About this manual ™ You can use this device as a companion device to some Samsung Android smartphones or tablet PCs. This user manual is specially designed to explain applications and features that are available when the device is connected to a mobile device.
Table of Contents Getting started Gear Manager Device layout About Gear Manager Button Configuring the device settings Package contents Customizing the Home screen Charging the battery Managing applications Wearing the device Finding the device Turning the device on and off Activating the auto lock feature Connecting to a mobile device Activating the notification features...
Page 5
Table of Contents Timer Today’s Schedule Voice Memo Weather Settings About Settings Clock Sound Volume Display Battery Bluetooth Privacy lock Language Reset Gear Gear info Troubleshooting Health and Safety...
Getting started Device layout Touch screen Power button Microphone Camera Microphone Buckle Charging terminals Strap Speaker Humidity and liquids may damage your device. Keep your device dry. • Do not use a screen protector. This causes sensor malfunctions. • Do not allow water to contact the touch screen. The touch screen may malfunction in humid conditions or when exposed to water.
• Appearances and specifications are subject to change without prior notice. • You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase. • Other accessories may not be compatible with your device.
Use the charging cradle to charge the battery before using it for the first time. A computer can be also used to charge the device by connecting them via the USB cable. Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.
Page 9
Getting started Place the device on the charging cradle with the charging terminals facing each other. Close the cover of the charging cradle.
Page 10
• If the device is not charging properly, take the device and the charger to a Samsung Service Centre. After fully charging, disconnect the device from the charging cradle. Remove the device from the charging cradle, unplug the charger from the charging cradle, and then unplug the charger from the electric socket.
Getting started Checking the battery charge status When you charge the battery while the device is off, the following icons will show the current battery charge status: Charging Fully charged Wearing the device Release the buckle. • Be careful not to damage your fingernails when you release the buckle. •...
Getting started Press the buckle until it clicks. Turning the device on and off When turning on the device for the first time, follow the on-screen instructions to connect the device to a smartphone or tablet PC and set up your device. Press and hold the Power button for a few seconds to turn on the device.
Getting started Connecting to a mobile device By connecting the device to another mobile device, you can use applications and features on the connected mobile device. To connect the device to another mobile device, use the charging cradle that has an NFC tag and an embedded Bluetooth address that matches your device.
Page 14
If your mobile device does not have an NFC feature you must connect the devices manually. The steps and screens may vary depending on the mobile devices. Access Samsung Apps on the mobile device, and then download and install Gear Manager.
Page 15
Getting started Check the ID number on the device, and then select the device with the same number on the detected devices list. Accept the auto-generated passkey on both devices to confirm the connection. Read and agree to the terms and conditions. Using applications after connecting to a mobile device When the device is connected to a mobile device using the Bluetooth feature, you can use the following features and applications:...
Getting started • S Voice: Command the device by voice. • Today’s Schedule: View today’s events. • Weather: View weather information. Locking and unlocking the device When not in use, lock the device to prevent unwanted operation. Pressing the Power button on the Clock screen turns off the screen and puts the device into lock mode.
Getting started Switching to silent mode Use one of the following methods: • Press and hold the Power button, and then tap Sound or Vibrate. • On the Home screen, scroll to Apps, tap Apps → Settings → Sound → Sound mode → Vibrate or Mute.
Basics Indicator icons The following icons provide information about the status of the device. These icons appear when you double-tap the screen with two fingers. Icon Meaning Bluetooth feature activated Another Bluetooth device connected Battery power level Using the touch screen Use only fingers to operate the touch screen.
Basics Finger gestures Tapping To open an application, to select a menu item, or to press an on-screen button, tap it with a finger. Tapping and holding Tap and hold the screen with two fingers to open the list of recent applications.
Page 20
Basics Double-tapping • Double-tap on an image to zoom in a part. Double-tap again to return. • Double-tap the screen with two fingers to access the brightness and volume control panel and view indicator icons and the remaining battery life.
Basics Flicking Flick left or right on the Home screen or the Applications screen to see another panel. Pinching Spread two fingers apart on an image to zoom in a part. Pinch to zoom out. Notifications Once the device is connected to a mobile device and the mobile device is locked, you can receive notifications of activities, such as missed calls or new messages.
Basics Home screen The Home screen is the starting point to access all of the device’s features. It displays the clock, widgets, shortcuts to applications, and others. The Home screen can have multiple panels. To view other panels, scroll left or right. Panels on the Home screen Number Application or feature...
Basics Clock screen Press the Power button to open the Clock screen. On the Clock screen, you can launch Dialer by flicking up and launch Camera by flicking down. Tap the weather information to launch Weather. Applications screen The Applications screen displays icons for all applications. On the Home screen, scroll to Apps, and then tap Apps to open the Applications screen.
Basics Returning to the previous screen While using applications or on the Applications screen, flick down from the top of the screen. Securing the device Prevent others from using or accessing personal data and information stored in the device by using the pattern lock.
Bluetooth Bluetooth creates a direct wireless connection between two devices over short distances. • Samsung is not responsible for the loss, interception, or misuse of data sent or received via the Bluetooth feature. • Always ensure that you share and receive data with devices that are trusted and properly secured.
Basics Sending files to a mobile device To send images or videos, on the Applications screen, tap Gallery, select a file, and then tap → Transfer. To send voice memos, on the mobile device launch Gear Manager, tap My Apps → Favourites →...
Gear Manager About Gear Manager This application allows you to connect to a mobile device, customize your device settings and applications, and use features of the connected mobile device. From the connected mobile device, tap Gear Manager on the Applications screen. Configuring the device settings Access device information and update device software.
Installing applications Tap Samsung Apps. Browse applications and select an application to download. Applications are downloaded to both your device and the connected mobile device. To browse and download suggested applications, tap My Apps → Featured.
Gear Manager Uninstalling applications Tap My Apps → Installed apps. Tap → next to an application → OK. Default applications that come with the device cannot be uninstalled. Finding the device If you misplace the device, Gear Manager will help you find the device by making it emit sounds and turn on the screen.
Gear Manager Setting an application shortcut You can launch an application quickly by pressing the Power button twice. First, set a shortcut to a frequently-used application. Tap Settings → Double pressing power key, and then select an application. Setting up emergency messages Set the device to send an emergency message that includes a photo and your current location when you press the Power button 3 times.
Gear Manager Using a wake-up gesture Set the device to recognise your gesture to wake up the device when the screen is turned off. Tap Settings → Wake-up gesture, and then drag the Wake-up gesture switch to the right. To wake up the device, raise the hand wearing the device and look at the screen for a few seconds.
Applications Camera Use this application to take photos or videos. The device can save up to 50 photos and 15 videos. Use Gallery to view photos and videos taken with the device’s camera. (p. 34) Tap Camera on the Applications screen. Alternatively, flick down on the Clock screen. •...
Applications Taking photos Taking a photo Tap the screen to take a photo. Switch between still and video Change the camera settings. mode. Taking a photo with sound → Sound & shot → On. Tap the screen to take a photo. The device records a few seconds of audio after taking a photo.
Applications Configuring settings for Camera to configure settings for Camera. Not all of the following options are available in both still camera and video camera modes. • Focus mode: Select a focus mode. Auto is camera-controlled. Macro is for very close subjects.
Applications Playing videos Video files show the icon on the preview. Select a video to watch it and tap Deleting files → Delete. When viewing a file, tap Sharing files → Share to send it to others or share it via social network services. When viewing a file, tap Sending files to a mobile device →...
Applications Find my device Use this application to find the connected mobile device. Tap Find my device on the Applications screen. Tap Start, the mobile device emits sounds, vibrates, and turns on the screen. This application is available only when the devices are connected. Logs Use this application to view call and message logs on the mobile device.
Applications Pedometer Use this application to track your steps and information about workouts for managing your health. Tap Pedometer on the Applications screen. Before You Start Exercising This app can be used to monitor your exercise. While moderate physical activity, such as brisk walking, is safe for most people, health experts suggest that you talk with your doctor before you start an exercise program, particularly if you have any of the following conditions: •...
Page 38
Applications When in Doubt - Check it Out If you are unsure of your health status, have several health problems, or are pregnant, you should speak with your doctor before starting a new exercise program. Working with your doctor ahead of time is a good way to plan an exercise program that is right and safe for you. Consider it the first step on your path to physical fitness.
Page 39
Applications Checking the walking status On the walking status screen, view the calorie burning status based on your walking pace. On the step count screen, flick to the right to access the walking status screen while counting your steps. Exercising with training courses On the S trainer screen, begin exercising by following the on-screen instructions.
Applications S Voice Use this application to command the device remotely by voice to dial a number, send a message, and more. Tap S Voice on the Applications screen. Alternatively, press the Power button twice. • This application may not be available depending on the region or service provider. •...
Applications Timer Use this application to use the device as a countdown timer. Tap Timer on the Applications screen. Set the duration, and then tap Start. Tap Dismiss when the timer goes off. Today’s Schedule Use this application to view today’s events. Tap Today’s Schedule on the Applications screen.
Applications Playing voice memos Select a voice memo to play. If spoken text is recorded and the text converting is finished, appears next to the filename. The device shows the text on the screen during playback. • : Adjust the volume by tapping •...
Settings About Settings Use this application to configure the device and set application options. Tap Settings on the Applications screen. Clock Access and alter the following settings to control how the device displays the time and date. If the battery becomes fully discharged, the time and date are reset. •...
Settings Sound Change settings for various sounds on the device. • Sound mode: Activate silent mode to make your device vibrate or mute all sounds, except for media sounds. • Touch sounds: Set the device to sound when selecting an application or option on the touch screen.
Settings Battery View the remaining battery life. Bluetooth • Bluetooth: Turn the Bluetooth wireless feature on or off. • Visibility: Set the device to be visible to other Bluetooth devices. Privacy lock • Privacy lock: Activate the screen lock feature. •...
• Restart your device to clear any temporary software bugs. • Ensure that your device software is upgraded to the latest version. • If the touch screen is scratched or damaged, visit a Samsung Service Centre. Your device freezes or has fatal errors If your device freezes or hangs, you may need to close applications and turn on the device to regain functionality.
• Ensure that your device and the other Bluetooth device are within the maximum Bluetooth range (10 m). If the tips above do not solve the problem, contact a Samsung Service Centre. A connection is not established when you connect the device to a mobile device •...
Page 48
The battery icon is empty Your battery is low. Recharge the battery. The battery does not charge properly (For Samsung-approved chargers) • Ensure that you place the device on the charging cradle and connect the cradle to the charger properly.
Page 49
• Ensure that you have the proper driver installed and updated on your computer. • If you are a Windows XP user, ensure that you have Windows XP Service Pack 3 or higher installed on your computer. • Ensure that you have Samsung Kies installed on your computer.
Page 50
Data stored on the device has been lost Always make backup copies of all important data stored on the device. Otherwise, you cannot restore data if it is corrupted or lost. Samsung is not responsible for the loss of data stored on the device.
Page 51
• Use only Samsung-approved charger specifically designed for your device. Incompatible charger can cause serious injuries or damage to your device. • Samsung cannot be responsible for the user’s safety when using accessories or supplies that are not approved by Samsung.
Page 52
Health and Safety • Never crush or puncture the device. • Avoid exposing the device to high external pressure, which can lead to an internal short circuit and overheating. Protect the device and charger from damage • Avoid exposing your device to very cold or very hot temperatures. •...
Page 53
If you notice strange smells or sounds coming from your device or the battery, or if you see smoke or liquids leaking from the device or battery, stop using the device immediately and take it to a Samsung Service Centre Failure to do so may result in fire or explosion.
Page 54
Health and Safety • Position your device within easy reach. Make sure you can access your wireless device without taking your eyes off the road. If you receive an incoming call at an inconvenient time, let your voicemail answer it for you. •...
Page 55
Health and Safety Do not store your device with metal objects, such as coins, keys, and necklaces Your device may be scratched or may malfunction. Do not wear the device when you experience skin irritation If you experience skin irritation when you are wearing the device, stop wearing the device and consult a physician.
Page 56
Do not use the device if the screen is cracked or broken • Broken glass or acrylic could cause injury to your hands and face. Take the device to a Samsung Service Centre to have it repaired. Install devices and equipment with caution •...
Page 57
Protect your personal data and prevent leakage or misuse of sensitive information • While using your device, be sure to back up important data. Samsung is not responsible for the loss of any data.
Page 58
Health and Safety Malware and viruses To protect your device from malware and viruses, follow these usage tips. Failure to do so may result in damages or loss of data that may not be covered by the warranty service • Deactivate wireless features, such as Bluetooth, when not in use. •...
Page 59
THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. ” Third party services may be terminated or interrupted at any time, and Samsung makes no representation or warranty that any content or service will remain available for any period...
Page 60
Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be...
Page 61
Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. www.samsung.com English (CA). 09/2013. Rev. 1.0...
