28. DVD/USB 9. Setup 29. Return/Auto Scan 10. UP 30.
- Page 9 The figure below shows the unit connection setup and all possible connections to external devices WARNING: Ensure that the AC power is turned off when making or changing cable connections. Note: When connecting this product's speaker wires to the main unit, note the white markings on the wires and make the connections consistent (ie.
- Page 10 OPERATION WITH IPOD/IPHONE/IPAD 1. Dock an iPod onto the unit’s Dock Connector . 2. Press the Power button to turn the unit on . 3. Press the SOURCE button to switch to iPod mode . 4. Press ► button to begin playing the docked iPod . 5.
- Page 11 14. PAUSE While playing in DVD/USB/iPod , press the PAUSE button on the remote control or front panel to pause playback. 15. PLAY Press to start or resume program playback 16. L/R During VCD/SVCD playback,press L/R repeatedly to select the channel of audio-output: Left/Right/ Mix/Stereo.
- Page 12 25. CD RIP This function converts audio CD tracks to convert to MP3 file format. After the CD has been loaded, press CD RIP on remote, a CD ripping menu will display. Follow the options and set your requirements. SPEED: Change ripping speed from Normal to Fast. Bitrate: The encoding bitrate from 96,112,128kbps or above.
- Page 13 36. MUTE During playback, press the MUTE button to silence the audio completely. Press the button again to revert to the original volume. 37. GOTO In DVD Mode, press to go to to your desired position directly via this function. 38.39 /CH- /CH+...
- Page 14 REFERENCE Problem Solution Unit has no power Battery is flat infra-red at infra-red sensor window sensor properly Place an audio CD in the No audio CD inserted disc compartment CD will not play Distorted or intermittent sound Unit cannot be operated...
- Page 15 Power supply ............~240VAC 50 Hz Power consumption ..........30W MAX) Frequency response..........20Hz-20kHz (±3dB) Distortion ............≤ 0.7% Supported format …………………………………CD, CD-R/RW, DVD-R/RW,DVD+R/RW USB supported size up to ..……………………… 16GB Multi Media supported file and format ..…………FLAC, MP3, WMA, AVI, JPEG, XVID Frequency range.…….…….…….…….…………..FM 87.5 - 108MHZ Supported system file ………………….…………FAT, FAT32 Dimensions ............153(W) x200(H) x235(D) mm...
