Setting up a wired Ethernet network

We recommend using category 5, unshielded, twisted-pair cable (approximately 1/4" in
diameter with a thin outer-jacket, containing eight color-coded wires), and equipment
compatible with this type of cable. This type of cable is equipped with RJ-45 connectors
(like a large telephone jack connector, but with eight pins) on each end.
Important
Setting up a network using a router
If you are setting up a network for more than two computers and you will be connecting
your network to a high-speed Broadband Internet connection (cable or DSL modem), we
recommend the use of a router. A router lets you access the Internet connection from any
network computer. The router can assign IP addresses to the computers on the network
and can provide firewall protection for your network as well.
In addition to a router, you need a straight-through cable for each computer you want to
connect to the network.
For more information about configuring a wireless network, click
Start, then click Help and Support. Type the keyword wireless
network in the Search box
arrow.
Category 5 cables are available in two different types; straight-through
cables, used to connect computers to a router, and crossover cables,
used to connect two computers.
To determine which type of cable you have, hold both ends of the
cable with the connectors facing away from you and with the spring
clip on the bottom. For straight-through cable, the wires on both
connectors are attached to copper pins in the same order (same
colors, left to right). For a crossover cable, the wires on each
connector are attached to the copper pins in a different order (different
colors, left to right).
www.gateway.com
Creating an Ethernet network
, then click the
97
