Page 1: Repair Parts
™ OWNERS MANUAL Model No. 45-04381 40" FRONT MOUNT TINE DETHATCHER Safety CAUTION: Assembly Read Rules for Operating Safe Operation Maintenance and Instructions Repair Parts Carefully the fastest way to purchase parts www.speedepart.com FORM NO. 42688 (09/12/12) PRINTED IN USA... - Page 2 Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times, when using power equipment. • Read safety rules in the vehicle owners manual and • When de-thatching do not drive too close to a creek or know how to operate your equipment, before using the ditch and be alert for holes and other hazards which tine dethatcher. could cause you to lose control of the vehicle. • Never operate vehicle and tine dethatcher attachment • Before operating vehicle on any grade (hill) refer to the without wearing substantial footwear, and do not allow safety rules in the vehicle owners manual concerning safe anyone to ride or sit on the tine dethatcher. operation on slopes. STAY OFF STEEP SLOPES. • Never allow children to operate the tractor or • This equipment is not meant for street or highway use.
- Page 3 PART NO. QTY DESCRIPTION PART NO. QTY DESCRIPTION 44326 Carriage Bolt, 5/16-18 x 1" 43343 Hairpin Cotter, 1/8" 43063 Hex Bolt, 5/16-18 x 1" 46838 Spacer, .8" x 1" x .5" 43001 Hex Bolt, 3/8-16 x 1" 44044 Clevis Pin, 3/8" x 3/4" 43087 Hex Bolt, 3/8-16 x 1-1/4" 43055 Hairpin Cotter, 3/32" 43069 Carriage Bolt, 3/8-16 x 1-1/2" 47810 Nylock Nut, 5/16-18 R19212113 Flat Washer, 5/8" HA21362 Nylock Nut, 3/8-16 PART NO. QTY DESCRIPTION PART NO. QTY DESCRIPTION 24876 Mounting Arm 24043...
- Page 4 • Remove any front mounted attachments which may Stop engine and let muffler cool before be installed on your tractor. attempting to install dethatcher hitch brackets. • Mark all loose parts and save for reassembly. LEFT END TINES POINT TO FRONT...
- Page 5 APPLY OIL...
- Page 6 ATTACHING DETHATCHER TO TRACTOR • If the front of your tractor has front mounting holes as shown in figure 7, continue on to figure 8. • If the front of your tractor DOES NOT have front mounting holes, go to figure 9. FRONT MOUNTING HOLES • Remove two self threading bolts (if present) from SELF THREADING BOLT front cross-member of tractor. Assemble bolts through FRONT lower slots in hitch bracket, then reinstall them back into front crossmember. (Make sure notches at top of hitch bracket and crossmember are aligned.) • From behind tractor's front crossmember, insert two 3/8" x 1" hex bolts (3) through holes in crossmember and through upper slots in hitch bracket. Secure with two 3/8" nylock hex nuts (12). • Go to figure 11 on page 7. SELF THREADING BOLT FIGURES 9 AND 10 ARE ONLY FOR TRACTORS WITH NO FRONT MOUNTING HOLES.
- Page 7 • Assemble the frame mount bracket (27) to the tractor frame using four 3/8" x 1-1/2" carriage bolts (5), spacers (8) and 3/8" nylock nuts (12). The spacers (8) go between the tractor frame and the frame mount bracket. FRONT...
- Page 8 • Attach dethatcher to hitch plate by placing mounting FRONT OF TRACTOR shaft into slots at front of hitch plate. Dethatcher mounting arms go to inside of hitch plate. Assemble SLOT keeper plates onto ends of mounting shaft and secure with (large) 1/8" hairpin cotters. HITCH PLATE MOUNTING SHAFT (LARGE) 1/8" KEEPER HAIRPIN COTTER PLATE • Raise and lock dethatcher in transport position (see operation instructions on pages 9 and 10). Move MOUNTING tractor with front mounted dethatcher onto a level ARMS surface, such as a drive or garage floor. Lower the tine AXLE dethatcher from transport position to rest on the level BUSHING surface. ANGLE BRACKETS • Adjust tine shield until spring tines come in contact with level surface, keeping front and back tines at the same height. Tighten carriage bolts securing...
-
Page 9: Customer Responsibilities
CUSTOMER RESPONSIBILITIES • Read and follow the maintenance schedule and the maintenance procedures listed in this section. MAINTENANCE SCHEDULE Fill in dates as you Service Dates complete regular service. Check for loose fasteners Lubrication CHECK FOR LOOSE FASTENERS LIFT HANDLE • Before each use check all nuts and bolts for tightness. Tighten loose fasteners before using. SMALL HAIRPIN COTTER LUBRICATION • Before each use apply a small amount of motor oil between washer and wheel bearing and between washer and top of axle bushing. See figure 16. HANDLE LOCK BRACKET LIFT HANDLE CLEVIS PIN LIFT HANDLE BRACKET FIGURE 16... - Page 10 KNOW YOUR DETHATCHER Leveling the dethatcher • Move tractor with front mounted dethatcher onto a level surface, such as a drive or garage floor. • Lower dethatcher from transport position to rest on LIFT HANDLE level surface. • Loosen carriage bolts through mounting arms and angle brackets. (Refer to figure 3 on page 5.) • Adjust tine shield until spring tines come in contact with level surface, keeping front and back tines at same height. Tighten mounting arm carriage bolts on top of dethatcher shield to lock adjustment. See figure 20. • If you need more adjustment, try moving the axle bushing up or down between the mounting arms. Be HANDLE sure to retighten the bolts securing the bushing. See LOCK figure 20. BRACKET MOUNTING ARMS AXLE BUSHING ANGLE BRACKETS LIFT HANDLE...
- Page 11 40" TINE DETHATCHER MODEL 45-04381 PART NO. QTY DESCRIPTION PART NO. QTY DESCRIPTION 44326 Carriage Bolt, 5/16-18 x 1" 23666 Angle Mount Bracket 43063 Hex Bolt, 5/16-18 x 1" 62601 Lift Handle Bracket 43001 Hex Bolt, 3/8-16 x 1" 43943 Plastic Grip 43087 Hex Bolt, 3/8-16 x 1-1/4" 27453 Hitch Plate 43069 Carriage Bolt, 3/8-16 x 1-1/2" 26043 Mounting Shaft R19212113 Flat Washer, 5/8" 24043 Lift Handle Arm 43343 Hairpin Cotter, 1/8"...
-
Page 12: Repair Parts
the fastest way to purchase parts www.speedepart.com REPAIR PARTS Agri-Fab, Inc. 809 South Hamilton Sullivan, IL. 61951 217-728-8388 © 2006 Agri-Fab, Inc. www.agri-fab.com...
