About this manual ™ You can use this device as a companion device to some Samsung Android smartphones or tablet PCs. This user manual is specially designed to explain applications and features that are available when the device is connected to a mobile device. •...
Table of Contents Getting started Gear Manager Device layout About Gear Manager Button Configuring the device settings Package contents Customising the Home screen Charging the battery Managing applications Wearing the device Finding the device Turning the device on and off Activating the auto lock feature Connecting to a mobile device Activating the notification features...
Page 5
Table of Contents Timer Today’s Schedule Voice Memo Weather Settings About Settings Clock Sound Volume Display Battery Bluetooth Motions Privacy lock Language Reset Gear Gear info Troubleshooting...
Getting started Device layout Touch screen Power button Microphone Camera Microphone Buckle Charging terminals Strap Speaker Humidity and liquids may damage your device. Keep your device dry. • D o not use a screen protector. This causes sensor malfunctions. •...
Getting started Button Button Function • P ress and hold to turn the device on or off. • P ress and hold for 8-10 seconds to reset the device if it has fatal errors or hang-ups, or freezes. Power •...
Getting started Charging the battery Use the charging dock to charge the battery before using it for the first time. A computer can be also used to charge the device by connecting them via the USB cable. Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.
Page 9
Getting started Place the device on the charging dock with the charging terminals facing each other. Close the cover of the charging dock.
Page 10
Getting started Plug the small end of the charger into the multipurpose jack of the charging dock, and plug the large end of the charger into an electric socket. Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty.
Getting started Checking the battery charge status When you charge the battery while the device is off, the following icons will show the current battery charge status: Charging Fully charged Wearing the device Release the buckle. • B e careful not to damage your fingernails when you release the buckle. •...
Getting started Press the buckle until it clicks. Turning the device on and off When turning on the device for the first time, follow the on-screen instructions to connect the device to a smartphone or tablet PC and set up your device. Press and hold the Power button for a few seconds to turn on the device.
Getting started Connecting to a mobile device By connecting the device to another mobile device, you can use applications and features on the connected mobile device. To connect the device to another mobile device, use the charging dock that has an NFC tag and an embedded Bluetooth address that matches your device.
Page 14
Getting started Connecting manually If your mobile device does not have an NFC feature you must connect the devices manually. The steps and screens may vary depending on the mobile devices. Access Samsung Apps on the mobile device, and then download and install Gear Manager.
Page 15
Getting started Check the ID number on the device, and then select the device with the same number on the detected devices list. Accept the auto-generated passkey on both devices to confirm the connection. Read and agree to the terms and conditions. Using applications after connecting to a mobile device When the device is connected to a mobile device using the Bluetooth feature, you can use the following features and applications:...
Getting started • S Voice: Command the device by voice. • T oday’s Schedule: View today’s events. • W eather: View weather information. Locking and unlocking the device When not in use, lock the device to prevent unwanted operation. Pressing the Power button on the Clock screen turns off the screen and puts the device into lock mode.
Getting started Switching to silent mode Use one of the following methods: • P ress and hold the Power button, and then tap Sound or Vibrate. • O n the Home screen, scroll to Apps, tap Apps → Settings → Sound → Sound mode → Vibrate or Mute.
Basics Indicator icons The following icons provide information about the status of the device. These icons appears when you double-tap the screen with two fingers. Icon Meaning Bluetooth feature activated Another Bluetooth device connected Battery power level Using the touch screen Use only fingers to use the touch screen.
Page 19
Basics Finger gestures Tapping To open an application, to select a menu item, or to press an on-screen button, tap it with a finger. Tapping and holding Tap and hold the screen with two fingers to open the list of recent applications.
Page 20
Basics Double-tapping • D ouble-tap on an image to zoom in a part. Double-tap again to return. • D ouble-tap the screen with two fingers to access the brightness and volume control panel and view indicator icons and the remaining battery life.
Basics Flicking Flick left or right on the Home screen or the Applications screen to see another panel. Pinching Spread two fingers apart on an image to zoom in a part. Pinch to zoom out. Notifications Once the device is connected to a mobile device and the mobile device is locked, you can receive notifications of activities, such as missed calls or new messages.
Basics Home screen The Home screen is the starting point to access all of the device’s features. It displays the clock, widgets, shortcuts to applications, and others. The Home screen can have multiple panels. To view other panels, scroll left or right. Panels on the Home screen Number Application or feature...
Basics Clock screen Press the Power button to open the Clock screen. On the Clock screen, you can launch Dialler by flicking up and launch Camera by flicking down. Tap the weather information to launch Weather. Applications screen The Applications screen displays icons for all applications. On the Home screen, scroll to Apps, and then tap Apps to open the Applications screen.
Basics Returning to the previous screen While using applications or on the Applications screen, flick down from the top of the screen. Securing the device Prevent others from using or accessing personal data and information stored in the device by using the pattern lock.
Basics Unlocking the device Turn on the screen by pressing the Power button, and enter the unlock code. Or, connect to the mobile device again to unlock the device automatically. Bluetooth Bluetooth creates a direct wireless connection between two devices over short distances. To activate Bluetooth, on the Applications screen, tap Settings →...
Basics Pairing with other Bluetooth devices When the other Bluetooth device sends a request to pair with, accept the auto-generated passkey on the device to confirm. Sending files to a mobile device To send images or videos, on the Applications screen, tap Gallery, select a file, and then tap →...
Basics Answering a call When a call comes in, drag to the right. If the call waiting service is active, another call can be made. When the second call is answered, the first call is put on hold. Rejecting a call When a call comes in, drag to the left.
Gear Manager About Gear Manager This application allows you to connect to a mobile device, customise your device settings and applications, and use features of the connected mobile device. From the connected mobile device, tap Gear Manager on the Applications screen. Configuring the device settings Access device information and update device software.
Gear Manager Customising shortcuts Adding shortcuts Tap My Apps → Favourites. Tap , select applications, and then tap Done. You can add up to 10 shortcuts. Rearranging shortcuts Tap My Apps → Favourites. Tap , tap and hold next to the application name, drag it up or down to another position, and then tap Done.
Gear Manager Installing applications Tap Samsung Apps. Browse applications and select an application to download. To browse and download suggested applications, tap My Apps → Featured. To install applications from sources other than Samsung Apps, tap Settings → Unknown Sources. Uninstalling applications Tap My Apps →...
Gear Manager Activating the notification features Stay up-to-date with a variety of events, such as missed calls or new messages, of the connected mobile device. Tap Settings → Notifications, and then drag the Notifications switch to the right. To activate notifications for each feature, select features by ticking. Setting an application shortcut You can launch an application quickly by pressing the Power button twice.
Gear Manager Smart relay Use this feature to view new messages, events, and other information on the mobile device when you receive notifications. Before using this feature, make sure the motion feature of the mobile device is activated. Tap Settings → Smart relay, and then drag the Smart relay switch to the right. When you receive a notification, pick up the connected mobile device while your device’s screen is on.
Applications Camera Use this application to take photos or videos. The device can save up to 50 photos and 15 videos. Use Gallery to view photos and videos taken with the device’s camera. (p. 35) Tap Camera on the Applications screen. Alternatively, flick down on the Clock screen. •...
Page 34
Applications Taking photos Taking a photo Tap the screen to take a photo. Switch between still and video Change the camera settings. mode. Taking a photo with sound → Sound & shot → On. Tap the screen to take a photo. The device records a few seconds of audio after taking a photo.
Applications Configuring settings for Camera to configure settings for Camera. Not all of the following options are available in both still camera and video camera modes. • F ocus mode: Select a focus mode. Auto is camera-controlled. Macro is for very close objects.
Applications Playing videos Video files show the icon on the preview. Select a video to watch it and tap Deleting files → Delete. When viewing a file, tap Sharing files → Share to send it to others or share it via social network services. When viewing a file, tap Sending files to a mobile device →...
Applications Find my device Use this application to find the connected mobile device. Tap Find my device on the Applications screen. Tap Start, the mobile device emits sounds, vibrates, and turns on the screen. This application is available only when the devices are connected. Logs Use this application to view call and message logs on the mobile device.
Applications Pedometer Use this application to track your steps and information about workouts for managing your health. Tap Pedometer on the Applications screen. Before You Start Exercising This app can be used to monitor your exercise. While moderate physical activity, such as brisk walking, is safe for most people, health experts suggest that you talk with your doctor before you start an exercise program, particularly if you have any of the following conditions: •...
Page 39
Applications When in Doubt - Check it Out If you are unsure of your health status, have several health problems, or are pregnant, you should speak with your doctor before starting a new exercise program. Working with your doctor ahead of time is a good way to plan an exercise program that is right and safe for you. Consider it the first step on your path to physical fitness.
Page 40
Applications Checking the walking status On the walking status screen, view the calorie burning status based on your walking pace. On the step count screen, flick to the right to access the walking status screen while counting your steps. Exercising with training courses On the S trainer screen, begin exercising by following the on-screen instructions.
Applications S Voice Use this application to command the device remotely by voice to dial a number, send a message, and more. Tap S Voice on the Applications screen. Alternatively, press the Power button twice. • T his application may not be available depending on the region or service provider. •...
Applications Timer Use this application to use the device as a countdown timer. Tap Timer on the Applications screen. Set the duration, and then tap Start. Tap Dismiss when the timer goes off. Today’s Schedule Use this application to view today’s events. Tap Today’s Schedule on the Applications screen.
Applications Playing voice memos Select a voice memo to play. If spoken text is recorded and the text converting is finished, appears next to the filename. The device shows the text on the screen during playback. • : Adjust the volume by tapping •...
Settings About Settings Use this application to configure the device and set application options. Tap Settings on the Applications screen. Clock Access and alter the following settings to control how the device displays the time and date. If the battery remains fully discharged, the time and date is reset. •...
Settings Sound Change settings for various sounds on the device. • S ound mode: Activate silent mode to make your device vibrate or mute all sounds, except for media sounds. • T ouch sounds: Set the device to sound when selecting an application or option on the touch screen.
Settings Battery View the remaining battery life. Bluetooth • B luetooth: Turn the Bluetooth wireless feature on or off. • V isibility: Set the device to be visible to other Bluetooth devices. Motions • S mart relay: Set to view new messages, events, and other information when you pick up your connected mobile device after receiving notifications on your device.
Settings Reset Gear Reset settings to the factory default values and delete all data. Gear info Access device information. • A bout Gear: Access device information. • U SB debug: Activate the USB debugging mode to connect your device to a computer with a USB cable.
Troubleshooting Before contacting a Samsung Service Centre, please attempt the following solutions. Some situations may not apply to your device. Your device does not turn on When the battery is completely discharged, your device will not turn on. Charge the battery completely before turning on the device.
Page 49
Troubleshooting Another Bluetooth device cannot locate your device • E nsure that the Bluetooth wireless feature is activated on your device. • R eset your device and try again. • E nsure that your device and the other Bluetooth device are within the maximum Bluetooth range (10 m).
Page 50
Troubleshooting Others cannot hear you speaking on a call • E nsure that you are not covering the built-in microphone. • E nsure that the microphone is close to your mouth. Sound echoes during a call Adjust the volume or move to another area. Audio quality is poor You may have connectivity problems due to issues with the mobile device’s network connections.
Page 51
Troubleshooting Your device is hot to the touch When you use applications that require more power or use applications on your device for an extended period of time, your device may feel hot to the touch. This is normal and should not affect your device’s lifespan or performance.
Page 52
Troubleshooting Data stored on the device has been lost Always make backup copies of all important data stored on the device. Otherwise, you cannot restore data if it is corrupted or lost. Samsung is not responsible for the loss of data stored on the device.
Page 53
Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. www.samsung.com English (EU). 10/2013. Rev.1.1...
