Related Manuals for BBQ 720-0001
Summary of Contents for BBQ 720-0001
- Page 1 Item # 41054 ASSEMBLY & OPERATING INSTRUCTIONS FOR OUTDOOR GAS GRILL ® PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE FOR MODEL 720-0001 OUTDOOR GRILL...
-
Page 2: Table Of Contents
This unit is not intended for commercial use. Distributed by L G Sourcing Inc. P.O. Box 1535, North Wilkesboro, NC 28659 Model # 720-0001, BBQ Grillware™ Failure to follow these instructions could result in fire or explosion which could cause property... -
Page 3: Illustrated Parts Breakdown
ILLUSTRATED PARTS BREAKDOWN MODEL 720-0001 TABLE-TOP GRILL MODEL 720-0001 -LP PARTS LIST REF# Description Lid, Front 1 SET Bowl Assembly Handle Assembly 1 SET Handle Assembly 1 SET Cooking Grid Flame tamer 1 PC Flame tamer 1 PC Grease Tray... -
Page 4: Safety Instructions
Safety Instructions READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE SURE YOUR GRILL IS PROPERLY INSTALLED, ASSEMBLED AND MAINTAINED. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE. IF YOU HAVE QUESTIONS CONCERNING ASSEMBLY OR OPERATION, CALL OUR SERVICE CENTER AT 1-800-913-8999, MONDAY THROUGH FRIDAY 8:OOAM-5:OOPM, PACIFIC COAST TIME. -
Page 5: The Location For Your Grill
Safety Instructions Read carefully before assembling and operating your gas grill. INSTALLATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 or CSA B149.1, Natural Gas and Propane Installation Code. - Page 6 Safety Instructions This position provides cooking temperatures between HIGH and LOW. This position provides the lowest cooking temperatures. ONLY A FACTORY SUPPLIED GAS VALVE/REGULATOR SHOULD BE USED. See parts list for replacement items. LP GAS REGULATOR CAUTION The gas pressure regulator provided with this appliance must be used. This regulator is equipped with the required orifice and is set for the required outlet pressure for this appliance.
- Page 7 COOKING TEMPERATURE SETTINGS HIGH - Approximately 450 degrees F MED - Approximately 400 degrees F LOW - Approximately 350 degrees F NOTE: A disposable 1 lb. Cylinder “NEAR EMPTY” can significantly reduce or will significantly reduce internal pressure and may affect the regulator’s capability to accurately control gas flow. This may cause hotter-than-normal cooking temperatures during the final few minutes of cylinder use as it reaches empty.
-
Page 8: Assembly Instruction
Assembly Instructions PLEASE READ THE INSTRUCTION CAREFULLY AND FOLLOW STEP BY STEP. Your BBQ Grillware Table Top Grill is pre-assembled. The only part that you need to assemble is to connect gas regulator into your grill. The estimated time for one person to assemble to table top grill is 5 to 8 minutes. -
Page 9: Lighting Instruction
Lighting Instructions 1. Make sure the regulator is properly secured into the burner end. 2. Make sure the propane cylinder is tightly threaded into the regulator-hand-tighten only. 3. Open lid. 4. Locate lighting access hole on right side of the panel. 5. -
Page 11: Lighting Rod Assembly Instruction
Lighting Rod Assembly Instructions PLEASE READ THE INSTRUCTION CAREFULLY AND FOLLOW STEP BY STEP. 1. Please locate the lighting rod located on the right side of your table top grill. Please see the following figure. Lighting Rod... - Page 12 2. Please attach the match to the front end of the lighting rod, and stick the lighting rod into the access to manual lighting hole to light the fire as indicated in below picture. Access to manual lighting...
-
Page 13: Care And Maintenance
Care & Maintenance There is very little care and maintenance needed. The BBQ Grillware Table Top Grill is designed and made of materials that will last many years with normal use. Following these instructions will improve the longevity and quality of cooking. To ensure safe operation of your grill, the area of cooking should always be kept free of combustible materials of any type, such as gasoline or other flammable vapors or liquids. -
Page 14: Cooking Instruction
Cooking Instructions 1. Allow grill to warm up with lid closed for 20-30 minutes prior to cooking. 2. This BBQ Grillware Table Top Grill model is equipped with an adjustable HIGH/MED/LOW burner control. This allows for complete flexibility in cooking temperatures. HIGH setting has a cooking temperature of approximately 450 degrees F. -
Page 15: Trouble Shooting
TROUBLE SHOOTING 1. The smell of gas in conjunction with the burner SPIDER AND INSECT WARNING!!! Spiders and insects can nest in the burners of the flames appearing yellow. grill and cause the gas to flow from the front of the 2. -
Page 16: Limited Warranty
LIMITED WARRANTY MODEL 720-0001 STAINLESS STEEL OUTDOOR GAS GRILL Nexgrill Industries, Inc. warrants to the original consumer purchaser of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below.
