- Page 1 User Manual...
-
Page 2: Table Of Contents
Configuration (DMX) ........................11 Starting Address ..........................11 DMX Channel Modes, Assignments, and Values ............... 12 4-Channel ............................12 LFS-75DMX Color Wheel ......................12 Configuration (Standalone) ......................13 Manual Mode ............................. 13 Display Orientation ..........................13 Temperature Display .......................... 13 Reset Software .......................... -
Page 3: Before You Begin
Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within 7 days of delivery. Text Convention Meaning 1—512... -
Page 4: Product At A Glance
This product is not intended for permanent installation. · Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner. Page 4 of 17 LFS-75DMX User Manual... -
Page 5: Introduction
2. I NTRODUCTION Overview Gobo Door Knob Framing Shutter (x4) Gobo Door DMX In/Out 5-pin Power DMX In/Out Power In 3-pin Fuse Power Top Panel View Holder Switch LFS-75DMX User Manual Page 5 of 17... -
Page 6: Overview (Cont.)
Overview (cont.) Control Panel and Buttons Bottom Panel View Page 6 of 17 LFS-75DMX User Manual... -
Page 7: Dimensions
Dimensions 15.1 in 385 mm 11.1 in 283 mm 13.6 in 345 mm LFS-75DMX User Manual Page 7 of 17... -
Page 8: Setup
3. S ETUP AC Power The LFS-75DMX has a dual voltage power supply and it can work with an input voltage of either 120 V, 60 Hz or 230 V, 50 Hz, depending on the position of the voltage selection switch. -
Page 9: Power Linking
Diagram Additional Products You can power link up to 8 LFS-75DMX units on 120 VAC or up to 14 LFS-75DMX units on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET®... -
Page 10: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The LFS-75DMX may be mounted in any position; however, make sure adequate ventilation is provided around the product. · Rigging Before deciding on a location, always make sure there is easy access to the product for maintenance and programming. -
Page 11: Operation
DMX mode uses. If you choose a starting address that is too high, you could restrict the access to some of the product’s channels. The LFS-75DMX uses up to 4 DMX channels in its 4-channel DMX mode, which defines the highest configurable address to 509. -
Page 12: Dmx Channel Modes, Assignments, And Values
Orange Red + Dark Blue 120 ó 127 Dark Blue + White 128 ó 191 Rainbow effect with increasing speed 192 ó 255 Reverse rainbow effect with increasing speed LFS-75DMX Color Wheel Orange Kelly Dark Blue Light Blue White Section 5... -
Page 13: Configuration (Standalone)
To reset the software in the LFS-75DMX, do the following: Press <MODE/ESC> repeatedly until rESt shows on the display. Press <ENTER>. Load Factory To load the factory default settings in the LFS-75DMX, follow the instructions below: Defaults Press <MODE/ESC> and until LoAd shows on the display. Press <ENTER>. -
Page 14: Included Gobos
Included Gobos Changing To change the gobos in the LFS-75DMX, do the following: Disconnect the product from power. Gobos Place the product on a flat, level surface. Loosen the gobo door thumbscrew and pull off the gobo door. Pull up the gobo holder out of the product. -
Page 15: Technical Information
Gently polish the external optics and glass/transparent surfaces until they are free of haze and lint. Always dry the external optics and glass/transparent surfaces carefully after cleaning them. Do not spin the cooling fan using compressed air because you could damage it. LFS-75DMX User Manual Page 15 of 17... -
Page 16: Technical Specifications
1 mm max thickness Thermal Maximum External Temp. Cooling System 104 °F (40 °C) Fan-cooled I/O Connectors Connector Type Channel Range 3- and 5-pin XLR Sockets Ordering Product Name Item Code UPC Number LFS-75DMX 08120673 781462210212 Page 16 of 17 LFS-75DMX User Manual... -
Page 17: Returns
You must send the merchandise prepaid, in its original box, and with its original packing and accessories. CHAUVET® will not issue call tags. Clearly label the package with the RMA number. CHAUVET® will refuse any product returned without an RMA number.
